DO KR01 - Smartwatch Manual
Know the Device
![DO - KR01 - Touch key functions Overview Touch key functions Overview]()
Touch key functions:
- Tap the Touch key to switch between menu pages.
- Tap and hold the Touch key to confirm.
Power On/Off
Note: the Bracelet must be activated through charging before the first use.
- Connect to the charging dock.
- Connect the USB end of the charging cable to the charger.
- When the charger is plugged in, the charging icon will appear on the screen and the screen will be on for 5 seconds. When the screen is off, tap the Touch key, the charging icon will be displayed again.
Charging and turning on
![]()
Functions
KR01 supports IP68 waterproof, 14 exercise modes, up to 10 alarms, and features such as cloud watch face, heart rate measurement and sleep monitoring, etc.
Please turn on the app to access the user guide, operating instructions and FAQ.
Maintenance
Below are three recommendations on wearing and maintenance:
- Keep the device clean;
- Keep the device dry;
- Do not wear the device too tight.
- Do not use household cleaners to clean the device. Use soap-free cleaners instead.
- For stains that are difficult to remove, it is recommended to scrub with alcohol.
Waterproof performance: the device is not suitable for diving, swimming in the sea or sauna. It is suitable for swimming pool, shower (cold water) and swimming in shallows.
Safety
- To prevent device failure, fire and explosion, never place the device or its accessories in any extremely-high-temperature or extremely-low-temperature area.
- To prevent device damage, accessory damage and device failure, always protect the device against strong impact or shock.
- Do not disassemble or modify the device or its accessories without authorization. Please contact our after-sales service in case of a device error
Specification
Model | KR01 |
Battery capacity | 90mAh |
Charging Time | about 2 hours |
Waterproof | IP68 |
Operating Temperature | 0°C-60°C |
Product Frequency | 2402-2480MHz |
Screen Type | 0.96 " TFT-LCD |
Charging Voltage | 5V±0.2V |
Battery Life | 7 Days |
Weight of Product | 18.1g |
Bluetooth Version | BLE4.2 |
Max. transmission Power Consumption | 4dBm |
Scan the QR code for more function information
![]()
