Marshall Stanmore II Bluetooth

LEGAL & TRADEMARK NOTICE

• Design of device and packaging are intellectual properties of Zound Industries International AB and Marshall Amplification Plc. © All Rights Reserved. Zound Industries International AB is hereinafter referred to as "Zound Industries" or "manufacturer".
• MARSHALL, Marshall Amps, their respective logos, "Marshall" and "Marshall" trade dress are trademarks and intellectual property of Marshall Amplification Plc and may not be used without permission. Permission granted to Zound Industries.
• Qualcomm aptX is a product of Qualcomm Technologies International, Ltd. Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries, used with permission. aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the United States and other countries, used with permission.
• The Bluetooth ® wordmark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Zound Industries is under license.
• Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
• Google Play and the Google Play logo are trademarks of Google LLC.
• All other trademarks are the property of their respective owners and may not be used without permission.
• For more legal information related to this product and to its use in your specific region, and for more detailed information about Zound Industries and partner & license information, please visit the website: www.marshallheadphones.com. The user is recommended to visit the website regularly for up-to-date information.

Zound Industries International AB, Centralplan 15, 111 20 Stockholm, Sweden

BOX CONTENTS

001. MARSHALL STANMORE II WIRELESS HOME Bluetooth^® SPEAKER
002. QUICK START GUIDE
003. IMPORTANT SAFETY INSTRUCTIONS
004. MAINS LEAD

GENERAL DESCRIPTION

001. AUX INPUT FOR 3.5 mm JACK
002. SOURCE INDICATORS
003. SOURCE BUTTON
004. VOLUME KNOB
005. BASS KNOB
006. TREBLE KNOB
007. PLAY/PAUSE BUTTON
008. POWER LEVER

009. BASS PORT
010. BACKPLATE
011. RCA INPUT (LEFT AND RIGHT)
012. MAINS INPUT
013. MAINS LEAD

PLUGGING IN THE STANMORE II

ALWAYS UNPLUG THE MAINS LEAD FROM THE WALL SOCKET BEFORE DISCONNECTING IT FROM THE SPEAKER.

ALWAYS ENSURE THAT THE MAINS LEAD, POWER JACK AND SPEAKER ARE COMPATIBLE WITH YOUR MAINS SUPPLY AND WALL SOCKET.

001. CONNECT THE MAINS LEAD INTO THE MAINS INPUT ON THE SPEAKER.
002. CONNECT THE POWER JACK TO THE WALL SOCKET.

TURNING THE STANMORE II ON/OFF

001. ON: PULL AND HOLD THE POWER LEVER TOWARDS THE FRONT OF THE SPEAKER UNTIL THE POWER ON SOUND PLAYS AND THE INDICATORS LIGHT UP.

002. OFF: PULL AND HOLD THE POWER LEVER TOWARDS THE FRONT OF THE SPEAKER UNTIL THE POWER OFF SOUND PLAYS AND ALL INDICATORS TURN OFF.

SETTING UP THE STANMORE II

CONFIGURE THE SPEAKER WITH THE MARSHALL BLUETOOTH^® APP TO GET THE MOST OUT OF IT. THE APP IS AVAILABLE FROM THE APP STORE AND GOOGLE PLAY.

001. DOWNLOAD THE MARSHALL BLUETOOTH^® APP AND FOLLOW THE IN-APP INSTRUCTIONS.

SELECTING AUDIO SOURCE

MAKE SURE THAT THE VOLUME IS SET TO LOW ON BOTH THE SPEAKER AND THE AUDIO SOURCE BEFORE USING THE SPEAKER.

THERE ARE MANY WAYS TO CONNECT TO YOUR STANMORE II, EITHER WIRELESSLY OR BY CABLE.

• - WIRELESS Bluetooth CONNECTION
• AUX - 3.5 mm STEREO JACK
• RCA - DOUBLE RCA (LEFT AND RIGHT) JACKS

001. PUSH THE SOURCE BUTTON TO TOGGLE BETWEEN Bluetooth, AUX AND RCA AUDIO SOURCE.
002. A LIT INDICATOR SHOWS WHICH SOURCE IS SELECTED.

