Summary of Contents for EVEBASE GO 120W
- Page 1 USER MANUAL SOLAR PANEL GO 120W / GO 200W / GO 350W...
-
Page 2: Table Of Contents
CONTENT IN THE BOX SAFETY INSTRUCTIONS GENERAL SET UP INSTRUCTION CHARGE CONTROLLER SET UP WITH A PORTABLE POWER STATION USB-PORT SET UP WITH OTHER BATTERIES TECHNICAL SPECIFICATIONS... -
Page 3: In The Box
IN THE BOX Solar Panel GO Connection Cable Multiple Connectors User Manual (5-meter) (DC/Anderson/XT-60) SAFETY INSTRUCTIONS • The installation and connection of this product should be carried out strictly in accordance with the instructions found in the user manual. • Use original or certified cables and chargers. -
Page 4: General Set Up Instruction
GENERAL SET UP INSTRUCTION 1) Unpack the solar panel at the location where it will be set up. Start with unfolding the back flip. Place the solar panel on solid ground and in the direction of the sun. 2) Unfold the solar panel and use the kick-stands at the back for support. 3) Use the kickstands at the back side of the panels to place the solar panel in the right angle. -
Page 5: Charge Controller
CHARGE CONTROLLER MENU button UP button DOWN button 1. Short press to switch between different Press to increase value. Press to decrease value. display interfaces. 2. Hold 3 seconds to Enter or Exit interface settings. Display Interfaces Description of how to cycle through the display interfaces and adjust the parameters manually: Short press the MENU button to cycle through the display interfaces. - Page 6 Overview of the display interfaces: Interface 1 Interface 2 Interface 3 Interface 4 Interface 5 Interface 6 Interface 7 Interface 8 Interface 9 Interface 10 Interface 11 Interface 1: Main interface. Interface 2: Displays the surrounding temperature of the charge controller. Interface 3: Displays the charge current from the solar panel to the connected battery.
-
Page 7: Set Up With A Portable Power Station
SET UP WITH A PORTABLE POWER STATION Solar Panel GO Power Station Devices 1. Follow the general setup instruction of the solar panel. 2. Use the 5-meter connection cable and connect this cable to the charging input port of the portable power station. - Page 8 4. Connect the 5-meter connection cable to the left DC-output port of the solar charge controller. Note: To secure a stable current it is recommended to connect the power station to the solar charge controller by using the 5-meter connection cable. However, it is also possible to connect the 1-meter solar panel cable directly to the power station.
-
Page 9: Usb-Port
USB-PORT 1. Follow the general setup instruction of the solar panel. 2. Unzip and open the controller bag. This bag is located at the back side of the solar panel. 3. Connect an USB-A cable of the device to the USB-A output port of the solar charge controller. When the devices are connected, recharging will start automatically. -
Page 10: Set Up With Other Batteries
SET UP WITH OTHER BATTERIES The solar charge controller makes this solar panel able to recharge a range of batteries. In this chapter is described how to set up the charge controller to recharge other batteries than a portable power station. Read the operation instruction in this chapter carefully before use. - Page 11 d. After selecting the correct BATTERY TYPE, hold the MENU button for 3 seconds to set the battery type. Note: The automatic memory function of this controller will set the value automatically if this is not done manually. Warning: Make sure the right battery type is selected before connecting the battery. The product and rechargeable device can get damaged when the wrong battery type has been selected.
-
Page 12: Technical Specifications
520 x 1660 x 25 mm 545 x 2405 x 55 mm 545 x 4055 x 55 mm Weight 5 kg 8 kg 13 kg EveBase Tech B.V. Oostwal 2 1747 EZ Tuitjenhorn The Netherlands support@evebase.com www.evebase.com Designed in NL. Made in PRC.
