Summary of Contents for Milesight WS523-868M-16A-EU
- Page 1 Portable Socket Featuring LoRaWAN ® WS52x User Guide Milesight IoT...
- Page 2 Safety Precautions Milesight will not shoulder responsibility for any losses or damages resulting from not following the instructions of this operating guide. The device must not be modified in any way. In order to get best data transmission, ensure the device is within the signal range of the ...
- Page 3 Revision History Date Doc Version Description August 11, 2021 V 1.0 Initial version...
-
Page 4: Table Of Contents
Contents 1. Product Introduction..........................5 1.1 Overview............................5 1.2 Features............................5 2. Hardware Introduction..........................5 2.1 Packing List............................. 5 2.2 Hardware Overview........................6 2.3 Dimensions............................6 2.4 Power Button and LED Patterns....................6 3. Operation Guide............................7 3.1 NFC Configuration.......................... 7 3.2 LoRaWAN Settings......................... 8 3.3 General Settings........................... -
Page 5: Product Introduction
LoRaWAN ® technology enables encrypted radio transmissions over long distances while consuming very little power. Also, users can check visualized data through Milesight IoT Cloud or through the user's own Application Server. 1.2 Features Plug & play experience ... -
Page 6: Hardware Overview
2.2 Hardware Overview Note: The outlook will differ according to socket types. 2.3 Dimensions (mm) Note: The plug size will a little differ according to socket types. 2.4 Power Button and LED Patterns Function Action LED Indicator Open the Supply Off →... -
Page 7: Operation Guide
1) Check the NFC area of your smartphone and it’s recommended to remove the phone case. 2) If the smartphone fails to read/write configurations via NFC, move the phone away and back to try again. 3) WS52x can also be configured on ToolBox via dedicated NFC reader provided by Milesight IoT. -
Page 8: Lorawan Settings
3.2 LoRaWAN Settings LoRaWAN settings are used to configure the data transmission parameters in LoRaWAN ® network. Basic LoRaWAN Settings: Go to Device -> Settings -> LoRaWAN Settings of ToolBox App to configure join type, App EUI, App Key and other information. You can also keep all settings by default. Parameters Description Device EUI... - Page 9 1) Please contact sales representative for device EUI list if there are many units. 2) Please contact sales representative if you need random App keys before purchase. 3) Select OTAA mode if you use Milesight IoT Cloud to manage devices. 4) Only OTAA mode supports rejoin mode.
-
Page 10: General Settings
Note: For -868M model, default frequency is EU868; For -915M model, default frequency is AU915. 3.3 General Settings Go to Device -> Settings -> General Settings of ToolBox App to change the reporting interval, etc. -
Page 11: Maintenance
Change the password for ToolBox App to write this device. 3.4 Maintenance 3.4.1 Upgrade 1. Download firmware from www.milesight-iot.com to your smartphone. 2. Open ToolBox App and click “Browse” to import firmware and upgrade the device. Note: 1) Operation on ToolBox is not supported during upgrade. -
Page 12: Backup
3.4.2 Backup WS52x supports configuration backup for easy and quick device configuration in bulk. Backup is allowed only for devices with the same model and LoRaWAN frequency band. 1. Go to “Template” page on the App and save current settings as a template. You can also edit the template file. -
Page 13: Reset To Factory Default
1 Byte N Bytes 1 Byte 1 Byte M Bytes 1 Byte For decoder examples you can find at https://github.com/Milesight-IoT/SensorDecoders. 4.1 Basic Information WS52x reports basic information of device every time when it joins the network. Channel Type Description 01(Protocol Version) 01=>V1... -
Page 14: Sensor Data
Channel Type Value Channel Type Value 0103 (Hardware 0100 (V1.0) (Software (V1.3) Version) Version) Channel Type Value Channel Type Value 01=>Enabled 01=>Enabled (Overcurrent (Overcurrent 0a=10A 0a=10A Alarm) Protection) Channel Type Value Channel Type Value 25(Button 26 (Power 01=>Enabled Lock) 80=>Enabled Consumption) 4.2 Sensor Data WS52x reports electrical data according to reporting interval (20 mins by default) or when... -
Page 15: Downlink Commands
4.3 Downlink Commands WS52x supports downlink commands to configure the device. Application port is 85 by default. Channel Type Description 00 00 ff-close, 01 00 ff-open 03 (Set Reporting Interval) 2 Bytes, unit: s Byte 1: 00 Byte 2-3: delay time, unit: s 22 (Add Delay Task) Byte 4: 10-close, 11-open Note:... - Page 16 3. Add a delay task: open the socket after 1minute ff22003c0011 Channel Type Value Byte 1:00 (Add Delay Byte 2-3: 3c 00=>00 3c=60s=1min Task) Byte 4: 11=>open 4. Delete the delay task ff2300ff Channel Type Value 23(Delete Delay 00ff Task) 5.
