Kinder Sydney Cot Assembly Instructions

K I N D E R

Va ey

Sydney Cot

ASSEMBLY INSTRUCTIONS

IMPORTANT, RETAIN FOR FUTURE

REFERENCE: READ CAREFULLY

Dimensions(cm): (L)125 x (W)65.5 x (H)91*

Fits Mattress Size(cm): (L)120 x (W)60

Easy assembly

Safe & Sturdy

Solid Pine Wood

•

3 Base Height Positions

Teething Rails

•

*Approx. measurements only. Sizes may vary.

sales@kinder-valley.com

0844 7744644 - Option 2

www.kinder-valley.com

*FACTORY CODE*

Table of Contents

Need help?

Do you have a question about the Sydney Cot and is the answer not in the manual?

Page 1 K I N D E R ® Va ey Sydney Cot ASSEMBLY INSTRUCTIONS IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Dimensions(cm): (L)125 x (W)65.5 x (H)91* Fits Mattress Size(cm): (L)120 x (W)60 Easy assembly Safe & Sturdy Solid Pine Wood •...
Page 2 200mm in the highest position of the cot base. We recommend you use any Kinder Valley mattress size 120cm x 60cm x 10cm. The length and width shall be such that the gap between the mattress and sides and ends does not exceed 30mm.
Page 3 Fixtures & Fittings CHECK THAT YOU HAVE ALL FIXTURES AND FITTINGS BEFORE ASSEMBLY, AND ENSURE THEY ARE NOT BROKEN. x2 Cot Ends x2 Side Rails x1 Base x12 Bolts x12 Barrel Nuts x1 Allen Key Number of people to assemble: Two adults are required to assemble this item.
Page 4 Step 1 Join Cot End to Side Rail with x2 Bolts and x2 Barrel Nuts Step 2 Step 1 Join remaining Cot End with x2 Bolts and x2 Barrel Nuts IMPORTANT - RETAIN FOR FUTURE REFERENCE...
Page 5 Step 3 Step 2 Join Cot Base at the required base height position with x4 Bolts x4 Barrel Nuts Step 4 Complete assembly of your Cot by joining the remaining Side Rail with x4 Bolts and x4 Barrel Nuts IMPORTANT - RETAIN FOR FUTURE REFERENCE...
