- Page 1 GD10 Installation Guide Operating Instructions Warranty...
-
Page 2: Table Of Contents
During the installation of this appliance, it may be necessary to manually handle heavy components (greater than 25kg). It is the installer’s responsibility to ensure appropriate manual-handling techniques are employed. NOTE: This GD10 appliance is fitted with an Oxyprotector (Oxygen depletion) pilot. Under NO circumstances should this pilot be replaced or removed. -
Page 3: Step 1: Ensure All Components Are Correct And Undamaged
Step 1: Unpack and ensure all components are correct and undamaged • Appliance. • Weather cover. • Box of firebed mediums. Step 2: Install plinth (if required) • If the table is to sit on a plinth, ensure it is capable of supporting a 200kg load. -
Page 4: Burner Tray Removal Process
Pilot cover • Remove the stainless steel burner end caps (3 x screws on GD10 Burner end caps each cap) at either end of the burner tray. This model has two end cap covers, one at each side of the burner. -
Page 5: Burner Tray Installation Process
This model has one pilot cover. Pilot cover GD10 Burner end caps • Replace the stainless steel burner end caps (3 x screws on each cap) at either end of the burner. This model has two end cap... -
Page 6: Weather Housing
Weather Housing • The gas supply pipe will need to be run into the weather housing under the burner, as this is where the copper tube with the gas supply connects to the burner. • The electrical supply cable will need to be run into the weather housing (must be a minimum of 1.0mm 4- core cable), ensure 1000mm of cable is at the centre of the cavity, as this is where it will connect to the burner. - Page 7 • Locate appliance into position and ensure that it complies with the minimum clearances required (500mm for combustibles) to the surrounding enclosure. The exception to these minimum clearances is the base and the front surround panels of the fire, the base can safely sit directly upon combustible (e.g. timber) and non- combustible (e.g.
-
Page 8: Step 4: Connect And Test Electrical Supply
After approximately five seconds, the pilot will spark. Because the gas supply is turned off, the pilot will spark for approximately five seconds then automatically switch off. • NOTE: GD10 models have both LOW and HIGH settings. • Switch to HIGH setting. Ensure that a red light appears on the electrical connections block. - Page 9 Version: July 2019...
-
Page 10: Step 5: Connect Gas Supply And Commission
Test/adjust high first and then the low pressures against rating plate specifications. • In the unlikely event that the rating plate is not attached, Do Not commission the appliance and contact ‘The Fire Dept.’ immediately. • Switch the appliance off. •... -
Page 11: Step 6: Lay The Firebed
Step 6: Lay the firebed • The GD10 Recessed Burner has three firebed options: River Rocks, Beach Driftwood & Forest Logs. • Particular care should be taken when placing the chosen firebed mediums into the burner tray. Failure to place the medium correctly may result in the appliance performing inefficiently. - Page 12 How to lay clay balls • Beginning in the middle at the back of the burner, carefully empty the bags of clay balls into the burner tray. • Ensure not to spill any clay balls in cavities in front of and behind burner tray. •...
-
Page 13: How To Lay River Rocks Firebed
How to lay River Rocks Firebed – GD10 1200 • Lay large rocks first, in these positions. • Lay small rocks next, in these positions. • Switch the appliance on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully. - Page 14 How to lay River Rocks Firebed – GD10 1400 & 2000 • Lay large rocks first, in these positions. • Lay small rocks next, in these positions. • Switch the appliance on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully.
-
Page 15: How To Lay Beach Driftwood Firebed
How to lay Beach Driftwood Firebed – GD10 1200 • Lay logs and large rocks first, in these positions. • Lay rocks next, in these positions. • Switch the appliance on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully. - Page 16 How to lay Beach Driftwood Firebed – GD10 1400 & 2000 • Lay logs and large rocks first, in these positions. • Lay rocks next, in these positions. • Switch the appliance on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully.
-
Page 17: How To Lay Forest Logs Firebed
How to lay Forest Logs Firebed – GD10 1200 • Lay logs and large rocks first, in these positions. • Lay rocks next, in these positions. • on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully. - Page 18 How to lay Forest Logs Firebed – GD10 1400 & 2000 • Lay logs and large rocks first, in these positions. • Lay rocks next, in these positions. • Switch the appliance on at ‘HIGH’ setting to check how flame looks. The flame will take 10-20 seconds to light fully.
-
Page 19: Step 7: Show Owner How To Operate Appliance
Step 7: Show owner how to operate appliance • Following the GD10 Operating Instructions on the next page, show the owner how to switch the appliance on and off, and how to switch between high and low settings. • If the owner is not available, leave this manual by the appliance. -
Page 20: Operating Instructions
GD10 OPERATING INSTRUCTIONS This GD10 appliance has been designed to be simple to use. It is controlled by a wall switch, which must be installed by a qualified electrician To start appliance: • Press the on/off switch to the ON position. -
Page 21: Warranty
(G) The product contains fire bricks and has not been subjected to the recommended first start-up and run-in procedure. (H) Used in conjunction with any equipment or parts or as part of a system not manufactured or supplied by ‘The Fire Dept.’.
