Single
Ball Holder
Assembly instructions
Assemble unit by inserting pressed wire ends
1
into slots on plastic base and snap in back plate.
Identify where wooden stud lies within wall,
2
drill pilot holes for wood screws.
3
Secure to wall by tightening both screws.
Tools Required
Hand Drill 1/8"(3mm)
Do not exceed maximum total weight limit of 4.5kg/10lbs.
To avoid injury, Do not overload.
UH4000
Horizontal Mounting Option
STUD
CENTERLINE
STUD
WALLBOARD
