- Page 1 USER MANUAL [ FC U - F LO OR CEIL ING ] FP-xxZD-K(E) ORIGINAL INSTRUCTIONS, VER. 01 2019-11-18...
- Page 2 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 3 To Users Thank you for selecting Gree’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below: (1) This equipment should be installed, operated or maintained by the qualified servicemen who have had specific training.
-
Page 4: Table Of Contents
Contents Safety Notices (Please be sure to abide ) .............. 1 1 Product Introduction ..................... 5 1.1 Working Principle......................5 1.2 Main Parts ........................5 1.3 Working Conditions ......................5 2 Unit Installation ...................... 6 2.1 Installation Environment ....................6 2.2 Precautions for Installation .................... -
Page 5: Safety Notices (Please Be Sure To Abide )
Floor and Ceiling FCU Safety Notices (Please be sure to abide ) WARNING: If not abide strictly, it may cause severe damage to the unit or the people. NOTE: If not abide strictly, it may cause slight or medium damage to the unit or the people. This sign indicates that the operation must be prohibited. - Page 6 Please contact insulated so as to prevent from GREE after-sales center and dewing in summer. repair should be done by the qualified servicemen.
- Page 7 The connection line should once, and then contact GREE not suffer external forces. For a f t e r - s a l e s s e r v i c e m e n . I f...
- Page 8 Floor and Ceiling FCU This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial or household use by lay persons. Installing the unit in the following places may cause malfunction. If it is unavoidable,please consult the local dealer: (1) The place with strong heat sources,vapors, flammable or explosive gas,or volatile objects spread in the air.
-
Page 9: Product Introduction
Floor and Ceiling FCU 1 Product Introduction 1.1 Working Principle The cold (hot) water entering the heat exchanger will do heat exchanging with air passing through the surface of the heat exchanger to condition the air temperature and humidity. There is no (cold) hot source for this product itself. -
Page 10: Unit Installation
Floor and Ceiling FCU water temperature, even cold water flow. y Dewing condition: 27°C dry bulb temperature, 24°C wet bulb temperature, 6°C entering water temperature, and 9°C leaving water temperature 2 Unit Installation 2.1 Installation Environment (1) There should be no direct sunlight. (2) The hanger, ceiling and the building structure should be capable of supporting the weight of the unit. -
Page 11: Outline Dimensions
Floor and Ceiling FCU 2.3 Outline Dimensions 4- Ø16 (160) Mounting Hole G(water inlet pipe G3/4") H(water outlet pipeG3/4") Unit: mm. TYPE TYPE FP-34WM FP-34ZD (130) (215) FP-51WM FP-51ZD (130) (215) FP-68WM FP-68ZD (130) (215) FP-85WM FP-85ZD (130) (215) FP-102WM FP-102ZD 1300 1202... -
Page 12: Installation And Maintenance Space
Floor and Ceiling FCU 2.4 Installation and Maintenance Space 150cm or more 60cm or more INSTALLATION PAPER PLANK 60cm or more 100cm or more 30cm or more 2.5 Installation of Inlet and Outlet Pipes (1) Both the torque wrench and ordinary wrench should be used for installing and uninstalling the water pipes, as shown in the figure below. -
Page 13: Installation Of The Water Valve
Floor and Ceiling FCU 2.6.2 Installation Steps of the Drain Pipe (When drain hose is connected) Incling the drain hose Clamp ⑤ Not to be lifted No foldings Not to be Daping area(Gray) Drain hose ④ soaking in water Larg e seeing pa d Cramp ⑤... - Page 14 Floor and Ceiling FCU (5) When the water pipe and water valve have been installed, connect the connection line of the valve to the wiring board of the unit. (6) Check the wiring carefully and then start the water pump and unit to see if they work normally. 2.7.2 Requirements on Installation (1) The water valve should be installed as the following statement;...
-
Page 15: Electric Wiring
Floor and Ceiling FCU 2.8 Electric Wiring 2.8.1 Precautions for Electric Wiring (1) All electric wiring should be performed by the qualified technical in accordance with local standards, regulations and this manual. (2) The specialized electric circuit with rated voltage should be used for the power supply. (3) Do not pull the power lines by force. -
Page 16: Commissioning And Maintenance
Floor and Ceiling FCU 3 Commissioning and Maintenance 3.1 Inspection after Installation Item Possible Consequence Inspection T h e u n i t m a y f a l l d o w n , v i b r a t e o r Is the main unit installed securely? generate noise. -
Page 17: Troubleshooting
Floor and Ceiling FCU 4 Troubleshooting 4.1 Troubleshooting Measures Symptoms Possible Causes Corrective Measures Repower the unit when power supply is There is no power supply. available. The unit does The power plug is loosened. Tighten the power plug. not run. The motor is burnt out. - Page 18 Please ask your local council where your nearest disposal station is located. In case of quality problem or other please contact your local supplier or authorized service center. Emergency number: 112 PRODUCER GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI West Jinji Rd, Qianshan, 519070 Zhuhai China REPRESENTATIVE GREE Czech &...
- Page 19 Pro stažení manuálu k tomuto produktu Pre stiahnutie manuálu k tomuto produktu za- zadejte modelové označení do následujícího dajte modelové označenie do následujúceho odkazu. odkazu. Um das Handbuch für dieses Produkt herun- terzuladen, geben Sie bitte den Modellnamen für diesen Link ein.
