- Page 1 User Guide IdeaPad Slim 7 Pro 16″...
- Page 2 • Setup Guide First Edition (October 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
CRUs for your product model ..Intelligent features ....Call Lenovo ....Customize intelligent features in Lenovo Before you contact Lenovo . - Page 4 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) IdeaPad Slim 7 Pro 16ACH6 82QR • For further compliance information, refer to the Generic Safety and Compliance Notices at https:// pcsupport.lenovo.com/docs/generic_notices... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
If the light is on, the camera is in use. 5. Time of flight (ToF) sensor Detect human presence in front of the computer for facilitating zero touch and other convenient features. 6. Screen Display text, graphics, and videos. The screen supports multi-touch function. © Copyright Lenovo 2021... -
Page 8: Base
Base 1. Wireless antennas Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Note: The antennas are not visible from the outside of the computer. 2. Numeric keypad To enable or disable the numeric keypad, press the Num Lock key. 3. -
Page 9: Left
Left 1. Power connector Connect to power with the included power cord and ac power adapter. Note: Power connector varies by model. It may be either a rectangular or a USB-C connector. If the power connector is a physical USB-C connector, it is used primarily for power input. It does not support DisplayPort Alt Mode nor does it support SuperSpeed USB data transfer. -
Page 10: Right
The always-on function can be turned on or off in the UEFI/BIOS setup utility. Note: If Lenovo Vantage is pre-installed on your computer, you can also set always-on function from within that software. -
Page 11: Features And Specifications
Features and specifications Dimensions • Width: 356 mm (14.01 inches) • Depth: 245.9 mm (9.68 inches) • Thickness – Thinnest: 17.4 mm (0.68 inches) – Thickest: 19.99 mm (0.78 inches) ac power adapter • With a USB-C plug – Input: 100 V ac–240 V ac, 50 Hz–60 Hz –... -
Page 12: Statement On Usb Transfer Rate
Connectors and slots • Combo audio jack • USB Type-A connector × 2 (one connector with Always-On function) • USB-C connector (with the icon) * – Power input up to 95 W using the included power adapter – Power output up to 5 V and 3 A –... -
Page 13: Operating Environment
Operating environment Maximum altitude (without pressurization) 3048 m (10 000 ft) Temperature • At altitudes up to 2438 m (8000 ft) – Operating: 5°C to 35°C (41°F to 95°F) – Storage: 5°C to 43°C (41°F to 109°F) • At altitudes above 2438 m (8000 ft) –... - Page 14 User Guide...
-
Page 15: Chapter 2. Get Started With Your Computer
If night light mode is turned on, you can adjust the color temperature of the Night light temperature screen. Note: Selected Lenovo computers are low blue light certified. These computers are tested with night light turned on and color temperature set to the default value of 48. Windows... -
Page 16: Windows Help Information
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store. -
Page 17: Interact With Your Computer
Lock the screen. Display thumbnails of all open apps. Open the Windows Calculator app. Open Lenovo Vantage, Lenovo PC Manager, or an app launch bar. Open the Windows snipping tool. Play or pause playback of media. Stop playback of media. -
Page 18: Numeric Keypad
Numeric keypad Some Lenovo computers includes a dedicated numeric keypad on the far right of the keyboard. The keypad is used for entering numbers and operators quickly. Press the NumLock key to enable or disable the numeric keypad. - Page 19 Touch operation Used for Zooming out Pinch Zooming in Spread Opening the widgets panel Swipe in from the left edge Opening the notification center Swipe in from the right edge The Windows operating system also supports 3- and 4-finger gestures on the screen and the touchpad. You can set them up in Settings ➙...
- Page 20 User Guide...
-
Page 21: Chapter 3. Explore Your Computer
Intelligent features Some Lenovo computers include a ToF sensor and an IR camera on top of the screen. Using data provided by the ToF sensor and IR camera, the computer is able to behave like a human. It can detect your presence, your movement, and perform operations automatically to protect your privacy, save battery power, or just make your daily use of the computer easier. - Page 22 Open Glance by Mirametrix You need to open Glance by Mirametrix to use the snap window and smart pointer feature. Step 1. Enter the software name in Windows Search box. Step 2. Select the matched result. The software icon appears in the Windows notification area to indicate that the software is open. Note: When the software is open, it takes up computer memory and may affect computer performance in rare cases where available memory is limited.
- Page 23 Step 2. Move your head or adjust the angle of the screen so that the shaded circle is positioned within the outer ring. The background color of the calibration window changes during calibration. The green color indicates that your head position is good and the sensor can detect your movement easily. Note: If the background color is red, the sensor cannot detect your head movement.
-
Page 24: Zero Touch
For selected video players, this feature will pause any video playing when you leave the computer and resume upon your return. Zero touch can be enabled or disabled in Lenovo Vantage or Lenovo PC Manager. Manage power Use the information in this section to achieve the best balance between performance and power efficiency. - Page 25 The maximum output power of a USB-C charger must be at least 45 W in order to work with the computer. Lenovo USB-C chargers (not supplied) with the following ratings are tested to work with such models. The power-supplying capability varies based on the specification of the charger.
-
Page 26: A Power Plan
Table 4. Lenovo USB-C chargers and corresponding power-supplying capabilities Lenovo USB-C charger Capability 95 W (20 V, 4.75 A) Capable of charging the computer 45 W (20 V, 2.25 A) Capable of charging the computer in sleep, hibernation, 65 W (20 V, 3.25 A) -
Page 27: Change Settings In Uefi/Bios Setup Utility
Change the setting to Disabled or Enabled. Step 4. Select Exit ➙ Exit Saving Changes. Enable or disable always-on For some Lenovo computers with always-on connectors, the always-on function can be enabled or disabled in the UEFI/BIOS setup utility. Step 1. Open the UEFI/BIOS setup utility. -
Page 28: Set Passwords In Uefi/Bios Setup Utility
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 29: Set User Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 30: Change Or Remove Hard Disk Password
Note: If you start the setup utility using the user password, you cannot set hard disk password. Step 3. Follow on-screen instructions to set both master and user passwords. Note: The master and user hard disk passwords must be set at the same time. Select Exit ➙... -
Page 31: Chapter 4. Help And Support
Where can I get the latest device • Lenovo Vantage or Lenovo PC Manager drivers and UEFI/BIOS? • Lenovo Support Web site at https://support.lenovo.com... -
Page 32: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 33: Crus For Your Product Model
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. -
Page 34: Purchase Additional Services
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty, trained service personnel are available to provide the applicable level of service. -
Page 35: Appendix A. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 36 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
