Dali Wireless Transcend t43 Installation And Operation Manual

Dual-band outdoor das
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DUAL-BAND OUTDOOR DAS
Installation and Operation Manual -
Document:
Revision:
Date:
Transcend t43™
DW-010-7373-09
Preliminary
DW-ML01-010-7373-09
0-2
Nov 2011
Dali Wireless (Canada), Inc.,
8618 Commerce Court
Burnaby, BC, V5A 4N6
Dali Wireless, Inc.,
125 University Ave., Suite 88
Palo Alto, CA, 94301
CommScope v. Dali Wireless
IPR2020-01409
DALI WIRELESS Exhibit 2004
Page 1 of 61

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Transcend t43 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dali Wireless Transcend t43

  • Page 1 Installation and Operation Manual - Preliminary Document: DW-ML01-010-7373-09 Revision: Date: Nov 2011 Dali Wireless (Canada), Inc., 8618 Commerce Court Burnaby, BC, V5A 4N6 Dali Wireless, Inc., 125 University Ave., Suite 88 Palo Alto, CA, 94301 CommScope v. Dali Wireless IPR2020-01409...
  • Page 2 Dali Wireless is a registered trademark of Dali group of companies, Dali Wireless, Inc. and Dali Wireless (Canada), Inc. The Dali Wireless logo is a registered trademark of Dali group of companies, Dali Wireless, Inc. and Dali Wireless (Canada), Inc.

  • Page 3: Table Of Contents

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary TABLE OF CONTENTS Safety Precautions ............................8 Outdoor DAS Overview ............................ 9 Features and Benefits ..........................9 System Description ............................ 10 2.2.1 tHost™ Introduction ..........................11 2.2.2 t43™ Introduction ..........................16 2.2.3...
  • Page 4 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Built-In Test Functions ..........................52 6.4.1 Optical Loop-Back Function ....................... 52 6.4.2 t43™ Delay Equalization Function ..................... 52 6.4.3 M&C Communication Status – Heartbeat Function ................52 System Maintanance ............................53 Preventive Maintenance ..........................
  • Page 5 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary TABLE OF TABLES Table 2-1 tHost™ External Interfaces ........................12 Table 2-2 t43™ External Interfaces ........................17 Table 3-1 Specification for Dali Dual-Band DAS, 1900-AWS, 20 + 20 W ............. 21 Table 6-1 Optical Transport Data Rate Calculation ....................
  • Page 6 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Figure 9-2 FC Type Fiber Optic Connector ......................59 Figure 9-3 LC Type Fiber Optic Connector ......................60 Figure 9-4 ST Type Fiber Optic Connector ......................60 Dali Wireless...
  • Page 7 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary ACRONYMS AND ABBREVIATIONS Alternating Current ACLR Adjacent Channel Leakage Ratio ACPR Adjacent Channel Power Ratio Base Transceiver Station CCMF Centralized Control and Monitoring Function Central Control Unit CDMA Code Division Multiple Access...

  • Page 8: Safety Precautions

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 1 SAFETY PRECAUTIONS IMPORTANT All safety precautions should be read and understood prior to deploying the Dali Dual- Band Digital Optical Repeater. This equipment contains components that emit laser radiation which can seriously damage the retina of the eye.

  • Page 9: Outdoor Das Overview

    The system is software configurable offering seamless upgrades to the system. Dali’s Transcend t43™™ DAS model # DW-010-7373-09 is a dual band, 1900MHz/AWS unit with 20W average output power per band. This model number comprises a single tHost and a single t43 remote as representative of the entire DAS system.

  • Page 10: System Description

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2 System Description The outdoor DAS is comprised of a tHost that is connected to the RF output of the base station, and multiple t43™remotes located in areas that the base station signal cannot reach (gaps created by natural or manmade obstacles, tunnels and subways, or inside large buildings) as well as simulcast in a DAS configuration to provide optimum coverage and capacity in wireless networks.

