  • Page 1 MAX II CPLD Board ACM-001-1270 (Rev2) User’s Manual Ver. 1.1 HuMANDATA LTD.
  • Page 2: Table Of Contents

    Table of Contents Revision History ....................1  Introduction ....................1  1. Specifications ..................... 2 2. Overview ......................3 2.1. Name of Parts .......................3 2.2. Block Diagram ......................4 2.3. Power Supply ......................4 2.4. JTAG Connector ....................5 3. CPLD Programming ................... 6 4.
  • Page 3 HuMANDATA will revise the diagram. When a problem can be solved only by replacing components or modifying the product, HuMANDATA will take back the product to replace it with a properly functioning product.
  • Page 4: Revision History

    Delete Download cable connection example figure  Introduction Thank you for purchasing our product ACM-001-1270. This is an evaluation board equipped with an Altera MAX II, reset circuit, and LEDs. It can provide you with very convenient and easy-to-use environment.
  • Page 5: Specifications

    3.386" x 2.126" (86 x 54 [mm]) Weight 21 [g] typ. 66-pin through-hole User I/O Connectors dia. 0.9 [mm], 100[mil]/2.54 [mm] pitch Jumper socket x4 Accessories DIL 80-pin header(Cuttable) x2 RoHS Compliance * There may be cases when compatible parts are used. ACM-001-1270 v1.1...
  • Page 6: Overview

    2. Overview 2.1. Name of Parts User I/Os (CNB) JTAG User input(Jumper) Reset Circuit User LED CPLD Oscillator 30 MHz User I/Os (CNA) Component Side ACM-001-1270 v1.1...
  • Page 7: Block Diagram

    This board operates from single DC 3.3 V power supply. The external power supply should be sufficient and stabilized. Notes Please apply power to CNA and CNB with thick print pattern or cable. Please connect all ground pins. ACM-001-1270 v1.1...
  • Page 8: Jtag Connector

    Net Label Signal Name JTAG Pin Signal Name Net Label XTCK XTDO VCC (3.3 V) V33A XTMS XTDI You can use Altera download cable. (ByteBlaster [II/MV] or USB Blaster) Notice Please pay attention not to attach cables in reverse. ACM-001-1270 v1.1...
  • Page 9: Cpld Programming

    Quartus II help will give you more information.  4. Additional Documentation and User Support The following documents and other supports are available at http://www.hdl.co.jp/en/spc/ACM/acm-001/ Circuit Schematic  Pin List  Dimensional drawing  PCB drawing  Net List  … and more. ACM-001-1270 v1.1...
  • Page 10 MAX II CPLD Board ACM-001-1270 User’s Manual Ver. 1.1 ........... Mar. 27, 2012 HuMANDATA LTD. Address: 1-2-10-2F, Nakahozumi, Ibaraki Osaka, Japan ZIP 567-0034 Tel: 81-72-620-2002 (Japanese) Fax: 81-72-620-2003 (Japanese/English) URL: http://www.hdl.co.jp/en/ (Global) http://www.hdl.co.jp/ (Japan)
