MOVING THE REFRIGERATOR

1. Turn off the refrigerator and unplug from the outlet.
2. Remove all food and securely tape down all loose items inside.
3. Tape the door shut.
4. Do not lift or pull the door of door handle during transportation.
5. When moving, the appliance can not be tilted over 45 degrees as possible
to the sealed system could occur.
6. Take care to avoid strong vibration or impact to the appliance.

REVERSING THE DOOR

Top Hinge Cover
1
Top Hinge Screws
2
Top Hinge
3
Cabinet Plug
4
Bottom Hinge
5
Door Handle Plug
6
Bottom Hinge Screw
7
Leveling Legs
8
Do not tilt the appliance over 45°when reversing the door as possible damage to the
sealed system may occur.
Remove top hinge cover and 3 top hinge screws which are below it. Then
top hinge.
Remove 1 cabinet plugs and 1 door handle plug.
Remove the door.
Remove right and left leveling legs.
Remove the bottom hinge and 3 bottom hinge screws.
Install the bottom hinge on the other side of the leveling legs with 3 bottom hinge
screws.
Install right and left leveling legs. There are two holes below the refrigerator to fit
the two leveling legs.
I nstall the door.
I nstall the top hinge the other side with 3 top hinge screws.
Install top cover above the top hinge and install 1 cabinet plugs and 1 door
handle plug on the other side.
Adjust the leveling legs.
