Summary of Contents for Zimmer ZTone non-medical
- Page 1 Instructions for Use ZTone non-medical...
- Page 2 ZTone Instructions For Use The user of this device must sufficiently understand its functions and the precautions that must be observed for its safe use and stable performance. For the safe use and post management of the device, be sure to thoroughly understand the details of the Instructions For Use before using the device.
-
Page 3: Table Of Contents
ZTone Instructions For Use Contents 1. Information on safety ····················································································· 6 1.1 Definitions of symbols ····························································································································· 6 1.2 Requirements for safety ·························································································································· 9 1.3 Safety device ··········································································································································· 12 1.4 Applicable person ·································································································································· 12 1.5 Contraindications ··································································································································· 12 2. High intensity pulsed electromagnetic field ···················································· 13 2.1 Principle ···················································································································································... - Page 4 ZTone Instructions For Use 8.5 Stimulation Pulse Width ························································································································ 33 8.6 Expected life time ··································································································································· 33 9. EMC emissions and immunity ·······························Fehler! Textmarke nicht definiert. 10. FAQ ·········································································································· 34 11. Maintenance ······························································································ 35 11.1 Cleaning procedure ······························································································································ 35 11.2 Routine inspection of equipment ······································································································ 35 11.3 Safety inspection ··································································································································...
- Page 5 ZTone Instructions For Use List of figures Figure 1. Main Components ..........................14 Figure 2. Power cable connection ........................16 Figure 3. Transporting wheel in 'Loose' (Left) and in 'Locked' (right) ............16 Figure 4. Transducer connection ........................17 Figure 5. Front view ............................. 18 Figure 6.
-
Page 6: Information On Safety
ZTone Instructions For Use 1. Information on safety 1.1 Definitions of symbols ❏ When there is specific information in the Instructions For Use that needs to be emphasized for safety, the following terms and symbols are indicated. All warnings and precautions shall always be observed. - Page 7 ZTone Instructions For Use To indicate that the contents of the transport package Fragile are fragile and the package shall be handled with care. To indicate correct upright position of the transport This way up package. Recycling To indicate the location of a recycling bin or container. To indicate disconnection from the mains, at least for “OFF”...
-
Page 8: Table 1. Definitions Of Symbols
ZTone Instructions For Use Keep away from To indicate that transport package shall not be exposed to sunlight sunlight Unique Device Indicates a carrier that contains Unique Device Identifier Identifier information Table 1. Definitions of Symbols 8/40 [REMIFU-ZTN(EN)(NM)] 2022.12.13 (Rev. 0) -
Page 9: Requirements For Safety
ZTone Instructions For Use 1.2 Requirements for safety 1.2.1 Warning ❏ This equipment is not applicable to the following persons. - Person with high blood pressure - Person with high fever - Pregnant, newborns, infants, and children - Person with Heart disease (especially those with pacemakers) - Person with acute illness - A Person who has implanted implants in the body, such as an artificial hip joint - Person wearing artificial pacemakers, drug injection pumps, and hearing aids... - Page 10 ZTone Instructions For Use ❏ Keep the area where the equipment is installed free of water, alcohol, and flammable substances. ❏ For electrical safety, the device must be connected to a safety grounded power source. ❏ To prevent unintended phenomena, keep the device away from direct sunlight or strong electromagnetic fields.
- Page 11 ZTone Instructions For Use are located. 1.2.6 Application Notes ❏ Use care so that magnetic stimulation does not penetrate the heart area. ❏ You should review your current or past drug resistance level. ❏ Before using the device, check the connection status of the wires and connectors connected to the device, damage status, and surface status of components to confirm that there is no problem before use.
