Chroma A190201 User Manual

3-way scanning box

Advertisement

Quick Links

3-Way Scanning Box
A190201/A190202
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A190201 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chroma A190201

  • Page 1 3-Way Scanning Box A190201/A190202 User’s Manual...
  • Page 3 3-Way Scanning Box A190201/A190202 User’s Manual Version 1.0 June 2013...
  • Page 4 The information in this document is subject to change without notice. Chroma ATE INC. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 5 All of Chroma’s instruments are warranted against defects in material and workmanship for a period of one year from date of shipment. Chroma agrees to repair or replace any assembly or component found to be defective, under normal use during this period. Chroma’s obligation under this warranty is limited solely to repairing any such instrument, which in Chroma’s sole...
  • Page 6 Material Contents Declaration The recycling label shown on the product indicates the Hazardous Substances contained in the product as the table listed below. : See <Table 1>. : See <Table 2>. <Table 1> Hazardous Substances Lead Mercury Cadmium Hexavalent Polybrominated Polybromodiphenyl Part Name Chromium...
  • Page 7 “ ” indicates that the level of the specified chemical substance exceeds the threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC. Chroma is not fully transitioned to lead-free solder assembly at this moment; however, most of the components used are RoHS compliant.
  • Page 8 Failure to comply with these precautions or specific WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the instrument. Chroma assumes no liability for the customer’s failure to comply with these requirements.
  • Page 9 Safety Symbols DANGER – High voltage. Explanation: To avoid injury, death of personnel, or damage to the instrument, the operator must refer to an explanation in the instruction manual. High temperature: This symbol indicates the temperature is now higher than the acceptable range of human. Do not touch it to avoid any personal injury.
  • Page 10 A190202: 12 pcs. Cable High Voltage Control Cable BNC-BNC Head*2+ High 1 pc. A190201: 10 pcs. Voltage Cable A190202: 4 pcs. A190201: 10 pcs. A190202: 4 pcs. When additional items are required, contact Chroma and provide item’s Note description. viii...
  • Page 11 Hazard Operations This scanning box is able to output high voltage via remote control. For safety precaution, it is necessary to follow the guidelines listed below when performing the control remotely. Do not output any unexpected high voltage as it may cause danger. Operators and other personnel are not allowed to touch the UUT, test cable and the probe terminal when there is high voltage output.
  • Page 12 Storage, Freight & Maintenance Storage When not in use, please pack the device properly and store in a suitable environment. Freight Please pack the device carefully before moving it. If any of the original packing material is missing, please use suitable alternative material and mark it “fragile” and “keep away from water”...
  • Page 13 Revision History The following lists the additions, deletions and modifications in this manual at each revision. Date Version Revised Sections Jun. 2013 Complete this manual.
  • Page 15: Table Of Contents

    3-Way Scanning Box A190201/A190202 User’s Manual Table of Contents Preface..........................1-1 Overview......................1-1 Feature ........................1-1 Specification ........................2-1 Precautions before Use ....................3-1 Operating........................4-1 Connecting Rear Panel..................4-1 Output Terminals on the Front Panel ..............4-2 Using the 19020/19020-4 to Control A190201/ A190202 ........4-3 Setting Output Channel Parameter..............4-4 xiii...
  • Page 17: Preface

    UUT’’s primary, secondary or core testing. 1.2 Feature Fixed test mode The scanning box can work with the Chroma Model 19020/19020-4 to perform the built-in scanning test. It can test 10 UUTs (A190201) or 4 UUTs (A190202) simultaneously for Primary, Secondary or Core scanning tests.
  • Page 19: Specification

    40°C (104°F) -10 to 60°C (14 to 140°F), ≤ 80% RH. Storage Range 430 x 100 x 600 mm / 16.929 x 3.937 x 23.62 in. Dimension(WxHxD) A190201: < 20 kg / < 44lb. Weight A190202: <14.8kg / <33lb...
  • Page 21: Precautions Before Use

    Precautions before Use Precautions before Use The A190201/A190202 can only work with the Chroma Model 19020/19020-4 for use. The maximum operating voltage is AC 5kV/DC 6kV and the firmware version must be 2.02 or later. Whe the A190201/A190202 is working with the Chroma Model 19020/19020-4, the main control signal has to connect to A190201 TA board.
  • Page 23: Operating

    It should go through A190201 TA board before connecting to the 19020. Avoid contacting the high voltage cable and the grounding wire with the control cables. The main grounding wire of the A190201 and the 19020 has to be connected. Figure 4-2...
  • Page 24: Output Terminals On The Front Panel

    The A190202 output has 4 channels and each channel has 3 high voltage output terminals. The indicators show the output status and all are OFF before controlled. When the Model 19020 is working with the Model A190201, the 19020 is placed on top of the A190201 as the figure shown below.
  • Page 25: Using The 19020/19020-4 To Control A190201/ A190202

    Operating Figure 4-5 4.3 Using the 19020/19020-4 to Control A190201/ A190202 Setting SYSTEM CONFIG In SYSTEM SETUP screen, move the highlight to SYSYEM CONFIG and press the Function Key [ENTER] or ENTER on the keyboard. It goes into the SYSYEM CONFIG setup screen...
  • Page 26: Setting Output Channel Parameter

    3-Way Scanning Box A190201/A190202 User’s Manual When in the SYSTEM CONFIG setup screen, move the highlight to LINK SETUP and select SCANNER. 4.4 Setting Output Channel Parameter Following is the setting of SCANNER: AC Withstand Voltage/DC Withstand Voltage/IR Test Mode (WVAC/WVDC/IR) Description of test mode: P→S: Primary to Secondary...
  • Page 27 Operating Output RELAY Mode RTN/Low...
  • Page 28 Kuei-shan Hwaya Technology Park Taoyuan County 33383, Taiwan 33383 台灣桃園縣龜山鄉 華亞科技園區華亞一路 66 號 T +886-3-327-9999 F +886-3-327-8898 Mail: info@chromaate.com http://www.chromaate.com Copyright by CHROMA ATE INC. All Rights Reserved. All other trade names referenced are the properties of their respective companies.