  • Page 11: Thost™ Introduction

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Unit monitoring and control functionality is provided by proprietary software application that runs on Linux OS supported by ARM9 microprocessor. Multi-thread operation and web server access are supported by the system.

  • Page 12: Table 2-1 Thost™ External Interfaces

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2.1.1 tHost™ External Interfaces The tHost external (user) interfaces are located on the front and the back of the 19” rack mount chassis and are shown in Figure 2-4.
  • Page 13 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Green LED Band 4 UL path Green: Enabled LED OFF: Disabled LC/UPC simplex optical Single mode optical fiber interface #1 connection Orange LED left SFP mate status. Orange: The optical transceiver has mated properly.
  • Page 14 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary LC/UPC simplex optical Single mode optical fiber interface #6 connection Orange LED left SFP mate status. Orange: The optical transceiver has mated properly. LED OFF: Problem Remote synchronization status.

  • Page 15: Figure 2-4 Thost™ External Interfaces - Front (Simplex And Duplex), And Back Panel

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Figure 2-4 tHost™ External Interfaces – Front (Simplex and Duplex), and Back Panel Unit size (WxHxD) is: 482x45x400 mm / 19”x1.8”x15.7” Weight: ~ 7.5 kg /16.5 lbs Dali Wireless...

  • Page 16: T43™ Introduction

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2.2 t43™ Introduction The Dali t43™ is located close to the antenna, and hence helps reduce coaxial feedline RF losses, leading to increased system efficiency, reduced cooling requirements and small physical size.

  • Page 17: Table 2-2 T43™ External Interfaces

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2.2.1 t43™ External Interfaces The t43™ external (user) interfaces are located on the bottom of the unit and shown in Figure 2-6. Table 2-2 provides description of the t43™ external interfaces.

  • Page 18: Figure 2-6 T43™ External Interfaces

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Figure 2-6 t43™ External Interfaces Dali Wireless Rev: 0-2 Proprietary and Confidential Nov , 2011 CommScope v. Dali Wireless IPR2020-01409 DALI WIRELESS Exhibit 2004 Page 18 of 61...

  • Page 19: Figure 2-7 T43™ Chassis

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2.2.2 t43™ Mechanical Description The t43™ mechanical assembly is comprised of an environmentally sealed chassis and variety of active and passive electronic modules housed inside. The t43™ is designed for implementation in outdoor and indoor applications.

  • Page 20: Accessories

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 2.2.3 Accessories 2.2.3.1 2x2 Optical Switch In applications that include daisy-chain connection of t43™s, if one of the remote units fails, the units that are downstream will lose the signal and be out of service.

  • Page 21: Product Specification

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 3 PRODUCT SPECIFICATION The technical Specification for Dali DAS Model DW-010-7373-09 is presented in Table 3-1. Table 3-1 Specification for Dali Dual-Band DAS, 1900-AWS, 20 + 20 W Ref.

  • Page 22: Instalation Procedure

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4 INSTALLATION PROCEDURE 4.1 Pre-Installation procedure 4.1.1 Incoming Inspection 1. Inspect the exterior of the shipping box(s) for any evidence of damage that can affect units inside. If damage is found file a claim with the carrier.

  • Page 23: Optical Attenuator

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary a. Obtain a cable with two #18 AWG insulated copper wires (colored red and black) and terminate one end with a 2 socket female connector provided with the unit.

  • Page 24: T43™ Installation

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3 t43™ Installation 4.3.1 t43™ Mounting The Dali dual-band DAS is designed to be mounted on the pole, inside the pole, or on the wall. Each unit comes with a universal mounting kit. Main installation steps encompass securing the mounting bracket to the carrier surface, and then hanging and securing the unit.

