All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.
Foreword Notes on information security The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online, are equipped with security functions that support the secure operation of plants, systems, machines and networks. Despite the security functions, the creation, implementation and constant updating of a holistic security concept for the operation are necessary to protect the respective plant, system, machine and networks against cyber threats.
Intended use The VOS2000-0822 lens is intended for use in industry, specifically for use in machine vision in manufacturing and production processes. It serves here as a lens system for inspection tasks, measurement and defect detection.
This symbol indicates information that helps in handling the product. Safety instructions The following safety instructions must be observed when handling the VOS2000-0822 lens. Application conditions • Never leave the lens in the sun or point it directly at the sun. This can cause smoke or fires.
Product overview Product overview With its robust and easy-to-mount design, the VOS2000-0822 C-mount lens is ideal for use in harsh industrial automation environments. In addition to being straightforward to adjust, the focus and fixed aperture can be locked easily and precisely using compact screws. The broadband anti-reflection coating ranges from 420 nm to 1050 nm, while the vibration resistance facilitates reliable measurements in the...
Product overview Structure Fig. 2: VOS2000-0822 structure Number Part identification Filter thread Focusing ring Aperture ring Aperture scale C-mount connection Locking screw for the aperture ring Locking screw for the focusing ring "Beckhoff" ring VOS2000-0822 Version: 1.0...
0 ... 60 Storage temperature (°C) -10 ... 60 according to JISC60068-2-6 Freq. 10 - 150 [Hz], Test time: X,Y,X axis direction 20 cycles / 8 min total 160 min x 3 = 480 min. relative humidity 20 ... 70%, non-condensing non-condensing Version: 1.0 VOS2000-0822...
Page 13
Available spectral range (nm) 420 ... 1050 identical with the object distance according to DIN 1335:2003-12 identical with the double object field angle according to DIN 1335:2003-12 at a circle of confusion diameter of 0.04 mm at 550 nm VOS2000-0822 Version: 1.0...
Page 14
Image distance Distance of the object-side principal point i Interstitium to the flange surface ω object-side field angle OO' Distance of the axis points of object and image Note: directional routes are indicated by arrows with an arrowhead. Version: 1.0 VOS2000-0822...
For example, the lens can be additionally fixed for high vibration applications. ü A wrench is required. The recommended torque is 100 N * cm and the maximum torque is 150 N * cm. 1. Place the wrench on the edges of the "Beckhoff" ring. 2. To tighten the lens, turn the "Beckhoff" ring clockwise.
3. Turn the lens counterclockwise until it can be detached from the camera. Fig. 7: Remove lens 4. Attach the rear lens cap to the lens. ð The lens can now be stored or attached to another camera. Version: 1.0 VOS2000-0822...
To obtain a sharp image at a long working distance, turn the focusing ring in the direction of the "Far" label. Fig. 9: Turn focusing ring 4. Fix the focusing ring in the desired position by tightening the focusing ring locking screw with an M3 Allen key. ð The set focus is now fixed. VOS2000-0822 Version: 1.0...
2. To adjust the aperture, turn the aperture ring. If you turn the aperture ring clockwise as seen from the camera, the aperture becomes larger and the image brighter. If you turn counterclockwise, the aperture becomes smaller and the image darker. Version: 1.0 VOS2000-0822...
M35.5 filter thread of the lens. Fig. 12: Screw on filter Information loss The application of a filter is accompanied by a loss of information. Clean lens Clean the lens with a soft brush, a bellows or a lint-free cloth. VOS2000-0822 Version: 1.0...
Disposal Disposal Beckhoff Automation products are marketed exclusively in the corporate business. It is therefore not necessary to mark the products with the symbol of Annex 3 of the ElektroG. In accordance with the 2012/19/ EU "WEEE" directives, you can return used devices and accessories for professional disposal. The transport costs are borne by the sender.
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: https://www.beckhoff.com You will also find further documentation for Beckhoff components there.
