Contents Health and Safety �������������������������������������������������������������������������������������������� Remove and attach covers ������������������������������������������������������������������������������ Install an M�2 SSD �������������������������������������������������������������������������������������������� Attach or remove the disc drive �������������������������������������������������������������������� When disposing of the controller ������������������������������������������������������������������ Use and handling ������������������������������������������������������������������������������������������� Specifications �������������������������������������������������������������������������������������������������� HARDWARE WARRANTY ��������������������������������������������������������������������������������� Compliance information ��������������������������������������������������������������������������������� Copyright and trademarks �����������������������������������������������������������������������������...
Health and Safety Before using this product, carefully read this manual and retain it for future reference� IMMEDIATELY DISCONTINUE USE and consult your physician before resuming gameplay Parents and guardians of children should read this manual and make sure that children if you or your child experience any of the following health problems or symptoms: follow all safety precautions�...
Page 5
Health and Safety LITHIUM-ION BATTERY Static shock The controller contains a lithium-ion rechargeable battery� Do not handle damaged or When using the headset or headphones in particularly dry air conditions, you may leaking lithium-ion batteries� If the built-in battery fluid leaks, stop using the product sometimes experience a small and quick (static) shock on your ears�...
Page 6
Health and Safety AC power cord and cables • When setting up or carrying the console, be careful to securely hold the main body of the console� Do not hold, carry, or lift the console by only the cover; doing so could •...
Remove and attach covers Remove the covers when performing maintenance on your console, or when installing Place the console with the bottom facing up and the front side facing an M�2 SSD or disc drive� you, and then remove the feet. Safety warnings Remove the cover.
Install an M.2 SSD M�2 SSD is storage that uses flash memory� Install a commercially available M�2 SSD in Install or remove an M.2 SSD your PS5 console for more storage for your game and app data� Safety warnings Before installing or removing an M�2 SSD, please read the following safety precautions� Types of M.2 SSD You can use an M�2 SSD with the following specifications: Caution...
Page 9
Install an M.2 SSD Remove the screw from the expansion slot cover and then remove the Holding the edge of the M.2 SSD, align it with the notch on the cover. expansion connector. Tilt the M.2 SSD diagonally upward, and firmly insert it all the way into the expansion connector.
Attach or remove the disc drive If you have purchased a console without a disc drive installed, attach the disc drive (sold • Consult our support website if you lose parts such as the expansion slot cover, separately) to play disc-based games, Blu-ray Discs™ and DVDs� screws, and spacers (back cover)�...
Page 11
Attach or remove the disc drive Attach the disc drive Remove the disc drive Place your console on a soft cloth spread over a flat surface before attaching your disc Place your console on a soft cloth spread over a flat surface before removing your disc drive�...
When disposing of the controller Using a crosshead screwdriver, remove the screws (4 places). The lithium-ion battery of the controller is recyclable� When disposing of the controller, remove the battery and follow local regulations regarding disposing of batteries� Caution • Remove the battery in a location out of the reach of small children to help prevent accidental swallowing of small parts such as the screws�...
Use and handling Never disassemble or modify the console or accessories Cabinet (the plastic parts of the console and controller) • Wipe down with a soft, dry cloth� Use the console and accessories according to the instructions in the product •...
Specifications DualSense™ wireless controller Design and specifications are subject to change without notice� Depending on the software version in use, the console may operate differently than described in this manual� Input power rating 1,500 mA PlayStation®5 console Battery type Built-in lithium-ion battery Battery voltage 3�65 V Console with the disc drive...
Page 15
• If you cannot update over the internet, you can use a game disc or USB drive instead� For details, visit playstation�com/help/� Region code • The system software included within this product is subject to a limited license from Sony Interactive Entertainment Inc� Blu-ray Disc™ (BD) Refer to https://doc�dl�playstation�net/doc/ps5-eula/ for further details� PlayStation®4 format Blu-ray™...
HARDWARE WARRANTY Compliance information For warranty terms and conditions of respective regions, please refer to the PS5 console and wireless controller compliance with IMDA standards “Support”page of the official website https://playstation�com/help/, or call our Customer Service Hotline (back cover)� Complies with IMDA Standards DB102988...
AMD, Radeon and Ryzen are trademarks of Advanced Micro Devices, Inc� The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc� and any use of such marks by Sony Interactive Entertainment Inc� is under license� Other trademarks and trade names are those of their respective owners�...
Page 50
수출 통상 규제에 대하여 본 제품은 각국의 수출 통상 규제에 관한 법률 안에 포함됩니다. 사법권에 적용되는 본 제품과 관련된 모든 법률을 준수해야 하며 모든 법률적 요구에 응해야 합니다.
Page 51
목차 건강 및 안전 ................... 커버 제거 및 부착 ..................M.2 SSD 설치하기 .................. 디스크 드라이브 부착 또는 제거 ..............컨트롤러를 폐기할 때 ................사용 및 관리 ................... 주요 사양 ........................................저작권/상표 ...................
건강 및 안전 제품을 사용하시기 전에 본 사용설명서를 잘 읽으시고 나중에 참고하실 수 있도록 잘 보관해 주십시오. 전파에 대하여 부모 및 어린이 보호자는 본 설명서를 읽고 어린이가 모든 안전 예방책을 준수하는지 확인해 주십시오. 전파가 전자기기나 의료 기기(심장 박동기 등)에 영향을 미쳐 오작동에 의한 사고나 부상의 원인이 될 당사...
