Gourmia GAF778 - 7-Quart Stainless Steel Digital Air Fryer Manual

Also See for GAF778:

User manual (20 pages)

Table of Contents

Contents

1 KNOW YOUR DEVICE
- 1.1 DISPLAY AND CONTROL PANEL
2 DISPLAY MESSAGES
3 PRESETS CHART
4 USING YOUR DEVICE
5 COOKING TIPS
6 CLEANING & MAINTENANCE
7 TROUBLESHOOTING
8 IMPORTANT SAFEGUARDS
9 Documents / Resources
- 9.1 References
- 9.2 Download manual

Gourmia GAF778 - 7-Quart Stainless Steel Digital Air Fryer Manual

KNOW YOUR DEVICE

KNOW YOUR DEVICE - Part 1
KNOW YOUR DEVICE - Part 2
Crisper Tray
Place the Crisper Tray into the Basket with the arrow on the tray facing the back of the Basket.

DISPLAY AND CONTROL PANEL

PREHEAT
Preheating the air fryer before adding food will generally deliver the best results. When cooking multiple batches in a row, only preheat before the first batch.
Tap PREHEAT before START to enable or disable preheating. When preheating is enabled, PREHEAT appears in red on the Display.

TURN REMINDER
Turning or tossing food halfway through cook time will deliver evenly browned and crispy results.
Tap TURN REMINDER before START to enable or disable Turn Reminder. When Turn Reminder is enabled, TURN appears in red on the Display.

See 'Presets Chart' for Presets that have Preheat and Turn Reminder on by default and those that have the option to toggle the settings on and off.

DISPLAY MESSAGES

Preheat is enabled.

Turn Reminder is enabled.

Display Messages - Pre heat
The air fryer is preheating.

Display Messages - Add Food
The air fryer is preheated.

Display Messages - Turn Food
Reminder to turn or toss food.

The cook time has elapsed.

PRESETS CHART

Note: A check mark indicates Preheat and Turn Reminder can be enabled or disabled by tapping PREHEAT/TURN REMINDER before tapping START.

USING YOUR DEVICE

BEFORE FIRST USE

Remove all packaging stickers and labels from the air fryer, including the tape securing the Pan to the unit.
To pull out the Basket for cleaning, remove the tape securing it into place. Secure the unit with one hand and pull the handle straight back with the other hand.
Thoroughly clean the Basket and Crisper Tray with hot water, some dishwashing liquid, and a non-abrasive sponge.
Wipe the inside and outside of the air fryer with a moist cloth.

Note: During the first few uses, there might be a "hot plastic" smell. This is perfectly normal in new air fryers as the material is heated for the first time. It will go away after the first few uses.

Do not fill the Basket with oil, frying fat, or any other liquid - this appliance works by circulating hot air.
Do not put anything on top of the air fryer.
Do not place the air fryer against a wall or against other appliances. It is important to leave at least 4 inches of free space around the back and sides, and 4 inches of free space above the air fryer to allow for proper ventilation.

USING YOUR DEVICE

Place the air fryer on a stable, horizontal, heat-resistant, and level surface.
Insert the Crisper Tray into the Basket and slide it into the air fryer.
Plug the air fryer into an outlet.
Tap the Power Icon to turn on.
Tap the desired Preset.
The Display will show the preset temperature and time.

To adjust temperature and time follow instructions from 'ADJUSTING THE TEMPERATURE AND TIME'.

With PREHEAT Enabled (enable before tapping START.)

Tap START.
The Display will show "Preheat" ( ) and the air fryer will begin preheating. Once preheated, it will beep 5 times and the Display will show "Add Food" ( ).

Basket will be hot!
Remove the Basket carefully, place food inside, and return it to the air fryer to automatically begin cooking.

Remove the Basket, place food inside, and return it to the air fryer.
Ensure Preheat is disabled and Tap START.

Cooking Tip: Spray food with cooking oil for a crispier finish.

With TURN REMINDER Enabled (enable before tapping START.)

Halfway through the cook time, the air fryer will beep 5 times and the Display will show "Turn Food" ( ).
Remove the Basket carefully and place it on a heat-resistant surface.
Turn or toss the food using tongs.
Return the Basket to the air fryer to automatically resume cooking.