THE SOURCE CAN ALSO BE SELECTED FROM THE MARSHALL BLUETOOTH® APP.

CONNECTING VIA Bluetooth (PAIRING)

001. SELECT Bluetooth AS THE INPUT. PUSHING THE SOURCE BUTTON TOGGLES THE INPUT SOURCES.
002. PUSH AND HOLD THE SOURCE BUTTON FOR 2 SECONDS. THE Bluetooth INDICATOR STARTS TO BLINK.
003. ENABLE Bluetooth ON YOUR DEVICE (SMARTPHONE, TABLET, COMPUTER).
004. SELECT STANMORE II FROM THE Bluetooth LIST AND ACCEPT PAIRING. THE Bluetooth INDICATOR ON THE SPEAKER STOPS BLINKING AND REMAINS LIT WHEN THE UNITS ARE CONNECTED.

STANMORE II CAN BE CONNECTED TO TWO Bluetooth DEVICES AT THE SAME TIME. PLAYING A CONNECTED Bluetooth DEVICE WILL MAKE IT THE SELECTED AUDIO SOURCE, PAUSING ANY PREVIOUSLY PLAYED AUDIO ON THE SECOND DEVICE.

CONNECTING VIA AUX INPUT

NOTE: AUDIO LEADS ARE NOT INCLUDED IN THE STANMORE II.

001. CONNECT A 3.5 mm STEREO JACK TO THE INPUT LABELLED AUX ON THE TOP OF THE SPEAKER.
002. CONNECT THE OTHER END OF THE LEAD TO THE AUDIO OUTPUT ON YOUR AUDIO SOURCE.
003. SELECT AUX AS THE INPUT. PUSHING THE SOURCE BUTTON TOGGLES THE INPUT SOURCES.

CONNECTING VIA RCA INPUT

NOTE: A CONNECTED TURNTABLE MUST BE EQUIPPED WITH A RIAA AMPLIFIER OR A SEPARATE PREAMPLIFIER.

001. CONNECT A LEAD WITH RCA JACKS TO THE INPUTS LABELLED RCA ON THE BACK OF THE SPEAKER.
002. CONNECT THE OTHER END OF THE LEAD TO THE OUTPUT ON YOUR AUDIO SOURCE.
003. SELECT RCA AS THE INPUT. PUSHING THE SOURCE BUTTON TOGGLES THE INPUT SOURCES.

ADJUSTING THE VOLUME/BASS/TREBLE

NOTE: THE AUDIO CAN ALSO BE ADJUSTED FROM THE MARSHALL BLUETOOTH ® APP.

THE STANMORE II INCLUDES THREE CONTROLS FOR ADJUSTING THE AUDIO.

001. VOLUME KNOB
002. BASS KNOB
003. TREBLE KNOB

PLAY/PAUSE CONTROL

THE STANMORE II HAS A PLAY/PAUSE BUTTON TO CONTROL THE MUSIC WHEN PLAYING VIA Bluetooth.

001. SINGLE-CLICK TO EITHER PLAY OR PAUSE.
002. DOUBLE-CLICK TO SKIP FORWARD.
003. TRIPLE-CLICK TO SKIP BACK.

NOTE: PLAYBACK CAN ALSO BE CONTROLLED FROM THE MARSHALL BLUETOOTH ® APP.

COUPLE SPEAKERS

TWO ACTON II, STANMORE II, OR WOBURN II SPEAKERS CAN BE COUPLED TO ACT AS ONE SOUND SYSTEM.

NOTE THAT CERTAIN HARDWARE COMPONENTS VARY BETWEEN MODELS, AND MAY CAUSE LIMITATIONS ON THE COUPLING SUPPORT. THE TABLE BELOW DISPLAYS THE COMPATIBILITY BETWEEN STANMORE II AND OTHER MODELS.

THE SPEAKER MODEL IS STATED ON THE BACK OF THE SPEAKER.

