BIOS User Guide
H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0
BIOS Update ������������������������������������������������������������������������������������� 2
UEFI BIOS Setup �������������������������������������������������������������������������������� 6
A�I FAN Control ��������������������������������������������������������������������������������� 7
1� Main Menu ����������������������������������������������������������������������������������� 8
2� Advanced Menu ���������������������������������������������������������������������������� 9
3� Chipset Menu �������������������������������������������������������������������������������23
4� Boot Menu �����������������������������������������������������������������������������������27
5� Security Menu ������������������������������������������������������������������������������30
6� Tweaker Menu �����������������������������������������������������������������������������33
7� Save & Exit Menu �������������������������������������������������������������������������46

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H510MX/E 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar H510MX/E 2.0

Summary of Contents for Biostar H510MX/E 2.0

  • Page 1: Table Of Contents

    BIOS User Guide H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 BIOS Update ������������������������������������������������������������������������������������� 2 UEFI BIOS Setup �������������������������������������������������������������������������������� 6 A�I FAN Control ��������������������������������������������������������������������������������� 7 1� Main Menu ����������������������������������������������������������������������������������� 8 2� Advanced Menu ���������������������������������������������������������������������������� 9 3� Chipset Menu �������������������������������������������������������������������������������23 4� Boot Menu �����������������������������������������������������������������������������������27 5�...

  • Page 2: Bios Update

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIO-Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 3 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system. 8. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 4 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 5 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.

  • Page 6: Uefi Bios Setup

    UEFI BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. UEFI BIOS determines what a computer can do without accessing programs from a disk.

  • Page 7: A�I Fan Control

    H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 A�I FAN Control Press <F5> to display the A.I FAN Control menu. 1� CPU FAN/ System1/ System2: Click button to set the status value of CPU and system fan. 2� PWM/ Temperature Panel: According to the fan PWM value corresponding to CPU and system temperature to adjust the fan speed.

  • Page 8: 1� Main Menu

    1� Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information It shows system information including UEFI BIOS version, Project Code, Model Name, Build Date and etc.

  • Page 9: 2� Advanced Menu

    H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 2� Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note   » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. Connectivity Configuration This item shows Configure Connectivity related options.
  • Page 10 Preboot BLE This item enables or disables Preboot Bluetooth function. Options: Disabled (Default) / Enabled Note   » The following items appear only when you set the Preboot BLE function to [Enabled]. BLE Reconnection Delay This item Delay prior to connecting BLE host controller. Value between 0-1000ms. Default is 100ms.
  • Page 11 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 CPU Configuration This item shows CPU Information Overclocking Lock This item enables or disableds Overclocking Lock. Options: Disabled (Default) / Enabled Hardware Prefetcher This item to turn on/off the MLC streamer prefetcher. Options: Enabled (Default) / Disabled Adjacent Cache Line Prefetch This item to turn on/off prefetching of adjacent cache lines.
  • Page 12 Hyper-Threading This enables or disables Hyper-Threading Technology. Options: Enabled (Default) / Disabled This item sets CPU Advanced Encryption Standard instructions. Options: Enabled (Default) / Disabled SATA and RST Configuration The BIOS will automatically detect the presence of SATA devices. There is a sub-menu for each SATA device.
  • Page 13 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Trusted Computing Security Device Support This item enables or disables BIOS support for security device. O.S will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Options: Enabled (Default) / Disabled SHA-1 PCR Bank This item enables or disables SHA-1 PCR Bank.
  • Page 14 Endorsement Hierarchy This item enables or disables Endorsement Hierarchy. Options: Enabled (Default) / Disabled TPM2�0 UEFI Spec Version This item allows you to select the TCG2 Spec Version Support. TCG_1_2: the compatible mode for Win8/ Win10; TCG_2: Support new TCG2 protocol and event format for Win10 or later. Options: TCG_2 (Default) / TCG_1_2 Physical Presence Spec Version This item select to tell O.S.
  • Page 15 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 PS2 Keyboard PowerOn This item allows you to control the keyboard power on function. Options: Disabled (Default) / Any Key / Stroke Key / Specific Key Stroke Keys This item will show only when Keyboard PowerOn is set “Stroke Key.” Options: Wake Key (Default) / Power Key / Ctrl+F1 / Ctrl+F2 / Ctrl+F3 / Ctrl +F4 / Ctrl+F5 / Ctrl+F6 Specific Key This item will show only when Keyboard PowerOn is set “Specific Key.”...
  • Page 16 Super IO Configuration Serial Port 1 Configuration Serial Port This item enables or disables serial Port. Options: Enabled (Default) / Disabled Change Settings This item allows you to select an optimal settings for Super IO Device. Options: Auto (Default) / IO=3F8h; IRQ=4 / IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 / IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 / IO=3E8h;...
  • Page 17 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 H/W Monitor A�I TP Control This item enabled or disabled A.I TP Control. Options: Enabled (Default) / Disabled High Limit Temperature Options: 92 (Default) Base Limit Temperature This item enabled or disabled A.I TP Control. Options: 87 (Default) Shutdown Temperature This item allows you to set up the CPU shutdown Temperature.
  • Page 18 PCI Subsystem Settings Above 4G Decoding This item enables or disables Above 4G Decoding. Globally enables or disables 64 bit capable Devices to be Decoded in Above 4G Address Space (Only if System Supports 64 bit PCI Decoding). Options: Enabled (Default) / Disabled Re-Size BAR Support If system has Re-Size BAR capable PCIe Devices, this option Enables or Disables Resizable BAR Support (Only if System Supports 64 bit PCI Decoding).
  • Page 19 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 USB Configuration Legacy USB Support The item allows you to enable Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Options: Enabled (Default) / Disabled / Auto XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
  • Page 20 Device power-up delay Maximum time the device will take before it properly reports itself to the Host Controller. “Auto” uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. Options: Auto (Default) / Manual Note  ...
  • Page 21 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 IPv4 HTTP Support This item enables or disables IPv4 HTTP Boot Support. If disabled IPv4 HTTP boot support will not be available. Options: Disabled (Default) / Enabled IPv6 PXE Support This item enables or disables IPv6 PXE Boot Support. If disabled IPv6 PXE boot support will not be available.
  • Page 22 Offboard PCIe SATA Controller 22 | 2. Advanced Menu...

