French Manual: https://bit.ly/3l4sqbo
Manuel en Français : https://bit.ly/3l4sqbo
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury,
property damage, or loss of life.
Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
IMPORTANT: SAVE THESE INSTRUCTIONS
4001609
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 VENTURE ST., DELTA, BC, CANADA V4G 1H4
920-625
Greenfire
TECHNICAL MANUAL
Fireplace
Insert Pellet Stove
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or
any other appliance.
Installation and service must be performed
by an authorized installer or service agency.
GFI55-2
®
12.20.22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FPI Greenfire GFI55-2
Summary of Contents for FPI Greenfire GFI55-2
- Page 1 Installation and service must be performed additional information consult an authorized by an authorized installer or service agency. installer or service agency. Tested by: IMPORTANT: SAVE THESE INSTRUCTIONS 4001609 FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 VENTURE ST., DELTA, BC, CANADA V4G 1H4 920-625 12.20.22...
- Page 2 Safety Note: If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions, contact local building, fire officials, or authority having jurisdiction about restrictions and installation inspection requirements in your area. The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Emissions and Efficiency - GFI55-2: This manual describes the installation and operation of the Regency GFI55-2 pellet heater.
-
Page 3: Table Of Contents
TABLE OF CONTENTS *This manual is designed for the technician in conjunction with the owner’s manual.* SAFETY LABEL Plated Door Installation ...........14 Thermostat Installation ..........14 Slider/Damper Set-Up .......... 1 5 Copy of Serial No. Decal ..........4 Decal Location ............4 TROUBLESHOOTING UNIT DIMENSIONS Troubleshooting FAQ's ..........16... -
Page 4: Safety Label
SAFETY LABEL On the GFI55-2 the safety label is located on the hopper cover behind the top faceplate. GFI55-2 DECAL LOCATION When locating the rating plate on a GFI55-2 the surround must be removed. Once the Surround has been removed the rating plate will be located on the top of the unit as shown below. -
Page 5: Unit Dimensions
UNIT DIMENSIONS GFI55-2 FIREPLACE PELLET INSERT " (517mm) " (517mm) 10" 10" (253mm) (253mm) " " (26mm) (26mm) 13" 13" (329mm) (329mm) " (610mm) " (610mm) " " (183mm) (183mm) " " (766mm) (766mm) " " (582mm) (582mm) " " (567mm) (567mm) "... -
Page 6: Gfi55-2 Fireplace Pellet Insert W/ Top Vent Adaptor
GFI55-2 FIREPLACE PELLET INSERT WITH TOP VENT ADAPTOR GFI55-2 FIREPLACE PELLET INSERT WITH TOP VENT ADAPTOR 12 - 1/4” Ø 3” (311mm) (76mm) 6 - 9/16” 6 - 7/8” (167mm) (175mm) 16 - 7/8” (429mm) 13” (330mm) 24 - 1/16” (611mm) 30 - 3/4”... -
Page 7: Installation
Unit hot while in operation. Keep children, clothing and furniture away. Contact may cause skin burns. SINCE FPI HAS NO CONTROL OVER THE INSTALLATION OF YOUR STOVE, FPI GRANTS NO WARRANTY IMPLIED OR STATED FOR THE INSTALLATION SOOT: Operation of the stove with insufficient combustion air will result in OR MAINTENANCE OF YOUR STOVE. -
Page 8: Removing Pellet Insert From Pallet
INSTALLATION REMOVING PELLET INSERT FROM PALLET To remove your new insert from its pallet, remove the two (2) screws securing the bottom to the pallet. Fireplace Insert: There is one screw on either side of the bottom. See figure 2. Figure 2: Removing GFI55-2 From Pallet. -
Page 9: Clearances To Combustibles
INSTALLATION GFI55-2 PELLET INSERT CLEARANCES TO COMBUSTIBLES The fireplace insert is certified to be installed into a masonry fireplace only and/or zero clearance wood burning factory built fireplace where allowed by local codes. This model includes a surround faceplate and a pedestal. When installing this unit, ensure that the pedestal is removed from the inside of the hopper and installed on the bottom of the unit. -
Page 10: Exhaust & Fresh Air Intake Location
INSTALLATION EXHAUST AND FRESH AIR INTAKE LOCATION MASONRY FIREPLACE INSERT INSTALLATION EXHAUST: The GFI55-2 requires a surround faceplate and a pedestal. When install- ing this unit, ensure that the pedestal is removed from the inside of the Base of unit to center of flue 9-1/16"... -
Page 11: Positive Flue Connection Without A Full Reline (Usa Only)
INSTALLATION When installing the fireplace insert into a zero clearance fireplace, where When installing the insert into a masonry fireplace DO NOT remove any allowed by local codes, DO NOT cut or modify any factory firebox parts. bricks or masonry, with the following exception; masonry or steel, including If the fireplace insert does not fit into a zero clearance fireplace we rec- the damper plate, may be removed from the smoke shelf and adjacent ommend you use an Greenfire freestanding model and install as a hearth... -
Page 12: Top Vent Adaptor Kit & 3" To 6" Flue Adaptor
INSTALLATION INSTALLATION TOP VENT ADAPTOR KIT & 3” (76 MM) TO 6” (152 MM) FLUE ADAPTOR (APPROVED TOP VENT ADAPTOR KIT & 3” (76 MM) TO 6” (152 MM) FLUE ADAPTOR (APPROVED FOR VERTICAL INSTALLATIONS ONLY) FOR VERTICAL INSTALLATIONS ONLY) Rain cap Steel plate or flashing The existing chimney... -
