Introduction

Thanks for choosing MOVO!

The VXR10 PRO is an upgraded super-cardioid condenser microphone that delivers lower noise and higher sensitivity sound on your smartphones, tablets, DSLRs, consumer camcorder, PCs and more.

Due to its plug and play operation and no battery required design, the VXR10 PRO is a perfect audio solution for mobile journalists, vloggers and video hobbyists.

The VXR10 PRO features a compact and rugged aluminium body, while it will not be a heavy burden when recording.

The 3.5mm headphone output lets users monitor and playback audio with compatible apps, so you can ensure the integrity of audio.

Included detachable Rycote Lyre shock mount provides^{® ®} a reliable and solid construction, effectively eliminating noise from vibrations and camera handling.

Features

Compatible with smartphones, tablets, DSLRs, consumer camcorder, PCs and more
Super-cardioid condenser shotgun microphone
Improved sensitivity and signal to noise ratio
Plug and play operation
Durable metal construction
3.5mm headphone output
Rycote Lyre shock mount and furry windshield included ® ®

Specifications

Transducer:	Electret Condenser
Polar Pattern:	Super-cardioid
Frequency Response:	20Hz-18kHz
Sensitivity:	-36dB±3dB (0dB=1V/Pa, 1kHz)
Signal to Noise Ratio:	78dB
Plug:	3.5mm TRRS line-out
Plug:	3.5mm TRS headphone output
Dimensions:	Ф26x100 (Ф1x3.9")
Net Weight:	60g (2.1oz)

Product Structure

Furry windscreen
VXR10 PRO microphone
Audio output jack
3.5mm headphone output
Rycote Lyre shock mount ® ®
3.5mm TRRS to TRS output cable
3.5mm TRRS to TRRS output cable

What's difference

3.5mm TRRS to TRS output cable
- For cameras, camcorders, audio recorders and other audio/video recording devices with audio monitoring jack.
3.5mm TRRS to TRRS output cable
- For Smartphone, tablet or Ma

Attach the microphone to Smartphone or tablet

Connect 3.5mm TRRS to TRRS output cable into your smartphone, tablet.
Open the audio or video recording app and start recording.
When finishing, plug the 3.5mm headphone output and playback the previous audio you recorded.

Attach the microphone to cameras, camcorders, audio recorders and other audio or video recording devices

Turn counter-clockwise to loosen the screw.
Slide the microphone onto the camera's hot shoe.
Turn clockwise to tighten the screw to stabilize on the shoe mount.

Plug the 3.5 mm TRS connector into the audio output jack of your device.

Specifications

Specifications - Example 1

FREQUENCY RESPONSE

Specifications - Example 2

Troubleshooting

If you have any problem using the VXR10 PRO components, use the following checklist.

Problem	Solution
The microphone can't work	Make sure that using the correct audio connector. For smartphone, tablet or Mac, using 3.5mm TRRS to TRRS output cable. For others devices, using 3.5mm TRRS to TRS output cable cable.
Too much ambience noise is being picked up	Make sure that the microphone is as close as possible to the subject. A certain amount of ambient noise is unavoidable in loud environments.

HAPPY? LET US KNOW!

We love to hear from customers!
Share your experience with others by reviewing your product on Amazon. Scan the QR code below or visit:
amazon.com/review/review-your-purchases#:

Act Now!
This product includes a 1 year limited warranty. If you register the product within 30 days of purchase, you'll receive an additional 1-year warranty extension for a total of two years of protection.
To register your product and for full details on the warranty, visit www.movophoto.com/warranty or scan QR code:
