BigBlue AL1300NP Instruction Manual

A L 1 3 0 0 N P
I N S T R U C T I O N M A N U A L
L I - I O N R E C H A R G E A B L E B AT T E R Y
N A R R O W B E A M L E D L I G H T
Congratulations on your purchase of our BigBlue product. The BigBlue
Diving Light uses carefully selected materials that have met rigorous
industry standards. With innovative manufacturing processes, and
strict quality controls, we guarantee the reliability of ail BigBlue Di-
ving products.
INTRODUCTION
The AL1300NP Li-ion Rechargeable Battery Narrow Beam LED Light de-
livers 1300 lumens of light output and it features a 4-level and SOS push
button on the body that enables you to adjust the brightness and pro-
long the burn time according to each individual need. Or just in emer-
gency to go to SOS to seek for help.
LIMITED WARRANTY
1. BigBlue guarantees the proper operation of this product by the
original retail purchaser under norrnal and intended use.
2. This warranty applies only to the original retail purchaser, which
does not cover commercial or rentai use, and it is not transferable
to third parties.
3. If the original retail purchaser detects defect in the materials
or workmanship, return the product together with proof of pur-
chase, including the date of purchase to an authorized BigBlue
dealer or BigBlue.
4. The warranty covers a period of up to one year from the date of
purchase. Warranty for rechargeable battery pack is valid for six
months only.
5. This limited warranty is in lieu of all other warranties. No other
person or party is authorized to assume for BigBlue any other lia-
bility in connection with the sales of this product.
6. This warranty will be voided if the product or any of its parts have
been tempered with, repaired, modified, transformed, adapted,
or damaged without authorization by BigBlue.
7. This warranty does not cover parts subjected to normal wear and
tear, including and is not limited to the following: O-ring, battery
pack, front glass (surface scratch or damage on impact).
8. This warranty does not cover damages due to impact, used in
chlorinated or polluted waters, and extended exposure to heat
sources.
FEATURES
Our high output LED system delivers brilliant luminosity at 1300 lumens, a
10°strong penetrating light spot, making it ideal for tech-dive.
- The unique XML high intensity LED is energy efficient to guarantee a long
burn time of up to 50,000 hours, reducing the need for frequent bulb re-
placement.
- The 6500K white light reflects the true vibrant colors of the underwater
surrounding while diving.
- The 4-level power output lets you choose between 100%, 50%, 25% and
10% of total brightness for cool white.
- The push button not only makes it easy to change between the power
output levels, but it is also designed to be insulated from all internai parts,
eliminating the risk of leakage.
- The product cornes with a smart charger, enabling you to smart qui-
ck-charge in 2-3 hours.
- The thermal protection system prevents the light from overhea-
ting by automatically cutting off its power supply in the event of
prolonged use on land, or exposure to temperatures in excess of
70°C. As soon as the lamp cools down, power is restored.
PRECAUTIONS AND ADVICE
CONCERNING THE LI-ION RECHARGEABLE BATTERY
- Intended to be used with the custom-made BATCELL18650 Li-ion
rechargeable battery pack only.
- Make sure to connect with the correct polarity. Incorrect connec-
tion can damage the unit.
- Fully charge the batteries before using for the first lime.
- Use only the power adapters supplied with the charger. Using in-
compatible adapters may damage the charger or result in tire or
electric shock.
- Charge lime will depend on the remaining charge in the battery
and the surrounding temperature.
- Do not charge near hot temperature, under direct sunlight, co-
ver the charger with a blanket, or place under heavy pressure. If
the temperature is too high, il may cause the battery to leak or
rupture.
- When storing or carrying the battery, avoid direct contact with
metal abjects to avoid short circuit.
- The Li ion battery should not be dropped or be subjected to strong
mechanical shock.
- Do not operate the battery or the charger if il has been damaged
or subjected to shock.
- Remove the battery from the light if il is not going to be in use for
an extended period of lime.
- Do not dispose of in fire. Do not heat, deform, solder, disassemble
or modify.
- Do not dispose of your rechargeable battery with general
household waste. Check with your local collection system for
electrical and electronic products.
- Do not short-circuit, overcharge, crush, drop, mutilate, penetrate
with foreign abjects, apply reverse polarity, expose to high tempera-
ture or disassemble packs and cells.
- Use only lithium-ion cells with a designated protection circuit and
approved charger.
- Discontinue using the battery and/or charger if the battery gels
excessively warm.
- The electrolyte is highly flammable and battery rupture can
cause physical injury.
- Use a foam extinguisher, C02, dry chemical, powdered graphite,
copper powder or soda (sodium carbonate) to extinguish a
lithium-ion lire. Only pour water to prevent the tire from sprea-
ding.
- If the lire of a burning lithium-ion battery cannot be extinguished,
allow the pack to burn out on its own in a controlled and safe
manner.
Charge the battery after each use. It is not necessary to discharge the
battery before charging. It is preferable to recharge the battery every
month, even if it is not in use.
