Superior Electric 9T92PVC2 Series Instructions Manual

Volt-pac variable transformer controller

Advertisement

Quick Links

INSTRUCTIONS
for
®
Volt-Pac
Variable Transformer Controller
9T92PVC2 Series
The following models are covered in this manual:
9T92PVC2-1, 9T92PVC2-2, 9T92PVC2-3
Revision D
Superior Electric reserves the right to make engineering changes on all its products. Such refinements may affect
information given in the instructions. Therefore, USE ONLY THE INSTRUCTIONS THAT ARE PACKED WITH THE
PRODUCT.
213709-213 Rev F

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9T92PVC2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Superior Electric 9T92PVC2 Series

  • Page 1 The following models are covered in this manual: 9T92PVC2-1, 9T92PVC2-2, 9T92PVC2-3 Revision D Superior Electric reserves the right to make engineering changes on all its products. Such refinements may affect information given in the instructions. Therefore, USE ONLY THE INSTRUCTIONS THAT ARE PACKED WITH THE PRODUCT.
  • Page 2 DESCRIPTION GENERAL The 9T92PVC2 series of Variable Transformer Controllers can be configured for one to three control channels. Each channel measures the output voltage from a variable transformer and controls the motor drive on the variable transformer to control the output voltage to a desired set point within a specified dead band. The unit can be programmed from an integral keypad or read and programmed remotely via a serial RS-232 port.
  • Page 3 SPECIFICATIONS CONFIGURATIONS Designed for Single Phase 120, 240, or 277 line to neutral Three Phase 208Y/120, 240Y/138, 380Y/220, 480Y/277 or 600Y/346 INPUT VOLTAGE SIGNALS Measurement Controlled 0 to 500 VAC Line - Neutral Instrument Power * 120 VAC @ 5 watts max *Instrument Power source also supplies motor voltage.
  • Page 4 OUTLINE...
  • Page 5 CONNECTIONS...
  • Page 6 CONTROL MODES AND FEATURES Set Point This is the value to which the unit controls the output of a variable transformer. To enter a set point, press the “D” key until the display says “A.”, on the left side, Enter a set point and then press “E”.
  • Page 7 SERIAL COMMUNICATION Serial interface is provided which can be used to remotely read and write the following: READ Voltage set point dead band control address Write set point dead band control address keypad lock toggle Set Point This is the value to which the unit controls the output of a variable transformer. To enter a set point, press the “D”...
  • Page 8 If a phase is in manual mode, its instantaneous voltage display will flash quickly. ASCII COMMUNICATIONS Communication with the 9T92PVC2 series Variable Transformer Controller is a simple ASCII protocol with defined commands and responses. Communication Parameters:...
  • Page 9 “F” is the single digit 5 or 6 representing powerline frequency of 50Hz or 60Hz. “Ø” is either the letter I, S or B causing the phases to be individually controlled (I), controlled from “A” phase (S) or controlled from “D” phase (B) respectively. ”S”...
  • Page 10 ® Power Conditioners STABILINE In addition, Superior Electric Manufacturer’s Representatives are available to provide prompt attention to customer needs. Call or fax for ordering and application information or for the address of the closest Manufacturer’s Representative, Authorized Distributor or Reseller.