Note: If the Basket is not removed, cooking will resume.

When your selected cook time has elapsed, the air fryer will beep 5 times and the Display will show "End" ( End ).

Remove the Basket carefully and place it on a heat-resistant surface.
Remove food from the Basket using tongs.

Always use caution when removing the Basket during/after cooking.

Carefully remove Basket - hot steam may escape!

The Basket and food will be hot! Do not touch hot surfaces.

Do not use sharp or metal utensils to avoid scratching the nonstick surface.

Do not turn the Basket upside down, as any excess oil that has collected on the bottom of the Basket will leak onto the food.

ADJUSTING TEMPERATURE AND TIME

Cooking Tip: For ideal temperature and time settings for various foods, see the Air Fry Cooking Chart and Dehydrate Chart in the Gourmia Recipe Book.

Tap TEMP/TIME to adjust temperature.
Tap + and - icons to increase and decrease temperature.
Tap TEMP/TIME again to adjust time.
Tap + and - icons to increase and decrease time.

Tip: Press and hold + and - icons to increase and decrease temperature and time rapidly.

STOP/CANCEL COOKING

Tap STOP/CANCEL once to stop cooking. Tap START to resume cooking.

Removing the Basket from the air fryer during cooking will stop cooking. Returning the Basket to the air fryer will automatically resume cooking.

Tap STOP/CANCEL twice to cancel cooking.

COOKING TIPS

For an extensive list of foods and their ideal amounts, temperature and time settings, along with preparation notes, see the Air Fry Cooking Chart and Dehydrate Chart in the Gourmia Recipe Book.
Air fryers perform similar to ovens, refer to oven instructions on item packaging or recipe.
Snacks that can be prepared in an oven can also be prepared in the air fryer.
Smaller ingredients usually require a slightly shorter cook time than larger ingredients.
Turning or tossing food halfway through cook time will deliver evenly browned and crispy results. (See Turn Reminder).
Add 1 tablespoon of oil to fresh potatoes for a crispy result. Air fry the ingredients within a few minutes after adding the oil.
Do not prepare foods that will produce a large amount of grease in the air fryer.
Place a baking pan or an oven-safe dish or pan in the Basket to bake a cake or quiche or to air fry fragile or filled ingredients.

CLEANING & MAINTENANCE

NEVER immerse cord, plug, or air fryer in water or any other liquid.

Do not use metal kitchen utensils or abrasive cleaning material to clean the Basket and Crisper Tray, as this may damage the non-stick coating.

Clean the air fryer after every use.
Remove the plug from the outlet.
Let the air fryer cool down completely. Remove the Basket from the air fryer to cool it down quicker.
Clean the Basket and Crisper Tray in the dishwasher's top rack only or with hot water, dish soap, and a non-abrasive sponge.
If residue is stuck to the bottom of the Basket, fill it with hot water and dish soap and let it soak.
Wipe the outside of the air fryer with a moist cloth.
Clean the inside of the air fryer with hot water, dish soap and a cleaning brush to remove any food residue.
Ensure the air fryer is completely dry before using.

STORAGE

Unplug the appliance and let it cool down.
Make sure all parts are clean and dry.
Store the appliance in a clean and dry place.

ENVIRONMENT
Do not throw away the appliance with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment.

