Eurosound HM88-4K-IP User Manual

4k 8x8 hdmi2.0 matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
HM88-4K-IP
4K 8x8 HDMI2.0 Matrix Switcher
All Rights Reserved
Version: AUH88A-H2_2018V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM88-4K-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Eurosound HM88-4K-IP

Summary of Contents for Eurosound HM88-4K-IP

  • Page 1 User Manual HM88-4K-IP 4K 8x8 HDMI2.0 Matrix Switcher All Rights Reserved Version: AUH88A-H2_2018V1.0...
  • Page 2 4K 8x8 HDMI2.0 Matrix Switcher Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
  • Page 3 4K 8x8 HDMI2.0 Matrix Switcher SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...

  • Page 4: Table Of Contents

    4K 8x8 HDMI2.0 Matrix Switcher Table of Content 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ...................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Rear Panel ......................3 3. System Connection ..................... 4 3.1 Usage Precautions ....................
  • Page 5 4K 8x8 HDMI2.0 Matrix Switcher 7.3.1 Scene Setting ..................21 7.3.2 I/O connection switching ................ 22 7.3.3 EDID Configuration ................23 7.3.4 Audio Output ..................24 7.3.5 Status Setting ..................25 7.3.6 Network Configuration ................26 7.3.7 Password Modification ................27 7.4 TCP/IP Configuration ..................

  • Page 6: Product Introduction

    4K 8x8 HDMI2.0 Matrix Switcher 1. Product Introduction The product is a professional 4K 8x8 HDMI2.0 Matrix Switcher with 8 HDMI inputs, 8 HDMI outputs, and 8 SPDIF audio outputs, which is designed for switching four HDMI2.0 and HDCP2.2 compliant signals. It also provides powerful EDID management to ensure reliable AV distribution and routing.

  • Page 7: Panel Description

    4K 8x8 HDMI2.0 Matrix Switcher 2. Panel Description 2.1 Front Panel Name Description ① Firmware Micro USB port for updating firmware. Illuminates red when power on;  Turns green in standby mode; ②  Power Indicator Blinks red when upgrading. ...

  • Page 8: Rear Panel

    4K 8x8 HDMI2.0 Matrix Switcher 2.2 Rear Panel CONTROL ON DIP 1 2 3 4 SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF TCP/IP IR IN R S232 EDID DC 24V INPUTS OUTPUTS Name Description HDMI input ports, 8 in total, connect with HDMI ①...

  • Page 9: System Connection

    4K 8x8 HDMI2.0 Matrix Switcher 3. System Connection 3.1 Usage Precautions Make sure all components and accessories included before installation.  System should be installed in a clean environment with proper temperature and  humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ...

  • Page 10: Button Control

    4K 8x8 HDMI2.0 Matrix Switcher Step5. Insert an IR receiver to the IR IN port to control this switcher via IR Remote. Step6. Connect the TCP/IP ports of the control device (e.g. Laptop) and the Matrix Switcher to enable TCP/IP control. Step7.

  • Page 11: Edid Configuration

    4K 8x8 HDMI2.0 Matrix Switcher 4.2 EDID Configuration The rear panel boasts a 4-pin EDID DIP switch to manage EDID. The EDID data and its corresponding DIP switch status are shown in the below list. Switch Status EDID 0000 Pass though (default) 0001 720P 2D Pass-through CH 0010...

  • Page 12: Ir Control

    4K 8x8 HDMI2.0 Matrix Switcher 5. IR Control The Matrix Switcher features one built-in IR receiver to receive IR signal from IR remote to enable IR control. If the external IR receiver or other IR control device need to be used, the IR IN port on rear panel can be connected.

  • Page 13: Rs232 Control

    4K 8x8 HDMI2.0 Matrix Switcher 6. RS232 Control 6.1 Installation/uninstallation of RS232 Control Software Installation Copy the control software file to the computer connected with the Matrix  Switcher. Uninstallation Delete all the control software files in corresponding file path. ...
  • Page 14 4K 8x8 HDMI2.0 Matrix Switcher The main view is shown as below: Parameter configuration area Monitoring area, show the commands and its feedback information. Command sending area Operation area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in command sending area.

