Page 3: Introduction
Introduction This document provides detailed information on the AIR-CR Controller device structure and steps for installing and connecting it. It also includes instructions for preventing or troubleshooting many common problems. This guide is for informational purposes only, and in the event of any discrepancies, the actual product takes precedence.
Page 4: Device Specifications
Device Speciﬁcations Device info • Model AIR-CR • Processor ESP32-S3 • Over-the-air (OTA) update • Built-in web server • Support for 125 kHz identiﬁers EM Marin • Support for 13.56 MHz identiﬁers MIFARE DESFire; MIFARE Plus; MIFARE Ultra Light; MIFARE Classic mini/1K/4K;...
Page 5: Device Dimensions
Device Dimensions RFID CARD 125, 65535 3.375" AIR-CR...
Page 6: Wire Designation
Wire Designation +VDC Gray GND Lock Black Orange Green LED Brown Red LED Pink Blue Exit Button AIR-CR Yellow RS-485 A+ Purple RS-485 B- Green Data 0 White Data 1 Black Blue Gray Orange White +VDC GND Lock Black Orange...
Page 7: Installation Recommendations
The power supply line wires for the reader should be kept as short as possible to avoid a signiﬁcant voltage drop across them. After cabling, ensure that the power supply voltage to the reader is at least 12 VDC with the locks switched on. AIR-CR...
Page 8: Ethernet Network (Connection Diagram)
Ethernet Network Connection Diagram +VDC +VDC Black Make sure that the power supply voltage meets the recommended requirements. Warning Blue Gray Orange White AIR-CR Cable length up to 325 feet white-orange orange white-green blue white-blue green W.Br white-brown brown RJ-45 Adapter The voltage levels of the power supply and the Controller may diﬀer depending on the cable length and the resistance of the conductor.
Page 9: Wiegand Reader (Connection Diagram)
Black Orange G LED Brown R LED Green White Blue Gray Orange White AIR-CR W. + W. Black Orange Brown Green White Yellow Black Purple AIR-R The voltage levels of the power supply and the Controller may diﬀer depending on the cable length and the resistance of the conductor.
Page 10: Open Supervised Device Protocol (Osdp) Reader (Connection Diagram) Coming Soon
Connection Diagram +VDC Black Yellow OSDP A+ Purple OSDP B- AIR-CR W. + Black Yellow Black Purple AIR-R The voltage levels of the power supply and the Controller may diﬀer depending on the cable length and the resistance of the conductor.
Page 11: Exit Button (Connection Diagram)
Exit Button Connection Diagram +VDC Black Orange G LED Blue AIR-CR W. + Black Blue TO O Green AIR-B The voltage levels of the power supply and the Controller may diﬀer depending on the cable length and the resistance of the conductor.
Page 12: Door Sensor & Magnetic Lock Connection Diagram
+VDC Gray LOCK Black Pink AIR-CR Warning Use Correct Polarity! MAX 500 mA A protective diode is used to protect the Сontroller from reverse currents when an electromagnetic or electromechanical lock is triggered. The protective diode is connected in parallel with the contacts of the lock.
Page 13: Connecting To Device
Step 3. In the address bar of your browser, enter the device IP address 192.168.1.100 and press enter. Step 4. After the page loads, enter your login and password. After login, the browser will redirect you to the Quick Start page. Login AIR-CR...
Page 14: Quick Start
Wi-Fi AP or the login password, a • B. Ethernet: reboot may be required, increasing the time until the ◦ Submit the entered information to device appears in the cloud service. conﬁrm the settings. Cloud: ◦ Enter your account ID and click “Submit.” AIR-CR...
Page 15: System
The Network subsection displays the: ◦ Device’s current network settings. ◦ Device’s network address. ◦ Network mode - Manual or Dynamic Host Conﬁguration Protocol (DHCP). ◦ Network mask. ◦ Domain Name Service (DNS). ◦ Network port of the device. AIR-CR...
Page 16: Network
• ”Wi-Fi timer” ﬁeld: sets the built-in Wi-Fi following functions: AP availability time from 1 to 60 minutes. • Select your preferred option for the built- • HTTP port: By default, the device uses in Wi-Fi AP: port 80. AIR-CR...
Page 17 Ethernet. If you connected the device to the Internet using a Wi-Fi connection, specify the connection method as Wi-Fi. • The Account ID form is used for adding to the UNIMACS cloud system, as you only need to specify the ID to connect. AIR-CR...
Page 18: Main
If there is no password or it is format. different, the identiﬁer is ignored. Thus, all identiﬁers other than encrypted ones will be ignored. AIR-CR...
Page 19 Bluetooth connections. • Check the “Reverse byte order” checkbox to change the order in which the identiﬁer code is read from the reader connected to the controller. Note: The byte order will be reversed for all identiﬁer types. AIR-CR...
Page 20: Open Supervised Device Protocol (Osdp)
ﬁeld, and you can assign a available soon. Stay tuned for updates. name and physical address to the found device. • Clicking the “Add to the device list” button will add the device to the list on the left. AIR-CR...
Page 21: Maintenance
If the update takes more than 5 minutes, forcibly reboot the device by switching off the power and trying the time you log in to the device interface. update again. A power failure or network connection interruption during the update may cause a ﬁrmware update AIR-CR...
Page 22: Hardware Reset With Wires
8. The hardware reset procedure is complete, and the device is ready for use. When performing a hardware reset, all data stored in the device memory and all related settings will be deleted. This procedure cannot be undone. Warning AIR-CR...
Page 23: Glossary
Causes an event depending on the attribute used. • External relay - Relay with potential-free dry contact for remote control of the power supply. The relay is equipped with a dry contact, which is galvanically unconnected to the power supply circuit of the device. AIR-CR...
Page 24 • Pass control - The process of regulating, monitoring, or granting permission for individuals to enter or exit a secure area. • Power supply - A device or system that provides electrical energy to other devices, enabling them to operate and function. AIR-CR...
Page 25 • Wi-Fi AP - Wireless access point. A device that allows wireless devices to connect to a network. • Wireless access control gateway - A device that manages and connects wireless access control devices to a central system or network. AIR-CR...