-
Page 12: Safety Device
ZTone Instructions For Use 1.3 Safety device ❏ When a magnetic field is output, a buzzer sounds periodically to notify you that the magnetic field is being output. ❏ When the mode is changed or the power is turned on, the output always starts from “0”. -
Page 13: High Intensity Pulsed Electromagnetic Field
ZTone Instructions For Use 2. High intensity pulsed electromagnetic field 2.1 Principle The transducer which is used to magnetic stimulation makes electrical fields by pulse current flowing from a capacitor according to the principle of Faraday's Law. Whenever the capacitor bank is discharged by the action of the control system, a pulse of current flows through the stimulating coil. -
Page 14: Installation
ZTone Instructions For Use 3. Installation 3.1 Components Main body with transducer Transducer Power cable Instructions For Use Figure 1. Main Components 3.2 Electrical installation condition ❏ Input power : 220-240 V~, 50Hz, 60 Hz ❏ Power consumption : MAX 15A 14/40 [REMIFU-ZTN(EN)(NM)] 2022.12.13 (Rev. -
Page 15: Environmental Condition
ZTone Instructions For Use 3.3 Environmental condition 3.3.1 Operation environment ❏ Temperature : 5 – 28 ℃ (41 - 82.4 ℉) ❏ Humidity : 30 – 75 % R.H. ❏ Pressure : 80 - 106 kPa 3.3.2 Transport and Storage environment ❏... -
Page 16: Figure 2. Power Cable Connection
ZTone Instructions For Use ❏ Do not connect multiple devices to a single power outlet. ❏ Connect the power cable to the power terminal of ZTone as shown below and connect the other end to a grounded power socket. Figure 2. Power cable connection To prevent the danger of electrical shock, connection shall be made Warning to a protected and grounded power supply. -
Page 17: Figure 4. Transducer Connection
ZTone Instructions For Use 3.4.4 Connection of Transducer ❏ The transducer is detachable from the main body. Before using the product, turn the lever to connect the transducer and the body. Figure 4. Transducer connection 3.4.5 Transducer ❏ The ZTone is equipment that generates a magnetic field by applying a strong current to a transducer. -
Page 18: Product Description
ZTone Instructions For Use 4. Product description 4.1 External view 4.1.1 Front view Figure 5. Front view Name Function A display unit that operates the device using touch or displays Control Panel (Touch Screen) the device's operating status CH1 Transducer Magnetic field output transducer CH2 Transducer Magnetic field output transducer... -
Page 19: Figure 6. Rear View
ZTone Instructions For Use 4.1.2 Rear view Figure 6. Rear view Name Function CH2 transducer connector CH2 Transducer cable connector CH1 transducer connector CH1 Transducer cable connector Power Switch Power ON/OFF switch Vent Vents for air circulation Power input terminal AC power inlet Ground terminal Equal power ground connection... -
Page 20: Controls
ZTone Instructions For Use 4.2 Controls Figure 7. Initial screen Name Function Treatment area selection window Select the image of the area to be treated Configuration Brightness and volume settings 20/40 [REMIFU-ZTN(EN)(NM)] 2022.12.13 (Rev. 0) -
Page 21: Figure 8. Level Selection Screen
ZTone Instructions For Use Figure 8. Level selection screen Name Function Select the transducer you want to use Channel selection (Left = CH1, Dual = CH1 and CH2, Right = CH2) Level selection Select detail mode Next button Change to Intensity setting window Back to previous screen Return to treatment area selection window Configuration... -
Page 22: Figure 9. Intensity Setting Screen
ZTone Instructions For Use Figure 9. Intensity setting screen Name Function Select the transducer you want to use Channel selection (Left = CH1, Dual = CH1 and CH2, Right = CH2) CH1 Magnetic field Intensity Magnetic field strength can be set (0%~100%, 1% step) CH2 Magnetic field Intensity Magnetic field strength can be set (0%~100%, 1% step) Synchronize... -
Page 23: Figure 10. Configuration
ZTone Instructions For Use Figure 10. Configuration Name Function Close the window Return to previous screen Brightness setting Adjust the brightness of the screen in 7 steps Volume setting Volume control in 7 steps 23/40 [REMIFU-ZTN(EN)(NM)] 2022.12.13 (Rev. 0) -
Page 24: Component
ZTone Instructions For Use 4.3 Component 4.3.1 Transducer Figure 11. Transducer Name Function Transducer connector Transducer connector Magnetic field output Output part where the magnetic field of the coil is output 4.3.2 Power cable Figure 12. Power Cable Name Function Power Cable The cable that supplies power to the Main Unit 24/40... -
Page 25: Operation Instructions
ZTone Instructions For Use 5. Operation instructions 5.1 Preparation For hygiene reasons, the treatment area of the person’s body and the device are not in direct contact. There is no need to undress when using this device. Please prepare some fabric towels to be placed on the treatment area of person’s body for hygine purpose. - Page 26 ZTone Instructions For Use 5.2.1 Method There are 5 modes in which the protocol is applied to suit the body part. Frequency, on time, off time, strength, repetition are preset. The selected mode has a fixed operating time. (a) Select the image of the area to be treated using the touch screen.
- Page 27 ZTone Instructions For Use (d) When the start button is pressed, the remaining operating time displayed. (e) Adjust the Intensity by touch- scrolling. If you touch-scroll after pressing Synchronize, the intensity of CH1 and CH2 is adjusted at the same time. (Synchronize is enabled only in Dual.) (f) After finishing use, select the STOP button and turn off the power switch...