Page 13: Installation And Removal Of Control Panel In The Surround Panel
INSTALLATION INSTALLATION AND REMOVAL OF CONTROL PANEL IN THE SURROUND PANEL When installing the circuit board control panel into the surround panel, the surround does not need to be assembled. The circuit board will be found in the firebox. Place the circuit board control panel on the backside of the right surround panel so the hinge is on the outside and the top and bottom holes on the control panel line up with those on the surround. -
Page 14: Plated Door Installation
INSTALLATION PLATED DOOR INSTALLATION THERMOSTAT INSTALLATION TO AVOID PERSONAL INJURY DO NOT REMOVE OR REPLACE 1. Install the thermostat by connecting a low voltage millivolt thermostat COVER WHEN PELLET STOVE IS HOT! to the circuit board jumper location shown below. Connect 2 x 18 gauge wires from the connection points on the back of the control board to the thermostat (see figure 38). -
Page 15: Slider/Damper Set
INSTALLATION SLIDER / DAMPER SET-UP THE SLIDER / DAMPER HAS BEEN SET AT THE FACTORY. This is used to regulate the airflow through the pellet stove. The slider damper knob is located on the left cabinet side (see Figure 42) when facing appliance from the front. -
Page 16: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING FAQ'S DO NOT: • Service the stove with wet hands. The stove is an electrical appliance, which may cause a shock hazard if handled improperly. • Only qualified technicians should deal with possible internal electrical failures. • Do not attempt to remove or loosen any screws from inside the firebox without applying penetrating oil (ie. WD40) to any of the screws. WHAT TO DO IF: 1. - Page 17 TROUBLESHOOTING Blocked exhaust / venting system - Have stove and venting cleaned and inspected. Severe negative pressure in area where unit is installed - Check the operation by opening a window, does this solve the problem? If it does, install fresh air intake to unit or room.
-
Page 18: Wiring Diagram
TROUBLESHOOTING WIRING DIAGRAM Combustion Blower Blue 120 °F Brown Exhaust White Vacuum Temperature Switch Brown Sensor Centre Post Grey Un-used 160 °F Purple Convection Temperature Grey Black Switch White White White 120 V Grounded Connector Ignitor Ground Green White Black White Thermostat Yellow... -
Page 19: Parts List
PARTS LIST PARTS LIST & COMPONENTS Part # Description Part # Description 15) GF55-040 Door Handle 1) GF55-001 Auger Motor 115V 1 Rpm GF55-041 Door Handle Bolt, Nut, Washer 2) GF55-002 Combustion Blower Motor Only 115V 3) GF55-003 Convection Blower 115V 16) GF55-042 Slider Damper Rod W/Knob 4) GF55-004... - Page 20 PARTS LIST GFI55-2 PELLET INSERT Greenfire Pellet Insert Technical Manual...
- Page 21 PARTS LIST GFI55-2 PELLET INSERT Greenfire Pellet Insert Technical Manual...
- Page 22 PARTS LIST GFI55-2 PELLET INSERT Greenfire Pellet Insert Technical Manual...
- Page 23 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ Greenfire Pellet Insert Technical Manual...
-
Page 24: Warranty
Warranty protects against defect in manufacture or FPI factory assembled components only, unless herein specified otherwise. Any part(s) found to be defective during the warranty period as outlined above will be repaired or replaced at FPI’s option through an accredited distributor, dealer or pre-approved and assigned agent provided that the defective part is returned to the distributor, dealer or agent for inspection if requested by FPI. - Page 25 Minor movement, expansion and contraction of the steel is normal and is not covered under the terms of this warranty. FPI is not liable for the removal or replacement of facings or finishing in order to repair or replace any appliance in the field.
- Page 26 Customers should contact the authorized selling dealer to obtain warranty service. In the event the authorized selling dealer is unable to provide warranty service, please contact FPI by mail at the address listed below. Please include a brief description of the problem and your address, email and telephone contact information. A representative will contact you to make arrangements for an inspection and/or warranty service.
- Page 27 Phone: Email: For purchases made in CANADA: For purchases made in the UNITED STATES: For purchases made in AUSTRALIA: FPI Fireplace Products Fireplace Products US, Inc. Fireplace Products Australia Pty Ltd International Ltd. PO Box 2189 PMB 125 99 Colemans Road 6988 Venture St.
- Page 29 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________ Greenfire Pellet Insert Technical Manual...
- Page 30 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________ Greenfire Pellet Insert Technical Manual...
- Page 32 Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada Greenfire is a trademark of FPI Fireplace Products International Ltd. © Copyright 2022, FPI Fireplace Products International Ltd. All rights reserved. Greenfire Pellet Insert Technical Manual...
