- Page 1 User Manual 50” Ultra HD Smart TV MODEL: AK5020NF...
-
Page 2: Welcome
Please take special note of any important safety and usage information presented with the symbol. All products brought to you by AKAI are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty. -
Page 3: Table Of Contents
Contents Welcome Networking TV Guide Connecting to a Wireless Network 17 Contents Recording Connecting to a Wired Network Recording Live TV Unpack and Prepare TV Setting Menus Scheduled Recording What's in the box Picture Playback Important Tips Audio Pause Live TV (Time-shift) Attaching the stand General USB Mode... -
Page 4: Unpack And Prepare
Unpack and Prepare See the inside flap of the box for how to handle the TV without damaging it! What's in the box Before installing your new TV, check you have everything needed. In the box you will find: A. 50" Ultra HD Smart TV B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the stand • This TV is heavy! We recommend asking someone to help you lift it. • Unplug the TV from the power outlet before installing or removing the stand. • Only touch the frame, not the screen. • It is highly recommended to use safety straps for securing the TV. -
Page 7: Wall-Mounting The Tv
Wall-mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 200mm • VESA Mounting Bracket • 4 x M6*10mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your antenna Free-to-air TV in HD (High Definition) High Definition (HD) channels... -
Page 9: Controls And Connections
Controls and Connections Get to know your TV On/Standby light and Remote sensor Buttons on the TV • When the TV is on standby, press this button to turn the TV on. • When the TV is on, press to turn the TV off. Bottom view See next page for more info on the connections. -
Page 10: Ports On The Tv
Ports on the TV Connect to your headphones, amplifier or audio device, using an Headphone Jack AUX cable (not included). HDMI All-digital connection between the TV and any HDMI device. Use a high-speed Supports Ultra HD resolution. Requires a high-speed HDMI cable HDMI cable for (not included). - Page 11 AUDIO HDMI IN 1 HDMI IN 2 PC IN Connect an external digital audio device. Use an Optical cable (not OPTICAL AUDIO included) to connect the unit with an amplifier, soundbar or other audio decoding device for digital audio signal output. Connect to your broadband modem using a network cable (not included) for the best streaming experience.
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the AAA size polarity markings (+/-) inside the compartment. Make batteries sure the batteries are correctly aligned and properly included pushed into place. Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor Remote Hints and Tips at the front of the TV. The remote will not operate if its • Do not drop, step on or path is blocked. otherwise impact the remote The remote has a range of up to about 5 metres from control. -
Page 14: Buttons On The Remote
Buttons on the Remote (ON): Switch the TV to On or Standby (MUTE): Mute or restore sound NUMBER BUTTONS: Key in a TV channel : Return to the previous viewing number channel CH.LIST: Display or exit the channel list APPS: Direct access to YouTube, Toon Goggles, Foxxum and Netflix app MENU: Access streaming apps, TV settings... - Page 15 INFO: Display program information : Turn the volume up or down : Go to the next or previous channel GUIDE: Launch the TV Guide (DTV) : Skip forwards : Skip backwards : Fast forward / TIMESHIFT: Play/Pause live TV and video playback.
-
Page 16: On-Screen Set Up
On-Screen Set Up Make sure the TV is plugged in at the power socket and switched on. Press the (ON) button to Make sure equipment is properly connected (as shown on pages turn on the TV. 10-11) before connecting the TV to power. On/Standby light is RED in standby mode. -
Page 17: Networking
Networking You can set up your TV so that it can access the Internet through your home network using a wired or wireless connection. Connecting to a Wired Network Connecting to a Wireless Network • Connect an ethernet cable to the LAN port on the back of •... -
Page 18: Tv Setting Menus
TV Setting Menus Once you have programmed MENU any settings, the unit will retain them in its memory Menu Navigation Buttons until you change them, even after turning the TV off. Press the MENU button and select TV Settings. See the guide below for all the other buttons you'll need to use Menus Index to adjust and change your settings. - Page 19 General Time Channel • OSD Language • Sleep Timer • Auto Scan • Subtitle Language • Auto Standby • DTV Manual Tuning • Audio Language • OSD Active Time • Program Edit • Hearing Impaired • Time Zone • Channel List •...
