TASCAM
TEAC Professional Division
SX-1
Digital Production Environment
SX-1 Version 1.50
Sony P2 Protocol Documentation
This manual describes the changes and additions to the Sony P2 support for the SX-1OS
V1.50 software. See also the V1.10 release note for other issues that were addressed after
V1.00

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tascam SX-1

Summary of Contents for Tascam SX-1

  • Page 1 TEAC Professional Division SX-1 Digital Production Environment SX-1 Version 1.50 Sony P2 Protocol Documentation This manual describes the changes and additions to the Sony P2 support for the SX-1OS V1.50 software. See also the V1.10 release note for other issues that were addressed after...
  • Page 2 Mixdown mode, any tracks Rec-armed over P2 will be turned off until MixDown mode is exited. This is for safety and to make the behavior similar to the SX-1’s internal recorder. If the resulting mix is to be recorded to the external P2 device, another pass is required after...
  • Page 3 Make sure that the SX-1 HDR entry has CHASE=LTC Master set. It is still possible to control the SX-1 if it is set to chase LTC or MTC, in which case motion control commands will be translated and sent to the designated timecode master, if one is in the machine control list, and just EDIT ON/OFF &...
  • Page 4 Sony P2 Specifications. Timing: The SX-1 will reply to incoming commands within 9ms. The time required to actually execute the command and update the STATUS MAP will vary and may be much longer. See note *6 for details about deferred commands.

  • Page 5: Transport Page

    EDIT PRESET SENSE TIMER MODE SENSE Unsuported Commands Notes: *1 Command is acknowledged, but no action is taken. *2 The SX-1 can selectively reply to this command, set in the LCD Preferences screen, TRANSPORT page. F01A TASCAM HDR Series (Default) 6003...
  • Page 6 All other frame rates have no effect on the reply data, e.g. 29.97 and 30 frame rates, drop or non-drop. *3 If the SX-1 is currently set to emulate the Sony BVU950, the REC command is treated the same as EDIT ON (20 64), and the HDR will punch in on rec-arm’ed tracks. Otherwise this command is acknowledged but ignored.
  • Page 7 P2 EDIT FIELD: If the SX-1 is also receiving a valid VIDEO or TTL signal at the VIDEO SYNC IN port, this control can be used to specify which field of the frame that the command will be executed in.
  • Page 8 If there is no valid VIDEO or TTL signal being received by the SX-1, then the command will be executed during field 1 of the calculated frame. The frame boundaries are assumed to line-up with the first sample at 00:00:00:00...
  • Page 9 CH1-CH16 bits are ignored. HDR tracks 3-16 that are currently in record will not be cleared. If the device type = TASCAM or SONY 3324S then A1 and A2 status is ignored and the bits CH1-CH16 are read and applied to HDR Channel 1 to 16.
  • Page 10 This command is a deferred command whose execution may be delayed to occur on a subsequent frame or video field boundary, see Note *5 for details. *12 NAK DATA: The SX-1 returns the data value 01 = UNDEFINED COMMAND for commands that it does not recognize. If the received command has an incorrect checksum, the data value is 04 = CHECKSUM ERROR.
  • Page 11 DATA 1/BIT 7: STANDBY ON This bit is always set. DATA 1/BIT 5: STOP This bit is set whenever the SX-1 HDR is stopped, except when in shuttle mode with speed=0. DATA 1/BIT 3: REW This bit is set when the SX-1 HDR is rewinding.
  • Page 12 Program Play (21 38 or 21 39): Bit 3 DATA 2/BIT 2: DIRECTION This bit is set if the SX-1 HDR is shuttling in reverse. It is not cleared until a command is received that starts the transport moving forward again.
  • Page 13 This bit is set when the SX-1 HDR is recording or rehearsing. DATA 4/BIT 0: CUE UP REQUESTED This bit is set when the SX-1 HDR starts to locate, and clears when Data 2/Bit 0 is set. DATA 5/BIT 6: INSERT This bit is set whenever there is one or more HDR audio tracks are armed for recording.
  • Page 14 To fix this problem: Add washers under the SX-1 DSUB connector's nuts (1 or 2 as required) so that the cable's screws can reach the SX-1 connector. The appropriate washer is designed for DSUB: Part number :D-SUB WASHER HW-C050MN00) （92603306-00...
  • Page 15 Appendix TASCAM SX-1 auto detected P2 devices. No. Type Name Recs 0x0001 BVH-2000 0x0010 BVH-2000 0x0011 BVH-2000 0x0014 BVH-2000P 0x0015 BVH-2000P 0x0018 BVH-2180 0x0019 BVH-2180 0x001c BVH-2180P 0x001d BVH-2180P 0x0020 BVH-2500 0x0024 BVH-2500P 0x0030 BVH-2700 0x0040 BVH-2800 0x0044 BVH-2800P 0x0048...
  • Page 16 TASCAM SX-1 auto detected P2 devices. Type Name Recs 0xa011 LVA-3000 0xa020 CDP-3100 0xa030 PCM-9000 0xa040 BKDE-550 0xa04d GalVirVTR 0xa050 Doremi V1 0xa070 MAV-555 0xa080 AG-7750 0xa081 AG-7650 0xa082 DS-850 0xa086 AG-8700 0xa0a1 SM Atom 0xa0f0 HDL-5800 0xb000 DVW-A500 0xb001...