TROUBLESHOOTING

PROBLEM	POSSIBLE CAUSE	SOLUTION
The air fryer does not work.	The air fryer is not plugged in.	Plug the main plug into a grounded wall socket.
	You have not set the timer.	Tap the timer icon to set the required cook time to turn on the air fryer.
	The Basket is not put into the air fryer properly.	Slide the Basket into the air fryer properly.
The ingredients did not cook.	There are too many ingredients in the Basket.	Put smaller batches of ingredients in the pan. Smaller batches are fried more evenly.
	The set temperature is too low.	Tap + and - Icons to set the required temperature setting.
	The cook time is too short.	Tap + and - Icons to set the required cook time.
The ingredients are fried unevenly in the air fryer.	Certain types of ingredients need to be shaken halfway through the cook time.	Ingredients that lie on top of or across each other (e.g.fries) need to be shaken halfway through the cook time. (See Turn Reminder)
Fried snacks are not crispy when they come out of the air fryer.	You used a type of snack meant to be cooked in a traditional deep fryer.	Use oven snacks or lightly brush some oil onto the snacks for a crispier result.
I cannot slide the Basket into the air fryer properly.	The Basket is overfilled.	Do not fill the Basket beyond max line.
White smoke comes out of the air fryer.	You are preparing greasy ingredients.	When you fry greasy ingredients in the air fryer, a large amount of oil will leak into the Basket. The oil produces white smoke and the Basket may heat up more than usual. This does not affect the air fryer or the end result.
White smoke comes out of the air fryer.	The Basket still contains grease residue from previous use.	White smoke is caused by grease heating up in the pan. Make sure you clean the Basket properly after each use.
Fresh fries are fried unevenly in the air fryer.	Quality potatoes will give an even cook.	Use fresh potatoes and make sure they stay firm during frying.
Fresh fries are fried unevenly in the air fryer.	Potatoes are too starchy.	Rinse the potato sticks properly and dry to remove starch from the outside of the sticks.
Fresh fries are not crispy when they come out of the air fryer.	The crispiness of the fries depends on the amount of oil and water in the fries.	Make sure you dry the potato sticks properly before you add the oil. Cut the potato sticks smaller for a crispier result. Add slightly more oil for a crispier result.

IMPORTANT SAFEGUARDS

Read all instructions before using the electric appliance. The following basic precautions should always be followed:

This appliance is not intended for use by persons (including children younger than 8) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have supervision.
Check if the voltage indicated on the appliance corresponds to the local main voltage before you connect the appliance.
Do not use the appliance if the plug, the main cord or the appliance itself is damaged. Always make sure that the plug is inserted properly into a wall outlet.
Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or adjustment.
Close supervision is necessary when any appliance is used near children. Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be done by children unless they are older than 8 and supervised.
Do not let the cord hang over the edge of the table or counter or touch hot surfaces.
To protect against electric shock, do not immerse cord, plugs, or appliance in water or other liquid. Do not plug in the appliance or operate the control panel with wet hands.
Never connect this appliance to an external timer switch or separate remote-control system in order to avoid a hazardous situation. To disconnect, turn off the appliance, then remove plug from wall outlet.
Do not place the appliance on or near combustible materials such as a tablecloth or curtain. The accessible surfaces may become hot during use. Do not place on or near a hot gas or electric burner, or in a heated oven.
Do not place the appliance against a wall or against other appliances. Leave at least 4 inches of free space on the back and sides and 4 inches of free space above the appliance. Do not place anything on top of the appliance.
Do not use the appliance for any other purpose than described in this manual. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
Do not let the appliance operate unattended. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
Do not use outdoors.
Do not touch the hot surfaces; use handle. During air frying, hot steam is released through the air outlet openings. Keep your hands and face at a safe distance from the steam and from the air outlet openings. Also be careful of hot steam and air when you remove the basket from the appliance.
After using the appliance, avoid contact with the hot metal inside. Unplug from outlet when not in use and before cleaning. Allow the appliance to cool before cleaning.
Immediately unplug the appliance if you see dark smoke coming out of the appliance. Wait for the smoke emission to stop before you remove the basket from the appliance.
For household use only.

CORD AND PLUG SAFETY

A short power-supply cord is provided to reduce risk of becoming entangled in or tripping over a longer cord.
Extension cords may be used if care is exercised in their use.
If an extension cord is used:
1. The marked electrical rating of the extension cord should be at least equal to the electrical rating of the appliance; and
2. The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.

ELECTRICAL POLARIZED PLUG
shock hazard This unit has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, the plug is intended to be used by inserting it into the electrical outlet only one way. If the plug does not fit securely into the outlet, reverse the plug and re-insert. If it still does not fit, contact a qualified electrician for assistance. Do not modify the plug in any way.

Power:

120V 60HZ 1700W

SAVE THESE INSTRUCTIONS

FOR CUSTOMER SERVICE
QUESTIONS OR COMMENTS
VISIT WWW.GOURMIA.COM
EMAIL INFO@GOURMIA.COM
OR CALL 888.552.0033
MON-THU 9:00AM TO 6:00PM ET
AND FRI 9:00AM TO 3:00PM ET
LANGUAGES SUPPORTED: ENGLISH, SPANISH