-
Page 20: Picture
Picture Picture Mode Dynamic : Brighter and clearer picture settings for bright viewing environments. Dynamic Standard : Picture setting for general viewing environments and is energy efficient. Dynamic Movie : Settings are optimised for viewing movies. Dynamic : Adjust settings to best suit your viewing environment and content. User User Mode settings To adjust the brightness, change the Picture Mode Option... - Page 21 Colour Temp Adjust the on-screen colour temperature. Advanced Options Option Description Adjust the screen brightness by adjusting the backlight. The closer to 100, Backlight the brighter the screen. Noise Reduces screen noise/static. Reduction Open HDR Select high-dynamic range setting (TV must be receiving an HDR signal for this setting to be active.) TV SETTING MENUS | 21...
-
Page 22: Audio
Audio Option Description Sound Mode Movie Adjust the bass and treble. When changed, the sound mode will turn to Bass/Treble 'User' Automatically. Balance Adjust the audio output between the left and right speakers. Auto Volume Set auto volume to on or off. Set the audio out signal of the TV to match the sound capabilities of the Digital Audio Ouput connected external audio system. -
Page 23: General
General Option Description OSD Language Select the system language Select your preferred subtitle language. (Available for digital channels, depending on the Subtitle Language program). Select your preferred audio language. (Available for digital channels, depending on the Audio Language program.) Hearing Impaired Turn on/off hearing impaired function Transparency Turn on/off transparency effect of OSD menu... - Page 24 Option Description PVR Option See page 25 for more information. Restore the system settings to the factory default. When the restore is complete, the TV will Restore Default enter standby mode. Software Update (USB) Update the TV software via USB. View End User License View the usage license.
-
Page 25: Pvr Option
PVR Option To make changes to PVR (Personal Video Recording), ensure your USB drive is inserted into the TV. Check the troubleshooting section if you're having problems setting up your USB device. Option Description Recorded list Display and play recorded programs. Record Schedule a recording. - Page 26 INLINK (HDMI CEC) Setup This feature allows for your TV and your connected HDMI device to be controlled by one remote control. It also means you can turn them both on or off simultaneously. Press the SOURCE button on the TV or remote control to select the HDMI input source. Option Description HMDI CEC...
-
Page 27: Time
Time Option Description Sleep Timer Select the desired Auto Sleep (Standby) duration. Turn On/Off to set the TV to sleep after selected time of no user Auto Standby operation. OSD Active Time Select desired OSD menu active time. Time Zone Adjust your time zone. -
Page 28: Network
Network Option Description Select the network type (Wired/Wireless). • Wired: • Auto connect - select to connect directly • Manual connect - select to connect manually by entering the network address manually Network Type • Disable connect - disable current network connection. •... -
Page 29: Lock
Lock 0000 Factory Password: Enter the factory password '0000' using the number buttons 8899 Master Password: on the remote and select 'OK' on-screen. If you changed your password but forgot it, you can still use the master password. Option Description Change Input a new password using the number buttons on the remote and confirm to set Password... -
Page 30: Channel
Channel Option Description Automatically tunes all available free-to-air TV channels. Adjust settings (default settings Auto Scan are set for Australia), select 'Auto scan' and press OK. DTV Manual Tuning Manually select the broadcast channel frequency and tune digital TV channels. Program Edit See the next page for more information. - Page 31 Program Edit Press MENU then select Channel > Program Edit then use the buttons to highlight a channel. Option Description Delete RED to delete the highlighted channel. Press Skip BLUE to skip the highlighted channel. Press Favourite / FAV to add the channel to the Favourites list. Press Menu Press MENU to go back.