  • Page 15: Rs232 Communication Commands

    4K 8x8 HDMI2.0 Matrix Switcher 6.3 RS232 Communication Commands Note: Case-sensitive.  “[“, “]” in the commands are for easy recognition only and not necessary in real  operations. Other symbols including “.”, “,”, “/”, “%”, “;”, “^”. are parts of the commands.

  • Page 16: Lock/Unlock Commands

    4K 8x8 HDMI2.0 Matrix Switcher 6.3.2 Lock/unlock Commands Command Function Feedback Example /%Lock; Lock the front panel buttons. System Locked! /%Unlock; Unlock the front panel buttons. System Unlock! System Locked/ %9961. Query the system locking status. Unlock! 6.3.3 Switching Commands Command Function Feedback Example...
  • Page 17 4K 8x8 HDMI2.0 Matrix Switcher AV:01->05 AV:01->06 AV:01->07 AV:01->08 01 02 03 04 Connect Y N Y Y Query the connection status of the %9971. inputs. 05 06 07 08 Connect Y Y Y N Out 01 02 03 04 Connect Y Y Y Y Query the connection status of the %9972.

  • Page 18: Scene Commands

    4K 8x8 HDMI2.0 Matrix Switcher 6.3.4 Scene Commands Command Function Feedback Example Save the present operation to the Save[Y]. preset command [Y], ranges from 1 to Save To F6 Recall[Y]. Recall the preset command [Y]. Recall From F2 Clear[Y]. Clear the preset command [Y]. Clear F8 6.3.5 HDCP Compliance Command...

  • Page 19: Edid Configuration

    4K 8x8 HDMI2.0 Matrix Switcher 6.3.6 EDID Configuration The DIP switch status should be set as 1111 to enable Software EDID management mode: RS232 control or GUI control. Command Function Feedback Example Input port [y] learns the EDID from output port [x]. If the EDID data is available and the audio part supports not only PCM EDIDH[x]B[y].

  • Page 20: Enable/Disable Digital Audio

    4K 8x8 HDMI2.0 Matrix Switcher 6.3.7 Enable/disable Digital Audio Command Function Feedback Example Enable SPDIF audio output port x. DigitAudioON[ DigitAudio ON with [x]/ X=1~8, enable the port x.  ALL Outputs X=9, enable all ports.  Disable SPDIF audio output port x. DigitAudioOFF DigitAudio OFF with X=1~8, disable the port x.

  • Page 21: Tcp/Ip Control

    4K 8x8 HDMI2.0 Matrix Switcher 7. TCP/IP Control 7.1 Control Modes TCP/IP default settings: IP is 192.168.0.178, Gateway is 192.168.0.1, and Serial Port is 4001. IP can be changed as you need, Serial Port cannot be changed. Controlled by single PC ...

  • Page 22: Tcp/Ip Communication Software Control

    4K 8x8 HDMI2.0 Matrix Switcher Step1. Connect the TCP/IP port of the Matrix Switcher to Ethernet port of PC with twisted pair. Step2. Set the PC’s network segment to the same as the Matrix Switcher. Do please remember the PC’s original network segment. Step3.
  • Page 23 4K 8x8 HDMI2.0 Matrix Switcher 2) Enter commands in designed area to control the Matrix Switcher, see as below: Enter your command here. Commands are the same with RS232 commands listed in 6.3 RS232 Communication Commands Here you will receive the feedback after a command is sent.

  • Page 24: Gui Control

    4K 8x8 HDMI2.0 Matrix Switcher 7.3 GUI Control The Matrix Switcher can be controlled via GUI It allows users to interact with the Matrix Switcher through graphical icons and visual indicators. Access GUI interface through any one of the following methods: Access through web browser: Type the default IP 192.168.0.178 in the browser at first login.
  • Page 25 4K 8x8 HDMI2.0 Matrix Switcher Type 192.168.0.178 in your browser, it will enter the log-in interface shown as below: This system divides into administrator and user mode. Administrator mode: User name: admin; Password: admin (default setting) User mode: User name: user; Password: user (default setting) NOTE: Log in as admin can access more configuration interfaces than user.

  • Page 26: Scene Setting

    4K 8x8 HDMI2.0 Matrix Switcher 7.3.1 Scene Setting Type the user name: admin, password: admin, and then click LOGIN, it will show the Scene menu as shown below: All ten scenes are shown in above interface. Select a scene and then click “Load” can invoke the selected scene. Click “Cancel”...

