Dash DSIM100 - Shaved Ice Maker Manual & Recipes

PARTS & FEATURES

SETTING UP YOUR DASH shaved ice maker

NOTE:
Please clean your Dash Shaved Ice Maker before first using. Refer to pages 10-14 for instructions and details.

1. Place the Base on a stable and dry surface.

2. Install the Motor Unit on the Base.

3. Align and insert the Exterior Bowl onto the assembled Motor Unit and Base. The two notches on the side of the Exterior Bowl should fit into the two notches on the inside of the Motor Unit.


Lastly, plug in the Power Cord.

USING YOUR DASH shaved ice maker

1. Place ice cubes inside the Interior Bowl. The bowl should be filled to the top level. If the ice has been in the freezer for a long time, it may be too hard and may need to rest at room temperature for a few minutes before shaving. The machine will then produce a fluffier snow.

2. Place the Clear Lid on top of the Interior Bowl, locking it into place by aligning the fin-shaped notch on the lid with the corresponding notch on the Motor Unit.

3. Place an empty bowl on the base of the unit. This bowl will be used to collect the shaved ice.

   NOTE: At this time, you may want to insert the Ice Guard, which helps the ice shavings go more directly into the bowl. Simply slide the Ice Guard into place so that the notches on the Ice Guard and the Exterior Bowl align. (See red arrows on the left for reference)
4. To activate the machine, turn the lid counter clockwise until the fin-shaped notch activates the Safety Switch. To stop the shaving process, turn the lid clockwise to deactivate the Safety Switch. For optimal results, hold onto the lid during the shaving process to ensure all ice is shaved.


Unplug the Dash Shaved Ice Maker after each use.

PARTS & FEATURES

Disassembly & Assembly

Always ensure that the appliance is switched off and that it is not plugged into an electrical outlet before you disassemble or assemble the Dash Shaved Ice Maker.

TO disassemble:

1. First make sure the unit is unplugged, then remove the Dial from the Interior Bowl by turning counter clockwise.

2. Remove the Interior Bowl.

3. Remove the Gear Hoop and Ice Guard from the Exterior Bowl, then remove the Exterior Bowl.


The Shaving Blade in your Shaved Ice Maker is sharp! Handle with extreme care. Do not put hands near the Shaving Blade whilst the Shaved Ice Maker is connected to the power outlet.

4. Lift up the Motor Unit to release from the Base.

5. The Dash Shaved Ice Maker is now disassembled.


To assemble the Shaved Ice Maker, simply follow the steps in reverse order.

CLEANING & MAINTENANCE

• Disassemble the appliance before cleaning.
• When cleaning, exercise caution and avoid touching the Shaving Blade to prevent injury.
• DO NOT submerge the Motor Unit in water or other liquids. Wipe with a damp cloth before drying thoroughly.
• Avoid using abrasive cleaning agents when cleaning the appliance.
• All other parts may be washed in warm water with mild soap and rinsed. All parts of the Dash Shaved Ice Maker are NOT dishwasher safe.
• Dry all parts thoroughly before storing.

Directions:

1. Assemble your Dash Shaved Ice Maker.
2. Blend or purée your fruit in a food processor or blender. Pour the purée into a saucepan and add the rest of your ingredients and sugar or sweetener. Cook over medium heat, stirring occasionally, until boiling. Turn the heat down to low and continue to simmer for 5 minutes, before removing from the heat. Let cool, then strain if necessary.
3. Shave your ice using the Dash Shaved Ice Maker. Make sure that the syrup is chilled before pouring over your shaved ice. Pour a tablespoon or two of syrup over your shaved ice and enjoy!

MATCHA SHAVED ICE

Ingredients:
2 cups warm water
2 tsp Matcha green tea powder
¼ cup milk
2 tbsp condensed milk

Directions:
Whisk together Matcha & water in a bowl. Pour into ice cube trays and freeze overnight. Pour the milk into a bowl and shave the Matcha ice cubes over the milk.

Drizzle condensed milk over the shaved Matcha ice. Enjoy!

COLD BREW SHAVED ICE

Ingredients:
2 cups cold brew coffee
2 tbsp condensed milk

Directions:
Pour your cold brew coffee into an ice cube tray, or two. Freeze overnight. Shave your cold brew coffee ice cubes. Drizzle the condensed milk over your cold brew shaved ice.

RAINBOW SHAVED ICE

Ingredients:
2 tbsp strawberry syrup (see recipe in chart)
2 tbsp pineapple-mango syrup (see recipe in chart)
2 tbsp blueberry syrup (see recipe in chart)

Directions:
Shave your ice. Next, pour the strawberry syrup in a straight line across the shaved ice, leaving room for the rest of the lines of syrup. Pour your pineapple mango syrup in a line next to the strawberry syrup. Finally, pour your blueberry syrup in a straight line across the rest of the plain shaved ice.

CUSTOMER SUPPORT

Dash values quality and workmanship and stands behind this product with our Feel Good Guarantee ™. To learn more about our commitment to quality, visit bydash.com/feelgood.

Our customer support teams in the US and Canada are at your service Monday - Friday during the times below.
Contact us at 1 (800) 898-6970 or support@bydash.com

Hey Hawaii! You can reach our customer service team from 3AM to 3PM.
And also, Alaska, feel free to reach out from 5AM to 5PM.

REPAIRS

Risk of electric shock! The Dash Shaved Ice Maker is an electrical appliance.

Do not attempt to repair the appliance yourself under any circumstances.

Contact Customer Support regarding repairs to the appliance.

TECHNICAL SPECIFICATIONS

Voltage 120V ~ 60Hz

Power Rating 85W

Stock#: DSIM100_20171215_v10

IMPORTANT SAFEGUARDS

IMPORTANT SAFEGUARDS:PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

When using electrical appliances, basic safety precautions should be followed, including:

• Read all instructions
• When using electrical appliances, basic safety precautions should be followed, including:
• Read all instructions.
• Remove all bags and packaging from the appliance before use.
• Never leave appliance unattended when in use.
• Make sure the appliance is cleaned thoroughly before using.
• Do not use an appliance for other than its intended use. For household use only. Do not use outdoors.
• To prevent electric shock, do not submerge the cord, plugs, motor unit, or any electrical parts in water or other liquids.
• Do not operate the machine without ice. Do not use the appliance to shave or crush substances other than ice.
• Do not place your fingers in the appliance, as the blades are sharp and may cause injury.
• Do not attempt to sharpen the blades.
• In order to prevent the Dash Shaved Ice Maker from overheating, do not operate this appliance for more than 2 minutes continuously. Allow the appliance to rest in between uses.
• Do not operate this appliance with a damaged cord, damaged plug, after the appliance malfunctions, is dropped, or damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or adjustment.
• For maintenance other than cleaning, please contact StoreBound directly at 1-800-898-6970 from 9AM–9PM EST Monday-Friday or by email at support@bydash.com.
• Do not place the appliance on or near a hot gas burner, hot electric burner, or in a heated oven.
• Refrain from using attachments that are not recommended by the appliance manufacturer, as this may result in fire, electric shock, or personal injury.
• Do not let the cord touch hot surfaces, or hang over the edges of tables or counters.
• This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience or knowledge, if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• This appliance is not a toy. Do not let children use this appliance. Close supervision is necessary when any kitchen appliance is used by or near children.
• Always be sure to unplug the appliance from the outlet prior to moving, cleaning, storage, and when not in use.
• StoreBound shall not accept liability for damages caused by improper use of the appliance.
• Improper use of the appliance can result in property damage or even in personal injury.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not completely fit in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
• A short power supply cord is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.
