Genki GK-1200 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
G K- 1 2 0 0
| U s e r M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK-1200 and is the answer not in the manual?

Questions and answers

Related Manuals for Genki GK-1200

Summary of Contents for Genki GK-1200

  • Page 1 G K- 1 2 0 0 | U s e r M a n u a l...
  • Page 3 Read all safety tips, warning messages, terms of use, and disclaimers carefully. Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant regulations and using GENKIPWR products in a way that is compliant. GENKIPWR GK-1200...

  • Page 4: Table Of Contents

    CONTENTS Specifications 2. Safety Instructions 2.1 Usage 2.2 Disposal Guide 3. Getting Started 3.1 Product Introduction 3.2 Product Details 3.3 LCD Screen 3.4 Display Attention 3.5 UPS Mode 3.6 Solar Panel Connection 3.7 Car Charging 4. FAQs 5. What’s in the Box 6.

  • Page 5: Specifications

    1. Specifications General Info Net Weight Approximately 27.6lbs (12.5kg) Dimensions 15.4in x 9.1in x 12.6in(39 x 23 x 32 cm) Capacity 960Wh 48V Output Ports Pure Sine Wave, 1200W total (Surge 2400W), AC (x2) 100V-120V（US、JP）/220-240V (EU) / 50Hz/60Hz Max Device(s) Power Supported by X-Boost 1800W (Constant power) USB-A (x2) 2.4A, per port...

  • Page 6: Safety Instructions

    2. Safety Instructions 2.1 Usage 1. Do not use the product near a heat source, such as a fire source or a heating furnace. 2. Avoid contact with any liquid. Do not immerse the product in water or get it wet. Do not use the product in rain or humid environments.

  • Page 7: Disposal Guide

    equipment, please be sure to monitor the power status to ensure that the power does not run out. 18. When in use, power supply products will generate electromagnetic fields, which are likely to affect the normal operation of medical implants or personal medical equipment such as pacemakers, cochlear implants, hearing aids, defibrillators etc.

  • Page 8: Getting Started

    3. Getting Started 3.1 Product introduction This product is a 960Wh large capacity 1200W high power, 1.5 hours of high-speed charging portable energy storage power supply, using high safety performance of LiFePO4 battery. It can be used as a backup power supply in case of emergency powercut,disaster, camping and vehicles, and can also provide power for various electric tools.
  • Page 9 ① Main Power Control Main Control for the whole system turn on/off. Operate method: long press the button for 3s to turn on/off the system. ② LED light control Operate method: short press to turn on and change the light mode(SOS/Flash). Notice: you can turn off the light by long press the button(1-2s) in any mode.

  • Page 10: Lcd Screen

    ⑩ Overload protection To protect this product, an overload protector is added. Prevent damage to the product due to excessive AC input current caused by lightning and power grid fluctuations. When such a situation occurs, the overload protector will start to cut off the AC input to protect the product Restore the AC input function of the product in the following sequence.

  • Page 11: Ups Mode

    3.5 UPS mode UPS function GENKIPWR has the bypass mode, when charging, it directly supply power from AC to DC load without passing through the battery, when grid is off it can switch to DC-DC automatically and allow battery to discharge power to load continously within 10ms.

  • Page 12: Car Charging

    By solar panels Connecting Pattern ② 3.7 Car charging This product can be charged by the cigarette lighter in the car with an ACC cable(accessory: ACC hereinafter). Turn on GENKIPWR, connect the ACC charging cable to the cigarette lighter in the car and the XT60 interface on the side of the product, turn on the engine of the car, and the LCD of this product will show the input power.

  • Page 13: Faqs

    4. FAQs 1.What battery does the product use? It uses high-quality LiFePO4 battery. 2. What devices can the product's AC output port power? With 1800W constant power, the product's AC output port can power most household appliances. Before you use it, we recommend that you confirm the power of the appliances first and ensure the power sum of all loaded appliances is lower than the rated power.

  • Page 14: What's In The Box

    5. What’s in the Box G K- 1 2 0 0 | U s e r M a n u a l GK-1200 AC Charging Cable User Manual Car Charging Cable Solar Charging Cable 6. Storage & Maintenance 1. Ideally, use and store the product between 20°C to 30°C(68° to 86), and always keep it away from water, intense heat, and sharp objects.