  • Page 27: I/O Connection Switching

    4K 8x8 HDMI2.0 Matrix Switcher 7.3.2 I/O connection switching Click to enter the following interface, it provide intuitive I/O connection switching. The button matrix displays every possible connection between every input and output; users can carry on the connections by clicking corresponding button. Buttons 1~8 at the right-bottom corner provides quick saving and recall for overall connection status.

  • Page 28: Edid Configuration

    4K 8x8 HDMI2.0 Matrix Switcher 7.3.3 EDID Configuration Click setting button to enter configuration interfaces. All embedded EDID of the Matrix Switcher are shown in the above interface. User can select EDID in accordance with actual needs. Select “EDID Copy” to enter the following interface:...

  • Page 29: Audio Output

    4K 8x8 HDMI2.0 Matrix Switcher The EDID of INPUT device can be gained from OUTPUT devices. Step1: Select one OUTPUT device that you want to copy its EDID. Step2: Select one or more input devices that need to gain EDID. When select To All inputs, all input devices will copy the EDID from output device.

  • Page 30: Status Setting

    4K 8x8 HDMI2.0 Matrix Switcher 7.3.5 Status Setting Product Name& Model:  Click “Status” to enter the following interface to modify the name and mode of this machine, and then they will be display in LCD screen. Button label:  Select “Button”...

  • Page 31: Network Configuration

    4K 8x8 HDMI2.0 Matrix Switcher Scene name:  Select “Scene” to enter the following interface to modify the name of scenes. 7.3.6 Network Configuration Click “Network” to enter the following interface to inquire and configure network settings including MAC address, IP address, subnet mask, and Gateway.

  • Page 32: Password Modification

    4K 8x8 HDMI2.0 Matrix Switcher 7.3.7 Password Modification Click “Password” to enter the following interface to inquire and modify the admin or user password. In the above interface, turn on the Front Panel to lock all buttons of machine, they cannot be operated.

  • Page 33: Gui Update

    4K 8x8 HDMI2.0 Matrix Switcher 7.5 GUI Update GUI for the Matrix Switcher supports online update in http://192.168.0.178:100. Type the username and password (the same as the GUI log-in settings, modified password will be available only after rebooting) to log in the configuration interface. After that, click Administration at the source menu to get to Upload Program as shown below: Select the desired update file and press Apply, it will start upgrading then.

  • Page 34: Firmware Upgrade Through Usb Port

    4K 8x8 HDMI2.0 Matrix Switcher 8. Firmware Upgrade through USB port The matrix switcher boasts a USB port for online firmware upgrade on the front panel. Follow these steps to upgrade firmware: Step1. Copy the upgrade software and the latest upgrade file (.bin) to PC. Step2.

  • Page 35: Specification

    4K 8x8 HDMI2.0 Matrix Switcher 9. Specification Input Signal 8 HDMI Input Connector Female Type-A HDMI Output Signal 8 HDMI; 8 SPDIF audio Output Connector Female Type-A HDMI; 3.5mm mini jack Control Signal 1 IR IN; 1 TCP/IP; 1 RS232 Control Connector 3.5mm mini jack;...

  • Page 36: Panel Drawing

    4K 8x8 HDMI2.0 Matrix Switcher 10. Panel Drawing 23 mm 437 mm CONTROL ON DIP 1 2 3 4 SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF SPDIF TCP/IP IR IN R S232 EDID INPUTS OUTPUTS DC 24V...

  • Page 37: Troubleshooting & Maintenance

    4K 8x8 HDMI2.0 Matrix Switcher 11. Troubleshooting & Maintenance Problems Potential Causes Solutions The connecting cables may not be Check whether the cables connected correctly or it may be are connected correctly Color losing or no broken. and in working condition. video signal output Make sure the connection Fail or loose connection...
  • Page 38 4K 8x8 HDMI2.0 Matrix Switcher powered on EDID management Change for another HDMI The HDMI cable is broken at the does not work cable which is in good output end. normally working condition. Switch again. Manage the EDID data There is a blank manually to make the screen on the The display does not support the...

  • Page 39: Customer Service

    4K 8x8 HDMI2.0 Matrix Switcher 12. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years. 2) Scope These terms and conditions of Customer Service apply to the customer service provided for the products or any other items sold by authorized distributor only.
