U S E R G U I D E
A commitment to:
Stoves BI 90 Gas
Part Number: 083684600
Date: 14/11/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BI 90 Gas and is the answer not in the manual?

Questions and answers

Summary of Contents for Glen Dimplex Home Appliances BI 90 Gas

  • Page 1 U S E R G U I D E A commitment to: Stoves BI 90 Gas Part Number: 083684600 Date: 14/11/17...
  • Page 2 Our policy is one of constant development and improvement, therefore we cannot guarantee the strict accuracy of all of our illustrations and specifications. Changes may have been made subse- quent to publishing. Glen Dimplex Home Appliances, Stoney Lane, Prescot, Merseyside, L35 2XW...
  • Page 3 INTRODUCTION Thank you for buying this British-built appliance from us. This user guide book is designed to help you through each step of owning your new product. Please read it carefully before you start using your appliance, as we have endeavored to answer as many questions as possible, and provide you with as much support as we can.
  • Page 4 SAFETY WARNING • During use the appliance becomes hot. Care should be taken to avoid touching heating elements. • The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
  • Page 5 process has to be supervised continuously. • This appliance must not be installed behind a decorative door in order to avoid overheating. • Fire Safety Advice If you do have a fire in the kitchen, don’t take any risks - get everyone out of your home and call the Fire Brigade.

  • Page 6: Using Your Appliance

    USING YOUR APPLIANCE Getting to know your product Note: Your appliance layout may differ depending on the model. Control Panel Main Oven Top Oven/Grill Clock/Programmer Oven / Grill functions Note: Your oven may not have all of the functions shown here. We recommend for best cooking results, please preheat for 15 minutes.
  • Page 7 Top Oven / Grill Main Oven Oven/Grill Some appliances are automatic ignition and do not have an ignition switch fitted. Ovens Grill When using the oven/grill, the red thermostat indicator will come on until the selected temperature is reached. When the ovens or grill are switched on, the cooling fan comes on to keep the fascia and control knobs cool during cooking/grilling.
  • Page 8 Grill THE DOOR MUST BE OPEN WHEN THE GRILL IS USED FOR CONVENTIONAL GRILLING. Grill pan, trivet and detachable grill pan handle The grill trivet, inside the grill pan, can be inverted to give a high or low position, or it may be removed. The speed of grilling can be controlled by selecting a higher or lower shelf position, or adjusting the grill setting.

  • Page 9: Using The Touch Controls

    Please be aware that only the main oven is controlled by the programmer. Clock / Programmer Note: Your clock / programmer may not have all these functions Minus Menu Plus Minute minder Manual mode Volume level Cooking time / Duration 7-segment display End of cooking time Max.

  • Page 10: Setting The Time Of Day

    Setting the time of day By pressing menu, scroll through the functions until you reach ‘time of day’. Press the function button until the ‘time of day’ Press the plus or minus buttons to set a time symbol appears Setting the minute minder The maximum cooking time that can be set is 99 minutes.
  • Page 11 To modify or cancel the minute minder Return to the minute minder function and use either the plus or minus buttons to adjust the time. By setting the time to ‘0.00’, this will cancel the countdown. Setting the cooking time (the duration of time the oven will operate for) Semi Auto- matic cooking The maximum cooking time that can be set is 23 hours and 59 minutes.

  • Page 12: Setting The Volume

    Setting the volume Press the menu button until “LX” (X = 1, 2 or 3) flashes on the display. Use the plus or minus buttons to select a tone. Note: Default tone is L3 Activating / deactivating Key lock Press and hold the plus button for 3-5 seconds Once the Key lock is active, the buttons will be inactive.
  • Page 13 Removing Shelf Runners Telescopic positions Telescopic positions (if fitted) (if fitted) Standard shelves Slightly raise the shelf and insert in the chosen shelf position Ensure the shelf is fully pushed back towards the back of the oven, until the shelf stopper is reached.

  • Page 14: Changing The Light Bulb

    Removing Telescopic shelves (if fitted) Grasp and lift shelf Lift shelf from the retaining tabs. Front of appliance Before removing the shelves completely, please make sure that the shelf is unclipped from the retaining tabs. Changing the light bulb Not all appliances have the same number and type of bulbs. Before you replace your bulb, check to see what type you have.

  • Page 15: Cleaning Your Appliance

    CLEANING YOUR APPLIANCE Do’s Note: Always switch off your appliance and allow it to cool down before you clean any part of it. Note: Please take extra care when cleaning over the symbols on the control panel, as this can lead to them fading.

  • Page 16: Technical Data

    TECHNICAL DATA Gas built in oven Databadge Lower part of the front frame and rear of the appliance Electric supply 220V - 240V ~ 50Hz 1W - maximum 2660W (if fitted with an electric grill) Appliance class Class 3 built in oven and grill Gas category Natural Gas I (20)