Page 53
건강 및 안전 제품이나 액세서리의 분해 또는 개조 금지 모션 센서 화재, 감전 또는 부상의 위험이 있습니다. 컨트롤러의 모션 센서 기능을 사용하는 경우 다음 사항에 주의하십시오. 컨트롤러가 사람 또는 물체와 충돌할 경우 예기치 않은 부상 또는 손상이 발생할 수 있습니다. •...
Page 54
건강 및 안전 설치 및 관리 호환성 • 밀폐식 AV 랙 등 열이 빠져나가지 못하는 장소에 설치하여 사용하지 마십시오. 콘솔이 과열되어 PlayStation ® , PlayStation ® 2 및 PlayStation ® 3 전용 컨트롤러, 아날로그 컨트롤러 화재나 부상, 고장의 원인이 됩니다. (DUALSHOCK ®...
커버 제거 및 부착 콘솔에서 유지보수를 수행하거나 M.2 SSD 또는 디스크 드라이브를 설치할 경우 커버를 제거해 커버를 제거해 주십시오. 주십시오. 콘솔에서 커버를 살짝 들어 올려 클립을 분리하고 제거해 주십시오. 안전상의 유의사항 커버를 제거하거나 부착하기 전에 다음 안전상의 유의사항을 읽어 주십시오. 주의...
M.2 SSD 설치하기 M.2 SSD는 플래시 메모리를 사용하는 스토리지입니다. PS5에 게임 및 앱 데이터용으로 더 많은 M.2 SSD 설치 또는 제거하기 스토리지가 필요한 경우 시판되는 M.2 SSD를 설치하십시오. 안전상의 유의사항 M.2 SSD를 설치하거나 제거하기 전에 다음 안전상의 유의사항을 읽어 주십시오. M.2 SSD 유형...
Page 57
M.2 SSD 설치하기 확장 슬롯 커버에서 나사를 제거하고 커버를 제거합니다. M.2 SSD의 가장자리를 잡고 확장 커넥터의 홈 부분에 맞추어 주십시오. M.2 SSD를 대각선 위쪽으로 기울인 후 확장 커넥터 안쪽 끝까지 확실하게 삽입해 확장 슬롯 커버 주십시오. 다음은 히트 싱크와 열 전달 시트가 부착된 M.2 SSD입니다. 나사와...
디스크 드라이브 부착 또는 제거 디스크 드라이브가 설치되지 않은 콘솔을 구입한 경우 디스크 드라이브(별매품)를 부착하여 디스크 • 확장 슬롯 커버, 나사 및 스페이서와 같은 부품을 분실한 경우 당사 지원 웹사이트를 참조해 기반 게임을 플레이하거나 Blu-ray Disc™ 및 DVD를 재생해 주십시오. 주십시오...
Page 59
디스크 드라이브 부착 또는 제거 디스크 드라이브 부착 디스크 드라이브 제거 편평한 표면에 펼쳐져 있는 부드러운 천 위에 콘솔을 놓은 후 디스크 드라이브를 부착해 주십시오. 편평한 표면에 펼쳐져 있는 부드러운 천 위에 콘솔을 놓은 후 디스크 드라이브를 제거해 주십시오. 커버를 제거합니다(55 페이지). 커버를...
컨트롤러를 폐기할 때 컨트롤러에 내장되어 있는 리튬-이온 배터리는 재활용할 수 있습니다. 컨트롤러를 폐기할 때에는 십자(+) 드라이버로 나사를 풉니다 (4 군데). 배터리를 분리한 후 지자체의 폐기 관련 규정에 따라 주십시오. 주의 • 배터리를 분리할 때에는 어린이의 손이 닿지 않는 곳에서 분리해 주십시오. 나사 등의 부품을 삼킬...
사용 및 관리 절대 콘솔이나 주변기기를 임의로 분해하거나 개조하지 마십시오 환기구 환기구를 막지 마십시오. 환기가 잘 될 수 있도록 아래의 사항을 지켜 주십시오. 콘솔과 주변기기는 본 사용설명서에 안내되어 있는 방법에 따라 사용해 주십시오. 콘솔을 분해/내부 • 벽면에서 최소 10cm 이상 떨어져서 설치해 주십시오. 해석/개조하는...
주요 사양 디자인 및 사양은 예고없이 변경될 수 있습니다. *4 HDMI 케이블은 동봉된 것을 사용해 주십시오. 본 문서에 기재된 조작설명은 시스템 소프트웨어의 버전에 따라 다를 수 있습니다. *5 지역/국가에 따라 다릅니다. *6 이 제품은 1ch에서 11ch까지만 사용 가능합니다. PlayStation ® DualSense™...
Page 63
AS 규정/보증 규정 주의 Sony Interactive Entertainment Korea Inc.(이하 당사)는 다음 내용에 따라 고객님께 AS를 • 콘솔의 BD/DVD 지역 코드를 재생되는 디스크로 변경할 수 있습니다. 지역 코드는 최대 네 번 제공합니다. 본 규정을 잘 숙지 후 동의하실 경우 AS를 의뢰해 주십시오. 보증 기간은 구입일로부터...
Page 64
(https://playstation.com/help/)를 참조해 주십시오. 2) 견적을 낸 후에 교환/수리를 취소하신 경우 일정 요금이 부과될 수 있습니다. 보증 기간 중 정상적인 사용 상태(사용설명서 등의 주의사항에 따라 바르게 사용한 상태)에서 고장날 경우에는 Sony Interactive Entertainment Korea Inc.에서 데이터에 대하여 무상으로 수 리해 드립니다.
Bluetooth ® SIG, Inc. and any use of such marks by Sony Interactive Entertainment Inc. is under 당사는 이 규정을 언제라도 갱신/수정할 수 있으며 AS 시에는 최신의 규정이 license. Other trademarks and trade names are those of their respective owners.
