Warn Industries 15-A-59 Series Manual

Engineering Data
Rated Pulling Force:
Drum Barrel Diameter:
Drum Flange Diameter:
Distance Between Flanges:
Recommended Maximum Wire Rope Diameter:
Recommended Minimum Wire Rope Breaking Strength:
Approximate Shipping Weight:
Duty Cycle (intermittent per SAE J706 section 6.2):
Mounting Bolt Torque:
Maximum Layers of Wire Rope:
Gear Reduction:
Brake Type:
Contactor / Remote Type: N/A
Performance By Layer- 1/2" (12.7 mm) dia. rope
Drum Layer
lbf
1
15000
2 12273
3 10385
* Never exceed the Rated Pulling Force. Installation of a Rated Capacity Limiter is recommended.
Line Load
lbf kgf
0
3000 1361
6000 2722
9000 4082
12000 5443
15000 6804
WARN INDUSTRIES, INC
Industrial Products
WARN Industrial Winch
product photo
15000 lbf
4.00 in
8.24 in
9.95 in
1/2 in
26600 lbf
83.0 lb
932 ft
35 - 40 ft*lbf
3 (with 1/2" dia. rope)
36:1
Disk
Line Load * Line Speed 10 GPM
kgf ft/min
kN
6804 12.8
66.7
5567 54.6 15.6
4711 18.5
46.2
First Layer Performance
Pressure Drop at 10 GPM
psi
218
0
547
904
1279
1672
2150
Customer Service (North America): 1.800.543.9276
Customer Service (International): 1.503.722.3008
FAX: 1.503.722.3000 www.warn.com
Model
Series 15-A-59
Hydraulic Winch
Manual Clutch
The Series 15 hydraulic winch features a 2 stage planetary gear train with a
total reduction of 36:1. This winch uses a heavy duty automatic disc brake
and a locking clutch lever. The 4'' (102mm) steel drum provides excellent
durability for the wire rope. Designed to meet SAE J706 and CE standards.
Description:
Wire Rope Tension Plate 10''
Fairlead Black 10''
Fairlead Chrome 10"
Remote Clutch Mechanical
Remote Clutch Air
Wire Rope Assembly 1/2''x75' EIPS
Drum Rotation
6804 kgf
102
mm
209
mm
253
mm
12.7
mm
12066 kgf drum rotation image
37.6 kg
284
m
47 - 54
N*m
Viewed from Motor End
Line Speed 15 GPM
m/min ft/min m/min
3.9 18.9 5.8
4.8 23.1 7.0
5.6 27.3 8.3
Pressure Drop at 15 GPM
BAR psi
15.0 362
37.7 664
62.3 1003
88.2 1379
115.3 1790 123.4
148.2 2200
151.7
Part Number
65931
Accessories
Part Number
31149
24336
30859
38316
71370
77534
Compliance
1. -SAE J706
2.-CE Machinery Directive 98/37/EC and
2006/42/EC
Drum Capacity
30.0
ft m
21 6.4
20.0
46 14.0
75 22.9
10.0
0.0
1
Duty Cycle
2500
BAR min/10min
2000
25.0 N/A
1500
45.8 N/A
1000
69.2 N/A
500
95.1 N/A
N/A
0
0
N/A
12900 S.E. Capps Road,
Clackamas, OR USA 97015
Motor Type
Hydraulic
6.1 ci
(100 cc)
Standards
15 GPM
linespeed graph
10 GPM
2 3
Layer
15 GPM
pressure drop graph
10 GPM
5000 10000 15000
Line Load (lbf)
912509.C1 2/2013
