CarHD Camera 1080P TX–14
Declaration of Conformity: www.technaxx.de/ (in bottom bar "Konformitätserklärung")
Before using the device the first time, read the user manual carefully.
Attention: In order to help you operate it correctly please read this instruction carefully
using. Charge the device once before use. Important: During usage connect the device
directly to the cigarette lighter socket of your car!
Features
Car camcorder (video & photo & playback function) with Full HD resolution
2.7" high resolution LTPS display (16:9)
Supports MicroSD memory card (up to 32GB)
120°A and high resolution wide angle lens (3.0 mega pixels, JPEG format)
4x digital zoom, ranges from 12cm to limitless distance
WDR (Wide Dynamic Range technology)
1920 x 1080P FULL HD high quality video resolution
Advanced MOV H.264 video compression technology
Supports HDMI hight quality video transmission
Start video recording: automatic video recording with record time setting
Shows time and date on video and pictures
G-sensor function (explanation see later)
Anti-Shake mode
1080P 30fps, 720P 30fps, smooth video flow
Microphone & Speaker
Built-in simultaneous charging and recording mode
Motion detect function
USB2.0 and HDMI output
Live playback function (watch video while recording a video)
Auto power on when starting car and Auto power off when car is off
Continuous cycle recording mode: in case of full storage, recording goes on. Existing
files will be deleted one after the other.
Plug into car cigarette lighter as a power supply for video recording while driving.
Camera installation on bracket, easy to fix and to dismantle
Bracket installation on windscreen by suction cup
User Manual
Advertisement
Table of Contents
Related Manuals for Technaxx CarHD Cam 1080P TX-14
Summary of Contents for Technaxx CarHD Cam 1080P TX-14
- Page 1 CarHD Camera 1080P TX–14 User Manual Declaration of Conformity: www.technaxx.de/ (in bottom bar “Konformitätserklärung”) Before using the device the first time, read the user manual carefully. Attention: In order to help you operate it correctly please read this instruction carefully using.
-
Page 2: Product Overview
Product Overview USB port MicroSD card slot AV port UP button No function DOWN button POWER button REC button / OK button MENU button MODE button Lens HDMI port Speaker RESET button DESCRIPTION OF THE KEYS POWER button Switch the camera ON / OFF MENU button Select optional menu UP button... -
Page 3: Setting Mode
Starting to use the car camcorder Placing the MicroSD card: Insert a MicroSD card into the memory card slot by pushing it carefully until you hear a “Click” sound. Remove the MicroSD card by pushing it once and then remove it after it pops out. Turning ON / OFF: Press the POWER button once to power on, blue light indicator is on. - Page 4 Record Video and enter Setup Shooting video: In video mode press OK button to start recording, press the OK button again to stop recording. Video option settings: In video mode press MENU button to enter. Image resolution: see under technical specifications. Time display: ON / OFF.
-
Page 5: Manage Files
(use a clean drapery). Avoid using rough, coarse-grained materials/solvents/other aggressive cleaner. Wipe the cleaned device. Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany... - Page 6 Descriptions of symbols during video & photo recording Video Mode Video Recording Mode Recording Wide Angle (Wide Dynamic) Exposure Value G–Sensor (ON) Recording Time for present video; if you stop video recording, this icon shows “remaining time” for recording. Video Resolution Date and Time...
-
Page 7: Picture Mode
Day Mode Night Mode Voice Recording (ON) G–Sensor Grade MicroSD Card Battery Status Picture Mode... - Page 8 Picture Mode Exposure Value White Balance ISO Display “Anti–Shake” Mode Shows the remaining quantity of pictures. Picture Size MicroSD Card Battery Status...