  • Page 23: 3� Chipset Menu

    H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 3� Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components.
  • Page 24 Internal Graphics This item keeps IGFX enabled based on the setup options. Options: Auto (Default) / Disabled / Enabled Primary Display This item selects which of IGFX/PEG/PCI Graphics device should be Primary Display or select SG for Switchable Gfx. Options: Auto (Default) / IGFX / PEG / PCI GTT Size This item selects GTT Size.
  • Page 25 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 M2_64G MAX Link Speed Configure M2_64G Max Speed. Options: Auto (Default) / Gen1 / Gen2 / Gen3 / Gen4 PCH-IO Configuration PCI Express Configuration HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be unconditionally enabled.
  • Page 26 ErP Control When ErP is enabled, the system will meet ErP requirement. Options: Disabled (Default) / Enabled in S4-S5 BIOS Lock This item enables or disables the PCH BIOS Lock Enable feature. Required to be enabled to ensure SMM protection of flash. Options: Enabled (Default) / Disabled Onboard Device Onboard LAN1...

  • Page 27: 4� Boot Menu

    H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 4� Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting.
  • Page 28 Fast Boot This item enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. Options: Disabled (Default) / Enabled Note   » The following items appear only when you set the Fast Boot function to [Enabled] SATA Support If Last Boot HDD Only, Only last boot HDD device will be available in post.
  • Page 29 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Network This option controls the execution of UEFI and Legacy Network OpROM Options: Legacy (Default) / UEFI / Do not launch Storage This option controls the execution of UEFI and Legacy Storage OpROM Options: Legacy (Default) / UEFI / Do not launch Video This option controls the execution of UEFI and Legacy Video OpROM...

  • Page 30: 5� Security Menu

    5� Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Menu 30 | 5. Security Menu...
  • Page 31 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Secure Boot Secure Boot feature is active if Secure Boot is enabled, Platform Key(PK) is enrolled and the system is in user mode. The mode change requires platform reset. Options: Disabled (Default) / Enabled Secure Boot Mode Secure Boot mode options : Standard or Custom.
  • Page 32 Remove ‘UEFI CA’ from DB Device Guard ready system must not list ‘Microsoft UEFI CA’ Certificate in Authorized Signature database(db). Restore DB defaults Restore DB variable to factory defaults. Platform Key (PK) Options: Details / Export / Update / Delete Key Exchange Keys Options: Details / Export / Update / Append / Delete Authorized Signatures...

