- Page 1 Assembly Instructions Headline Universal Fire Pit Coffee Table 142 x 92cm & Stone Fire Pit Coffee Table 132 x 85cm KLFP202-0300 / KLFP202-0400 IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE USE AND CARE OF GAS FIRE PIT.
-
Page 2: Table Of Contents
Headline Index WARNING This appliance is intended for decorative purposes. For Outdoor use only. Keep the instructions for future reference. Read the instructions before installation and use. For gas adjustment refer to Appliance Marking. This manual book is for 30mbar version, Maximum gas bottle size including regulator: 390mm Index Safety Warnings... -
Page 3: Safety Warnings
Safety Warnings Warning • Do not modify the appliance • Do not move the appliance during use • Turn off the gas supply at the gas container after every use • Accessible parts may be very hot. Keep young children away •... - Page 4 Safety Warnings WARNING Failure to heed the Dangers, Warnings and Cautions contained in this Owner’s Manual may results in a serious explosion causing damage to property, bodily injury. GENERAL WARNINGS IF YOU SMELL GAS: FOR OUTDOOR USE ONLY 1. Shut off gas supply to the fireplace table. DO NOT SIT OR STAND ON TABLE 2.
- Page 5 Safety Warnings DO NOT • This outdoor fireplace table is to be • use this outdoor gas fireplace for indoor heating. TOXIC carbon monoxide operated by children. Young children should fumes can accumulate and cause be closely supervised when in the vicinity of asphyxiation.
- Page 6 Safety Warnings • Use only the regulator and hose assembly this purpose. provided. Use only replacement regulator DO NOT • use this outdoor fireplace table if and hose assemblies specified by the any part has been under water. Immediately manufacturer. call a qualified service technician to inspect the fireplace table and to replace any part •...
-
Page 7: Gas (Lpg) Warnings
Safety Warnings GAS (LPG) WARNINGS • Before each use, remove the lava rocks. Examine the burner and its components. • LP gas is flammable and hazardous If dirty, clean with a soft brush and soapy if handled improperly. Please review water solution. - Page 8 Safety Warnings NEVER • the pressure regulator is set for 28-30mbar or • use an LP gas tank with a damaged body, valve, collar, or footing. Dented or 50mbar. rusted LP gas tanks may be hazardous and • Regulator outlet pressure is 28~30mbar or should be checked by your LP gas supplier 50mbar.
- Page 9 Safety Warnings not over 1.5 m and approved for a working temperature not lower than 60 ˚C. When substitution will be necessary, you have to purchase suitable gas regulator, flexible gas rubber pipe and clamps from your local gas dealer; gas regulator should be substituted not over 10 years.
- Page 10 Safety Warnings Warning 1. Do not obstruct the ventilation holes 9. Use only the type of gas and the type of cylinder specified by the of the cylinder housing; manufacturer; 2. Close the gas supply at the valve of the gas cylinder or the regulator after use;...
-
Page 11: Technical Data
Technical Data KLFP202 16 kW (G30: 1164 g/h, G31: 114g/h) 2.05 mm 2.05... - Page 12 Technical Diagram - KLFP202-0300 / KLFP202-0400 HES Cross Screw & Nut 24” H Burner Component Burner Baffle Orifice Connector & Orifice Ignition Needle Back up Plate for Burner Thermocouple 31” Rectangular Fire Pan Control Panel Flex Line Safety Valve Electric Igniter...
-
Page 13: Installation
Installation 1. This Gas Fire Pit must be installed on flat, 5. Open the door and take down the lid of stable surface, away from any combustible cylinder cargo carefully and put it in the materials or construction. center of the tank bracket. (See fig 6-7) 2. -
Page 14: Instruction For Connecting Gas Circuit To Lpg Cylinder
Instruction for connecting gas circuit to LPG cylinder Keep at hand suitable crossed screwdriver, 1. Make sure appliance gas knob is turned adjustable spanners, pliers and wrenches. “OFF” (full disk) before assembling (Fig 3). Before assembly, make sure all protection packing material has been removed. - Page 15 Instruction for connecting gas circuit to LPG cylinder Note: 3. Connect the regulator to LPG cylinder by For model KLFP213-0200. The hose hand. Push down until you hear a click. must be fixed by the hose fixation clamp. (see Fig 5) Fig 5 4.
-
Page 16: Operating Instructions
Operating Instructions Lighting 1. Make sure the fireplace table is stable and in solid state. Leakage Test Points 1, 2, 3, 4 2. Remove the protective cover. 3. Press the control button fully until you hear a slight ticking sound (this is the piezo ignition). -
Page 17: Maintenance And Cleaning
Maintance & Cleaning To enjoy years of outstanding performance heavy duty pipe cleaner. Compressed air may help clear away smaller particles. from your appliance, regular service of the appliance is mandatory as follows: • Carbon deposits may create a fire hazard. If •... -
Page 18: Troubleshooting
Troubleshooting Problem: Condition: Solution suggested: Control knob is not in Turn the control knob to the maximum position Maximum position (big flame). (big flame). LPG cylinder valve is closed / Open the valve / Replace LPG cylinder with a new Empty. -
Page 19: Storage (After Use)
Troubleshooting / Storage Problem: Condition: Solution suggested: Carbon build-up Dirty or film on burner. Clean burner. Switch OFF the appliance. Close LPG cylinder Flash back (flame valve. Wait 2 minutes, following the ignition Burner ports are blocked. inside burner) procedure. Ignite burner. If problem continuous, switch-off. - Page 20 Headline Warranty For Home Use This product is covered by a 3 year www.kettler.co.uk warranty against manufacturing faults. This warranty applies to domestic use only. It does not cover commercial use, mis-use or accidental damage. To validate your warranty, register The symbol indicates that the product should not be discarded as at www.kettler.co.uk and quote...