THERE ARE TWO COUPLNG MODES TO CHOOSE FROM:

• AMBIENT MODE - TWO SPEAKERS PLAY THE SAME AUDIO SYNCHRONISED. EACH SPEAKER PLAYS BOTH THE LEFT AND RIGHT CHANNELS. CHOOSE THIS MODE IF YOUR SPEAKERS ARE PLACED AT DIFFERENT HEIGHTS, DIRECTION OR AREAS OF THE ROOM.

  AMBIENT MODE
• STEREO MODE - TWO SPEAKERS OF THE SAME SIZE ARE COUPLED AS A STEREO PAIR. WITH ONE SPEAKER THE LEFT CHANNEL AND THE OTHER THE RIGHT.

  STEREO MODE

  CHOOSE THIS MODE IF THE SPEAKERS ARE PLACED AT THE SAME HEIGHT, EQUAL DISTANCE AND FACING THE SAME DIRECTION.

001. TO COUPLE TWO SPEAKERS, OPEN THE MARSHALL BLUETOOTH® APP AND CONNECT TO YOUR SPEAKERS.
002. GO TO COUPLE SPEAKERS AND FOLLOW THE IN-APP INSTRUCTION.

NOTE: MAKE SURE YOUR AUDIO DEVICE IS ONLY CONNECTED VIA Bluetooth TO ONE SPEAKER WHEN PLAYING ON COUPLED SPEAKERS.

STANDBY MODE

NOTE: THE SPEAKER CAN ALSO BE WOKEN FROM THE MARSHALL BLUETOOTH ® APP.

IF THE STANMORE II IS LEFT UNUSED FOR 20 MINUTES THE SPEAKER GOES INTO STANDBY TO SAVE ENERGY. IN THIS MODE ALL INDICATORS ARE OFF.

001. INTERACT WITH ANY BUTTON OR KNOB ON THE TOP PANEL TO WAKE THE SPEAKER UP FROM STANDBY MODE.

TECHNICAL INFORMATION

ACOUSTIC SPECIFICATION

• STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• DIGITAL CLASS D AMPLIFIERS: 2 x 15 W + 1 x 50 W
• TWEETERS: 2 x ¾" dome tweeters
• WOOFER: 1 x 5¼" woofer
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 50–20,000 Hz ±6 dB
• MAXIMUM SOUND PRESSURE LEVEL: 101 dB SPL @ 1 m

CONNECTIVITY

• Bluetooth^®: Bluetooth 5.0 with Qualcomm^® aptX™
• AUX: 3.5 mm stereo jack
• RCA: RCA (left and right)

TECHNICAL INFORMATION

• MAINS INPUT VOLTAGE: 100–240 VAC
• MAINS FREQUENCY: 50–60 Hz
• SIZE: 350 x 195 x 185 mm
• WEIGHT: 4.65 kg

NOTE: THE FRONT OF THE SPEAKER IS NOT REMOVABLE. THIS ILLUSTRATION INTENDS TO SHOW THE INTERNAL SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE THE FRET FOR RISK OF DAMAGING YOUR SPEAKER.

TROUBLESHOOTING

NOTES:
A BLUETOOTH DEVICE COULD CAUSE AUDIO-RELATED OR TECHNICAL FAULTS, DEPENDING ON USE, IN THE FOLLOWING CASES:

• WHEN SOME PART OF THE BODY IS IN CONTACT WITH THE RECEIVING/TRANSMITTING SYSTEM FOR THE BLUETOOTH DEVICE OR THE STANMORE II.
• ELECTRICAL VARIATIONS DUE TO OBSTACLES IN THE FORM OF WALLS, CORNERS, ETC.
• EXPOSURE TO ELECTRICAL DISRUPTIONS FROM DEVICES WITHIN THE SAME FREQUENCY BAND, FOR EXAMPLE MEDICAL EQUIPMENT, MICROWAVE OVENS AND WIRELESS NETWORKS.

THIS WIRELESS DEVICE MAY CAUSE ELECTRICAL DISRUPTIONS DURING USE.