-
Page 32: App Settings
App Settings Under this setting, you can configure the settings of the Netflix app. Option Description Deactivate App Select to deactivate the Netflix app. Terminate App Select to Terminate Netflix app. Netflix Version Current version of Netflix app. 32 | TV SETTING MENUS... -
Page 33: High Dynamic Range (Hdr)
High Dynamic Range (HDR) About the HDR feature High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are perceived in real life by the human eye. By using this feature, the TV can reproduce greater dynamic range of luminosity by capturing and then combining several different exposures. -
Page 34: Smart Tv
Smart TV Applications Smart TV • Netflix • Zeasn app store Before you start using apps, your TV must be • YouTube • NetRange app portal connected to the internet. • Twitter • Foxxum app portal The speed of your internet connection determines •... -
Page 35: App Portals
App Portals Netflix is a streaming service that offers unlimited NetRange, Foxxum and Zeasn app portals gives viewing of a wide variety of award-winning TV shows, you access to number of other content and service movies and documentaries. providers. A paid subscription is required. Some apps may require a paid subscription. -
Page 36: Tv Guide
TV Guide (Free to air TV) TV Guide Functions Function Remote Button Select a channel or program GUIDE Schedule selected program for recording / RED Display program guide of previous day / GREEN To access the TV guide, press the / YELLOW Display program guide for next day. -
Page 37: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 38: Recording Live Tv
Recording, scheduled recording and pause live Before you can record with this TV TV functions only work in DTV mode (free-to-air). (including time-shift recording), you must insert your USB storage device into the USB port. Recording Live TV SOURCE Start Recording Press /RECORD to start recording. -
Page 39: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause Temporarily pause the live TV signal, then resume live TV functions only work in DTV mode playback at your convenience. (free-to-air). Before you can record with this TV (including time-shift recording), you must insert your USB storage device into the SOURCE USB port. -
Page 40: Usb Mode
USB Mode Set up Insert your USB into a USB port on the TV. Press the SOURCE button to select 'Media' mode. Function Remote Button Navigate media categories and file system You can only play Photos in the Photo category and Music in the Music category. - Page 41 Playback Functions Playback of different media types have different controls. Photo Music Function Remote Button Function Remote Button Navigate to a folder or file Navigate to a folder or file Select files Select tracks Display a photo Play a track / TIMESHIFT / TIMESHIFT Fast forward or rewind the track...
-
Page 42: Troubleshooting
Troubleshooting If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution Make sure that the batteries are installed with their poles (+/–) in the correct direction. Remove any obstacles between the remote control and remote control sensor on the TV. - Page 43 Problem Solution Ensure that connection to the device is correct and that all cables are fully inserted. Remove and reconnect all cables connected to the TV and the external devices. Try new cables if possible. There is no picture/ Restart the connected devices by unplugging each device's power cord and then plugging it in again. sound or distorted If "No Signal"...
- Page 44 Problem Solution When using Wi-Fi, make sure the Wi-Fi password is entered correctly. Turn off the access point. Wait for 2 minutes and then turn them back on. Ensure that there are no obstacles between the TV and the access point. (The Wi-Fi strength can be decreased by appliances, cordless phones, stone walls etc.) Reduce interference by not using or turning off other wireless devices.
-
Page 45: Specifications
Specifications Active screen size With stand: 1160.2 x 125.73cm (diagonal) 226.3 x 708.9 mm Dimensions (W x D x H) 3840 x 2160 Resolution Without stand: 1123.5 x 77.6 x 649.1 mm 16:9 Aspect ratio 8.7kg 60Hz Refresh rate Weight Gross 12.2kg HDMI version... -
Page 46: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a suffocation hazard for babies and young children, National Television and Computer Recycling Scheme please ensure all packaging materials are out of The careful disposal of e-waste is important... - Page 47 Notes...
- Page 48 For Technical and Warranty Support 1300 886 649 www.tempo.org info@tempo.org Distributed by Tempo (Aust) Pty Ltd, PO Box 6056, Frenchs Forest DC 2086...