-
Page 28: Environment Setting
ZTone Instructions For Use 5.3 Environment setting The brightness of screen and volume can be adjusted. (a) Press environment setting at the right bottom of the screen by using touch screen. (b) Adjust the brightness of screen and the volume by using the button. After finishing all the settings, close the environment setting... -
Page 29: Frequently Used Functions
ZTone Instructions For Use 5.4 Frequently used functions 1) Transducer attachment The transducer must be closered to the affected part and fixed. 2) End operation An image is displayed on the LCD display that the operation is finished, and the user must check it with the naked eye. -
Page 30: How To Store And Care For After Use
ZTone Instructions For Use 6. How to store and care for after use ❏ The machine must be stored with the main power switch turned OFF. ❏ Be sure to remove the power plug from the outlet when not using the machine for a long time. -
Page 31: Messages
ZTone Instructions For Use 7. Messages 7.1 Over Temperature The ZTone is an equipment that generates a magnetic field by applying a high current to a transducer. As heat is generated from the transducer using the high current used to create the magnetic field, cooling is performed by circulating the cooling oil inside the transducer. -
Page 32: Transdducer Error
ZTone Instructions For Use 7.2 Transdducer Error The ZTone always checks the connection of the transducer cable. If the cable is disconnected or damaged, the message is shown, [Figure 16]. In this case, equipment cannot be used anymore, and the user must contact authorized personnel of our local distributor maintenance. -
Page 33: Technical Specifications
ZTone Instructions For Use 8. Technical specifications 8.1 Size and weight ❏ Size : 570 (L) × 700 (W) × 1180 (H) mm ❏ Weight : Approximately 81 kg (No Safe Working Load) 8.2 Magnetic field strength ❏ CH1 : 3.0 T – pp (±20%) ❏... -
Page 34: Faq
ZTone Instructions For Use 9. FAQ Can it be used for the area of the body with artificial joints or plate pins? Due to the nature of the magnetic field deep heat will be generated, which may cause deep-seated burns. Is it the same effect to use on clothes? One of the characteristics of a magnetic field is that it is permeable with a similar therapeutic effect. -
Page 35: Maintenance
ZTone Instructions For Use 10. Maintenance If you wish to discard the existing product after purchasing a new product from Remed Co., Ltd., we will deal with it free of charge when the new product is delivered. This device and its components must not be disposed of with household waste and must be disposed of according to professional disposal procedures. -
Page 36: Safety Inspection
ZTone Instructions For Use ❏ Daily inspections as above are recommended. 10.3 Safety inspection ❏ In order to ensure safe use, internal inspection should be performed once per year by a person authorized by the manufacturer. ❏ In order to ensure safe use, be sure to check the equipment including internal components and output voltage from the person who has been given authorization from the manufacturer once per year. -
Page 37: Troubleshooting
ZTone Instructions For Use 10.4 Troubleshooting If the equipment does not operate normally during use, please check the items listed in the table below before requesting service. If none of the following problems apply, or if the following remedies do not help, turn off the power to the equipment and contact the REMED Customer Service Center. -
Page 38: Regular Inspection For Performance Maintenance
ZTone Instructions For Use 10.5 Regular inspection for performance maintenance In order to ensure safe use, be sure to do regular inspection from the person who has been given authorization from the manufacturer once per year. 10.6 Warranty ❏ This product is manufactured through an intensive quality control and inspection process. ❏... - Page 39 ZTone Instructions For Use Customer Service Request Form The purpose of this form is to obtain information that will enable us to expeditiously process your service request. Please describe the fault or abnormality in as much detail as possible. 1. User information - Address: - User name/telephone number: (Tel :...
-
Page 40: Contact Information
ZTone Instructions For Use 11. Contact information ❏ Purchasing of product and technical inquiry REMED Co., Ltd. Address : 21-7, Wiryeseoil-ro 1-gil, Sujeong-gu, Seongnam-si, Gyeonggi-do, 13647, Republic of Korea Telephone : +82 1588-7395 : +82 31-606-5757 ❏ Customer support REMED Co., Ltd. Address : 301-303, Migun Techno World II, 187, Techno 2-ro, Yuseong-gu, Daejeon, 34025, Republic of Korea... - Page 41 ZTone non-medical Instructions for Use Distribution: Zimmer MedizinSysteme GmbH Junkersstraße 9 89231 Neu-Ulm, Germany Tel. +49 7 31. 97 61-291 Fax +49 7 31. 97 61-299 export@zimmer.de www.zimmer-aesthetics.com...
