- Page 1 KITCHEN PLAY SET Model #MKG105 Assembly Instructions Please read this manual carefully and assemble the product according to the instructions given in this manual.
- Page 2 Kitchen Play Set Assembly Instructions Product Parts/Boards Other Parts and Accessories...
-
Page 3: Tools Required
Identify all the parts and the numbers (according to the manual) for correct assembly. • Assembly should be done by an adult. If you need help or replacement parts please contact us Kiddery Toys Inc. Text or Call: 1-914-623-8794 Email: support@kidderytoys.com Website: www.kidderytoys.com... - Page 4 Kitchen Play Set Assembly Instructions Step 2 Install Base: Step 3 Install Side Panels: Attach the Boards (2) And (3) to the base (1) Attach board (4) to board (1) by using the screws (A). using screws (A) Step 4 Install Toe kick &...
- Page 5 Kitchen Play Set Assembly Instructions Step 6 Install Striker & 33: Step 7 Install Knobs: Attach Striker (K) using Screws (G) Attach Stove Knobs (31) to Panel (8) using Screws (E). Attach (33) to front using screw (C). Cx1 GX2 KX1 33x1 EX4 31x2 Step 9: Fridge Handle:...
- Page 6 Kitchen Play Set Assembly Instructions Step 10: Fridge Door: Step 11: Install Striker: Attach Striker (K) to Door (9) using screws (G) Install part (33) to Door (9) using screw (C) GX2 KX1 Step 13: Install the Lever: Step 12: Install Ice-maker: Install ice maker part (28) onto Insert the Lever part (29) thru the top whole...
- Page 7 Kitchen Play Set Assembly Instructions Step 14: Step 15: Install Fridge Door & Install Oven Door & Control Panel: Stove Control Panel: Place Fridge Door (9) in slot, then place Place Oven Door (7) in slot, then place panel (10) in slot. panel (8) in slot.
- Page 8 Kitchen Play Set Assembly Instructions Step 17: Step 18: Install the Faucet: Install Side Panels: Attach left panel (12) and right panel (13) Attach Faucet (24) to counter-top (11) using screws (L) to counter (11) using (A) Step 20: Step 19: Install Cook-Top: Counter-Top: Install 2 x AA Batteries (Not Included)
- Page 9 Kitchen Play Set Assembly Instructions Step 22: Shelfs: Step 21: Install Back Panel: Attach shelf (15) and shelf (16) to Insert Back Panel (14) in slot back panel (14) using screws (B) Step 23: Assemble Hood and Shelf: Step 24: Install Assembled Attach Divider (18) to panel (17) using screws (B), Shelf and Hood:...
- Page 10 Kitchen Play Set Assembly Instructions Step 26: Install Microwave Step 25: Microwave Door & Top Panel: Panel, Door, Top Panel: Attach Handle (27) to Door (19) using screws (C) And Install Control Panel (20) And Striker (K) with screws (G), Microwave Door (19) then place (21) on top.
-
Page 11: Safety Instructions
Kitchen Play Set Assembly Instructions Safety Instructions: • Assembly should be done by an adult. • Don’t climb shelves to reach the top. • Place the unit over flat ground. • Tightly fix all the screws to prevent any accident. •... - Page 12 7. We reserve the right to retain and discard any part or accessories that have been found damaged upon replacement and repair. 8. Damage caused by accident, abuse, misuse, flood fire, earthquake or other external causes. Kiddery Toys Inc. Text or Call: 1-914-623-8794 Email: support@kidderytoys.com Website: www.kidderytoys.com...