  • Page 33: 6� Tweaker Menu

    H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 6� Tweaker Menu This submenu allows you to change voltage and clock of various devices. Note   » We suggest you use the default setting. Changing the voltage and clock improperly may damage the device.
  • Page 34 Ring Max OC Ratio This sets the maximum overclocking ratio for the CPU Ring. Memory Profile Select DIMM timing profile. The below values start with the currently running values and don’t auto populate. Options: Default profile (Default) / Custom profile / XMP Profile 1 Note  ...
  • Page 35 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 tCWL This item allows you to select Min CAS Write Latency Delay Time, 0: AUTO, max: 34 Options: Auto (Default) tFAW This item allows you to select Min Four Activate Window Delay Time, 0: AUTO, max: 127 Options: Auto (Default) tREFI This item allows you to select Refresh Interval, 0: AUTO, max: 65535...
  • Page 36 Turn Around Timing tRD2RD_SG This item delay between Read-to-Read commands in the same Bank Group, Range 4-54. Options: Auto (Default) tRD2RD_DG This item delay between Read-to-Read commands in different Bank Group for DDR4. All other DDR technologies should set this equal to SG. 0-Auto, Range 4-54. Options: Auto (Default) tRD2RD_DR This item delay between Read-to-Read commands in different Ranks.
  • Page 37 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 tWR2RD_DG This item delay between Write-to-Read commands in different Bank Group for DDR4. All other DDR technologies should set this equal to SG. 0-Auto, Range 4-54. Options: Auto (Default) tWR2RD_DR This item delay between Write-to-Read commands in different Ranks. 0-Auto, Range 4-54. Options: Auto (Default) tWR2RD_DD This item delay between Write-to-Read commands in different DIMMs.
  • Page 38 tWRPRE This item Holds DDR timing parameter tWRPRE. WR to PRE same bank minimum delay in tCK cycles. Supported Range is 18-159. Options: Auto (Default) This item Holds DDR timing parameter txP. Power up to any command minmum delay in tCK cycles Supported Range is 4-16.
  • Page 39 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 tZQCS This item for DDR4 holds tCK value in DCLK cycles. Options: Auto (Default) Misc Configuration RttWr Options: Auto (Default) RttNom Options: Auto (Default) RttPark Options: Auto (Default) Rank Interleave Options: Enabled (Default) / Disabled Enhanced Interleave Options: Enabled (Default) / Disabled 6.
  • Page 40 ODT Delay Duration Configuration ODT Read Duration This item allows you to controls the length of the ODT pulse for read commands. Default is 6 DCLK cycles (BL / 2 +2) Options: Auto (Default) ODT Read Delay This item allows you to controls delay from RD-CAS to ODT assertion in DCLK cycles. Options: Auto (Default) OODT Write Duration This item allows you to controls the length of the ODT pulse for write commands.
  • Page 41 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Voltage Configuration BCLK Aware Adaptive Voltage This item enables or disables BCLK Aware Adaptive Voltage. When enabled, pcode will be aware of the BCLK frequency when calculating the CPU V/F curves. This is ideal for BCLK OC to avoid high voltage overrides.
  • Page 42 Intel Speed Optimizer (ISO) This item allows you to sets Intel Speed Optimizer (ISO). When enabled Intel Speed Optimizer (ISO) feature will automatically overclocks your processor and depends on Board thermal design. Options: Supported (Default) / Unsupported Intel(R) SpeedStep(tm) This item allows more than two frequency ranges to be supported. Options: Enabled (Default) / Disabled Power Limit 1 Override This item enables or disables Power Limit 1 Override.
  • Page 43 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Package C-State Demotion This item sets Package C state Demotion. Options: Enabled (Default) / Disabled Package C-State Un-demotion This item sets Package C-State Un-demotion. Options: Enabled (Default) / Disabled CState Pre-Wake Disable - Sets bit 30 of POWER_CTL MSR(0x1FC) to 1 to disable the Cstate Pre-Wake. Options: Enabled (Default) / Disabled IO MWAIT Redirection This item enableds or disableds IO MWAIT Redirection.
  • Page 44 GT Power Management RC6(Render Standby) This item enables or disables Render Standby. Options: Enabled (Default) / Disabled Maximum GT frequency This item maximum GT frequency limited by te user. Value beyond the range will be clipped to min/max supported by SKU. Disable Turbo GT frequency This item Disable Turbo GT frequency.
  • Page 45 H510MH 2�0 | H510MX/E 2�0 | H510MH/E 2�0 Memory Insight DIMM Profile These items display memory information. 6. Tweaker Menu | 45...

  • Page 46: 7� Save & Exit Menu

    7� Save & Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup. Save Changes and Reset Reset the system after saving the changes.