  • Page 25: Figure 4-3 T43™ Mounting On A Wall

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3.1.2 t43™ Mounting On a Wall Installation steps for t43™ mounting on the wall are as follows: 1. Position support bracket on the mounting surface and mark the location of the six mounting holes;...
  • Page 26 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3.1.3 t43™ Mounting in a Shroud Figure 4-4 presents t43™ mounting in a customer supplied shroud. Dali Wireless Rev: 0-2 Proprietary and Confidential Nov , 2011 CommScope v. Dali Wireless...

  • Page 27: Figure 4-4 T43™ Mounted In The Shroud

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Figure 4-4 t43™ Mounted in the Shroud Dali Wireless Rev: 0-2 Proprietary and Confidential Nov , 2011 CommScope v. Dali Wireless IPR2020-01409 DALI WIRELESS Exhibit 2004 Page 27 of 61...

  • Page 28: Cables Installation

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3.2 Cables Installation Ensure that all low loss RF cables used to connect t43™ to the main and diversity antennas are tested and Insertion Loss and Return Loss information is logged.

  • Page 29: Figure 4-5 Outdoor Industrial Lc Adapter And Lc Cable Assembly Connectors

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3.2.3 Fiber Cable Installation The t43™ is equipped with two chassis mount, outdoor industrial LC adapters, each providing waterproof bidirectional optical interface for band 1 and 2 payload data, and M&C signals. A second optical interface enables daisy-chain networking with other t43™s.

  • Page 30: Figure 4-6 Ac Power Supply Wiring Diagram

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 4.3.2.4 AC Cable Installation The t43™ ships with a 6 m (19.7 feet) long 3-wire, indoor/outdoor cable furnished with mating 3 pin AC connector on one end, exposed on the other end for installation in the external junction box. The AC power (single phase between 100 and 240 VAC, 50 or 60 Hz) shall be supplied through a circuit breaker or fuse.

  • Page 31: Operation

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5 OPERATION This Section outlines steps for powering up the DAS system and verifying proper operation. This procedure assumes that the tHost™s and t43™s have been installed in accordance with the process outlined in Section 4.

  • Page 32: Local Access

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary t43™ 1 tHost™ SNMP Private Router Agent Network Internet Backbone t43™ 2 Embedded Remote Web Server Access to GUI using browser t43™6 Local Access to GUI using Local browser...

  • Page 33: Thost™ Network Configuration

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5.2.3 tHost™ Network Configuration T-HostQS-Cw01 T-HostQS-Cw01 T-43D-S01 Set Parameters T-43D-S02 DL Input Power Status DL Attenuation T-43D-C05 DL Input Power Low Threshold Status T-43D-C07 UL Attenuation DL Input Power High Threshold...

  • Page 34: Remote Access

    . When providing access from a remote location, through the firewall, direct TCP port 80 to the tHost™. For maintenance activities provided by Dali Wireless, provide access to TCP port 22 on the tHost™. 5.2.5 tHost™ Name Assignment and BTS Sector Assignment 15.

  • Page 35: Figure 5-5 Thost™ Configuration Screen - Sector Assignment

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary T-HostQS-Cw01 DAU Configuration T-43D-S01 T-43D-S02 DAU Name/Label: T-HostQS-Cw01 Reboot T-43D-C05 T-43D-C07 Interface BTS Sector Interface Frequency Type Assignment Setup AT&T-PCS-S1 Band 1: Sub-Band Selection Tx Rx AT&T-PCS-S2 Band 2:...

  • Page 36: T43™ Name Assignment And Bts Sector Selection

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5.2.6 t43™ Name Assignment and BTS Sector Selection 19. From the Function Explorer Tree on the left select desired t43™ unit. The t43™ main page will appear. 20. On the t43™ main page select “Configuration” button. The t43™ Configuration screen will appear.

  • Page 37: Sub-Band Selection

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 21. On the top section of the t43™ configuration screen enter the t43™ desired name. 22. On the main section of the t43™ configuration screen, below the each band frequency and output power description, select from the pull-down menu (please refer to Figure 5.8) sector to be processed by the...

