Tascam SX-1LE Brochure & Specs

40-input, 32 x 8 digital mixer with 100mm
motorized, touch-sensitive faders and dynamic
automation of all parameters
48kHz, 24-bit, 16-channel hard disk recorder
Complete 5.1 surround mixing capabilities:
16-track recording...plus 6 tracks for mixing
16 premium mic preamps with phantom power
Built-in CD-RW drive for creating audio CDs, data
backup, archiving and importing sounds
Highly integrated and intuitive waveform, MIDI,
and automation data editing
Onboard LCD screen displays editing and
automation information including waveforms
XVGA output to optional monitor
128-track MIDI sequencer with advanced editing
modes available on the fl y, standard and step
record modes and highly accurate timing
16 balanced XLR inputs, 16 TRS line inputs,
16 TRS inserts, onboard speaker switcher,
8 channels of ADAT ® digital interface, 2 stereo
S/PDIF inputs (with sample rate conversion) and
outputs, 2 MIDI inputs (for MIDI controllers and
MTC), 4 MIDI outputs, separate studio/control
room monitoring and more
MTC synchronization and LTC chase
Expansion slots for 24 more channels of AES/EBU,
TDIF, ADAT Optical digital I/O or extra analog I/O
SX- LE Digital Production Environment
The only digital workstation in its price range with
professional features like
moving faders, full dynamic automation, simultane-
ous 16-track, 24-bit hard disk recording, and built-in
128-track MIDI sequencer.
40-channel 16-channel
automated 24-bit / 48kHz
mixer HD recorder
mm touch-sensitive
128-channel DAW-style editing
MIDI
CD-RW recorder
sequencer
