URANIUM-SERIES
SUBWOOFER
ANLEITUNG / OWNER'S MANUAL
GZUW 8SQX
GZUW 10SQX
GZUW 12SQX
Ausstattungsmerkmale / Features
• Aluminium-Gußkorb
• Gepresste und beschichtete Papiermembrane
• 2x 2 Ohm Kupferschwingspule
• Kapton-Schwingspulenträger
• Audiophile POLYCOT-Zentrierung
o Aluminum cast basket
o Pressed and coated paper cone
o 2x 2 Ohm copper voice coil
o Kapton former
o Audiophile POLYCOT spider

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GZUW 8SQX and is the answer not in the manual?

Questions and answers

Related Manuals for Ground Zero GZUW 8SQX

Summary of Contents for Ground Zero GZUW 8SQX

  • Page 1 URANIUM-SERIES SUBWOOFER ANLEITUNG / OWNER’S MANUAL GZUW 8SQX GZUW 10SQX GZUW 12SQX Ausstattungsmerkmale / Features • Aluminium-Gußkorb • Gepresste und beschichtete Papiermembrane • 2x 2 Ohm Kupferschwingspule • Kapton-Schwingspulenträger • Audiophile POLYCOT-Zentrierung o Aluminum cast basket o Pressed and coated paper cone...
  • Page 2 Technische Daten / specifications GZUW 8SQX GZUW 10SQX GZUW 12SQX Voice coil diameter 50 / 2" 50 / 2" 50 / 2" (mm / inch) Impedance (ohm) 2x 2 2x 2 2x 2 (ohm) (Hz) 56.4 46.7 38.6 11.17 9.64 10.24...
  • Page 3 Gehäuseempfehlung / enclosure recommendation GZUW 8SQX vented Bassreflex/ 18 Liter netto / 0.64 cu.ft. net (Rot / red) 7 cm / 2.76” Port diameter 25 cm / 9.84” Port length 46 Hz / 37 Hz Fb / F3 21 Liter netto geschlossen / 0.74 cu.ft. net sealed Bandpass 4 th order 13 Liter netto ventiliert / 0.45 cu.ft.
  • Page 4 Gehäuseempfehlung / enclosure recommendation GZUW 10SQX /vented Bassreflex 42 Liter netto / 1.48 cu.ft. net (Rot / red) 8 cm / 3.15” Port diameter 21 cm / 8.27” Port length 36 Hz / 30 Hz 22 Liter netto geschlossen / 0.78 cu.ft. net sealed Bandpass 4 th order 26 Liter netto ventiliert / 0.92 cu.ft.
  • Page 5 Gehäuseempfehlung / enclosure recommendation GZUW 12SQX ented Bassreflex/v 56 Liter netto / 1.98 cu.ft. net (Rot / red) 10 cm / 4” Port diameter 26 cm / 10.24” Port length 35 Hz / 31 Hz 27 Liter netto geschlossen / 0.95 cu.ft. net sealed Bandpass 4 th order 33 Liter netto ventiliert / 1.17 cu.ft.
  • Page 6 Änderungen oder Verbesserungen an dem Produkt vorzunehmen ohne den Kunden darüber zu informieren. Terms of warranty The limited warranty for this product is covered by Ground Zero´s local distribution partners and their terms and conditions. For further information contact your local retailer or distributor.