  • Page 38: Figure 5-10 Thost™ Pcs And Aws Sub-Band Selection Screens

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary DAU Sub-Band Selection T-HostQS-Cw01 T-43D-S01 T-43D-S02 DAU Name/Label: T-HostQS-Cw01 T-43D-C05 T-43D-C07 Sub-Band Selection Frequency Band 3: Set Band(s) DAU Sub-Band Selection T-HostQS-Cw01 T-43D-S01 T-43D-S02 DAU Name/Label: T-HostQS-Cw01 T-43D-C05 T-43D-C07...

  • Page 39: Gain Control

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 30. Warning screen ‘UL and DL will be Disabled” will popup. Click “OK” (please refer to Figure 5-11). 31. Go to tHost™ and t43™ main GUI screens and Enable UL and DL path for the band that is set.

  • Page 40: Gain Setup

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5.3.1 Gain Setup 5.3.1.1 DL Gain Setup 32. From the Function Explorer Tree on the left select tHost™ unit. The tHost™ main page will appear. Note: tHost™ maximum input level with 0dB DL attenuation setting is -7 dBm. Absolute maximum average power at DL input is 0 dBm, but DL attenuator shall be set to 1 to 7 dB (for levels from -6 to 0 dBm) to prevent saturation (overflow) of digital section.

  • Page 41: Figure 5-13 T43™ Main Screen - Attenuation Setup

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 36. From the Function Explorer Tree on the left select desired t43™ unit. The t43™ main page will appear. 37. Read “DL System Gain” and “DL Output Power”. Change value in “DL Attenuation” field to optimize the Gain and output power of the particular band.

  • Page 42: Figure 5-14 Thost™ Main Page - Ul Attenuation Setup

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5.3.1.2 UL Gain Setup Note: To operate with the lowest UL NF maintain t43™ UL attenuation at the minimum (0 dB), and use tHost™ UL attenuation to set the system UL Gain to a desired value.

  • Page 43: Figure 5-15 T43™ Main Screen - Ul Attenuation Setup

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary T-43D-S01 T-HostQS-Cw01 T-43D-S01 Set Parameters T-43D-S02 DL Output Power Status T-43D-C05 DL Attenuation UL Input Power DL System Gain Status T-43D-C07 PA Temperature UL Attenuation DL VSWR Alarm UL System Gain...

  • Page 44: Figure 5-16 T43™ Main Screen - Delay Compensation

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5.3.1.3 Delay Compensation Setup 48. From the Function Explorer Tree on the left select first t43™ unit. The t43™ main screen will appear. 49. Read and note “Optical Delay” value.

  • Page 45: Das Functionality

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6 DAS FUNCTIONALITY 6.1 GUI Dali’s highly intuitive web server based Graphical User Interface (GUI) is designed using HTML and PHP language. This single application that resides on a Linux OS that runs on tHost™ and t43™ microprocessor provides local control and monitoring of each tHost™...

  • Page 46: Das Networking

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6.2 DAS Networking Dali’s tHost™s and t43™s support star, daisy-chain and hybrid type networking. Figure 6-2 shows typical network topologies supported: • 6 spoke star around tHost™1 Daisy-chain with tHost™2 •...

  • Page 47: Simulcast Function

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6.2.1 Simulcast Function Each Dali tHost™ supports a conventional simulcast function, feeding exactly the same DL signal(s) from a specific BTS Sector to multiple t43™s, combining the UL signals from those multiple t43™s and feeding them back to the BTS sector.

  • Page 48: Flexible Simulcast Function

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6.2.2 Flexible Simulcast Function Dali is also developing Flexible Simulcast functionality – capability to feed signal(s) from any BTS Sector to any t43™ in an overall network, and vice versa. This feature is helpful for applications where dependent on time-of- day the subscribers move from one area to another, and the available BTS capacity can “follow”...

