100BASE-FX Fast Ethernet Module
• The Module is a slide-in module for the expansion
slot of 10/100Mbps NWay Ethernet Switch.
• This Module is a 100Base-FX module with SC or ST
type connector.
•
The maximum cable distance is 420 meters in half-
duplex mode and 2Km in full-duplex mode.
SC Type
Module Description
ST Type
Advertisement
Table of Contents
Related Manuals for TRENDnet TE100-SFXM
Summary of Contents for TRENDnet TE100-SFXM
-
Page 1: Installation Guide
Installation Guide 100BASE-FX Fast Ethernet Module • The Module is a slide-in module for the expansion slot of 10/100Mbps NWay Ethernet Switch. • This Module is a 100Base-FX module with SC or ST type connector. • The maximum cable distance is 420 meters in half- duplex mode and 2Km in full-duplex mode. - Page 2 (1) Set the operating mode of this module (full-duplex or half-duplex mode). (2) Turn off the power of the Switch. (3) Remove dust cover plate. (4) Insert the module into the module bay (follow the plastic guide rails in the module bay).
