Sonnettech Echo 13 Quick Start Manual

Triple 4k display dock

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Quick Start Guide

for Echo

Triple

™

K Display Dock

Support Note:

date at the time of printing. However,

changes to the hardware or software may have

occurred since then. Please check the Sonnet

website for the latest documentation.

1. Go to https://www.sonnettech.com/support/kb/

kb.php

2. Navigate to and click the Echo 13 Triple 4K Display

Dock link.

3. Click the Manual link.

4. Click the Echo 13 Triple 4K Display Dock User's

Guide [English] link and then check the Document

Version information. If the version listed is

later than this document (revision C), click the

Download Now button for the latest version.

This document was up to

Table of Contents

Need help?

Do you have a question about the Echo 13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sonnettech Echo 13

Page 1 Please check the Sonnet website for the latest documentation. 1. Go to https://www.sonnettech.com/support/kb/ kb.php 2. Navigate to and click the Echo 13 Triple 4K Display Dock link. 3. Click the Manual link. 4. Click the Echo 13 Triple 4K Display Dock User’s Guide [English] link and then check the Document Version information.
Page 2: Table Of Contents
Mac Compatibility Windows Compatibility Chromebook Compatibility Required Ethernet Drivers Required DisplayLink Application or Drivers 2 Echo 13 Triple 4K Display Dock Description Front Panel Back Panel Left Side Panel Right Side Panel 3 DisplayLink Software Download and Displays Configuration Steps Application Download/Installation Steps—macOS...
Page 3: Compatibility Information And Computer Preparation
For Chromebook Users: The standard drivers required to support the The correct drivers required to enable the Ethernet port on the Echo 13 Triple 4K Display dock’s DisplayLink display ports are installed Dock are installed as part of macOS 11 and later, as part of ChromeOS version 100 or later.
Page 4: Echo 13 Triple 4K Display Dock Description
2 – Echo 13 Triple 4K Display Dock Description FRONT PANEL 1 – Power Indicator This lights green when the Echo dock is switched on, and stays off when the dock is switched off. 2 – Computer Power Delivery (PD) Link Indicator This lights blue when the computer to which the dock is connected is accepting PD (charging) power from the dock.
Page 5: Left Side Panel
2 – Echo 13 Triple 4K Display Dock Description 8 – Computer/Charging Port Connect your computer to this port using the included USB-C cable. For laptop/notebook computers that support charging through a USB-C or Thunderbolt port, this port delivers up to 100W of power.
Page 6: Displaylink Software Download And Displays Configuration Steps
Notifications (or Notifications & Focus), www.sonnettech.com/support/kb/kb.php selecting DisplayLink Manager on the left and clicking the Allow Notifications toggle 2. Navigate to and click the Echo 13 Triple 4K switch on the right. Display Dock link. 9. During the installation, a pop-up regarding 3.
Page 7 In the Privacy and Security pop-up that System Settings/Preferences when displays appears, enter your password and click are connected to the Echo 13 Triple 4K Display Unlock, and then click the checkbox next to Dock DisplayLink display port(s). DisplayLink Manager.
Page 8: Connected Display Configuration Steps-Macos
Although Windows 11 and 10 include in-box DisplayLink drivers, they are not up-to-date and Connected Display Configuration Steps— will not support the Echo 13 Triple 4K Display Dock. Windows Download the latest drivers through Sonnet website. In order to prevent the out-of-date 1.
Page 9: Audio Jacks And Ethernet Port Configuration Information
4 – Audio Jacks and Ethernet Port Configuration Information Enabling the Headphones Jack—macOS 1. Connect headphones to the Headphones Jack. 2. From the Apple menu, select System Settings (or System Preferences). 3. In the System Preferences window, click Sound. In the Sound preference window, click the Output tab, and then select Sonnet TD Dock Audio.
Page 10: Tips, General Information, And Known Issues
5 – Tips, General Information, and Known Issues TIPS, GENERAL INFORMATION USB-C Computer/Charging Cable Compatibility Hot Plugging the Echo Dock You may use a USB-C cable other than the one provided in the package with the Echo dock, but You may connect and disconnect the dock while the computer is on.
Page 11: Precautions, Fcc Compliance, And Support Information
6 – Precautions, Compliance, and Support Information SAFETY PRECAUTIONS FCC Compliance Please read this section carefully before Echo 13 Triple 4K Display Dock complies proceeding. These precautions explain the with Part 15 of the FCC Rules. Operation is correct and safe use of this device, thereby...
Page 12: Contacting Customer Service
E-mail: jp.support@sonnettech.com ©2023 Sonnet Technologies, Inc. All rights reserved. Sonnet, SONNETTECH, the Sonnettech logotype, and Echo are trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, MacBook Air, MacBook Pro, and macOS are trademarks of Apple Inc., registered in the United States and other countries. Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the U.S.