  • Page 49: Table 6-1 Optical Transport Data Rate Calculation

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary As an example, for transferring 50 MHz of signal bandwidth (25 MHz at PCS band, and 25 MHz at AWS band) the optical data link shall have a data rate of 1.952 Gbps (M&C data are also transported via same link).

  • Page 50: Monitoring, Control And Alarm Functions

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6.3 Monitoring, Control and Alarm Functions This section provides brief overview of the Monitoring, Control and Alarm functions currently supported by Digital Optical Repeater. 6.3.1 Control Functions The Control functions currently supported by the Repeater are as follows: •...

  • Page 51: Alarms

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary • t43™ DL (PA) VSWR Threshold – for each band • t43™ DL and UL Enable/Disable Status – for each band • t43™ Alarm Status – for each band t43™...

  • Page 52: Built-In Test Functions

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 6.4 Built-In Test Functions 6.4.1 Optical Loop-Back Function To test the optical link between tHost™ and t43™s that are part of the star network (maximum 6 spoke star network supported), the process is as follows: Test data frame (pattern) is generated by functional block inside master tHost™...

  • Page 53: System Maintanance

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 7 SYSTEM MAINTENANCE 7.1 Preventive Maintenance 7.1.1 tHost™ Fan Replacement Tools required: Philips screwdriver To replace the fan located at the back panel of the tHost unit please use following steps: 1.

  • Page 54: T43™ Fan Assembly Replacement

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 5. Connect new fan and perform steps 1 to 3 in reverse order. 7.1.2 t43™ Fan Assembly Replacement Tools required: None To replace the fan assembly located at the top of the t43 unit please use following steps: 1.

  • Page 55: Figure 7-6 T43 Fan Assembly Replacement - Power Connector Location

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 3. Undo power cable connector by turning counterclockwise. Figure 7-6 t43 Fan Assembly Replacement – Power Connector Location 4. Undo three captive thumb screws (turn each counterclockwise) to release fan assembly bracket with fans.

  • Page 56: Corrective Maintenance

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 7.2 Corrective Maintenance 7.2.1 Field Level Field level maintenance personal will verify system status and fault indicators received by headquarters via remote NMS and report back to headquarters. 7.2.2 Headquarters Level Headquarters maintenance personal will determine the cause and give instructions to field level maintenance personal to remove and replace the failed unit.

  • Page 57: System Troubleshooting

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 8 SYSTEM TROUBLESHOOTING This chapter describes the meaning of each Alarm indication and provides recommendations regarding how to troubleshoot the Dali dual-band DAS comprised of tHost™ unit, and network of t43™ remote units.
  • Page 58 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary t43™ DL RF Shutdown Enabled User has manually disabled the • Re-enable the DL path from the t43™ main page. downlink path in the tHost™ t43™ UL RF Shutdown Enabled User has manually disabled the •...

  • Page 59: Fiber Connectors

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 9 FIBER CONNECTORS 9.1 Fiber Connectors Overview 9.1.1 SC Type Fiber Optic Connector Originally developed by NTT, the SC connector has a push/pull snap fit. The duplex SC connector uses the same mating profile as the simplex design.

  • Page 60: Lc Type Fiber Optic Connector

    Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary 9.1.3 LC Type Fiber Optic Connector A small form factor ceramic based connector developed by Lucent. Figure 9-3 LC Type Fiber Optic Connector 9.1.4 ST Type Fiber Optic Connector Developed by AT&T, the ST connector (for Straight Tip) has been a perennial favorite for its termination simplicity...
  • Page 61 Transcend t43™ Dual-Band DAS DW-010-7373-09 Installation and Operation Manual - Preliminary Note: Avoid use of canned air since it is ineffective on oils, residues, or small static charged particles. Dali Wireless Rev: 0-2 Proprietary and Confidential Nov , 2011 CommScope v. Dali Wireless...
