Adec A-dec+ 43.0531.00 Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
A-dec+
Gateway
™
I
NSTALLATION
Contents
Before You Begin . . . . . . . . . . 2
Connect to A-dec+ . . . . . . . . 11
86.0924.00 Rev B
G
UIDE
Product Models and Versions Covered in This Document
Models
43.0531.00
Versions
Description
n/a
Gateway Network Device

Advertisement

loading
Need help?

Need help?

Do you have a question about the A-dec+ 43.0531.00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adec A-dec+ 43.0531.00

  • Page 1 A-dec+ Gateway ™ NSTALLATION UIDE Contents Before You Begin ..2 Install the A-dec+ Gateway . . 2 Connect to A-dec+ ..11 Regulatory Information and Warranty .

  • Page 2: Before You Begin

    A-dec+ Gateway Installation Guide Before You Begin Failure to turn off or disconnect the power before you begin this procedure can lead to product WARNING damage and result in serious injury or death. Shock hazard. When you remove or replace the covers, take care not to damage any wiring or WARNING tubing.
  • Page 3 A-dec+ Gateway Installation Guide Connect the Electrical Wires and Data Line Complete the following section according to which power supply the system includes. A-dec Universal Power Supply Manufactured After June 2023 ......4 A-dec 311B/411 Power Supply Manufactured Before June 2023 .
  • Page 4 A-dec+ Gateway Installation Guide A-dec Universal Power Supply Manufactured After June 2023 You can power the Gateway using the chair circuit board or the external power supply. Complete one of the following procedures based on how the Gateway will be powered. Power the Gateway Using the Chair Circuit Board .
  • Page 5 A-dec+ Gateway Installation Guide Power the Gateway Using the External Power Supply Fire hazard. Use only the external power supply provided with the Gateway. Using another WARNING external power supply might result in a fire hazard. Another power supply might also result in an inability to meet conducted emissions standards.
  • Page 6 A-dec+ Gateway Installation Guide A-dec 311B/411 Power Supply Manufactured Before June 2023 You can power the Gateway using the chair circuit board or the external power supply. Complete one of the following procedures based on how the Gateway will be powered. Power the Gateway Using the Chair Circuit Board .
  • Page 7 A-dec+ Gateway Installation Guide Power the Gateway Using the External Power Supply Fire hazard. Use only the external power supply provided with the Gateway. Using another WARNING external power supply might result in a fire hazard. Another power supply might also result in an inability to meet conducted emissions standards.
  • Page 8 A-dec+ Gateway Installation Guide A-dec 511 Power Supply Manufactured Before June 2023 You can power the Gateway using the chair circuit board or the external power supply. Complete one of the following procedures based on how the Gateway will be powered. Power the Gateway Using the Chair Circuit Board .
  • Page 9 A-dec+ Gateway Installation Guide Power the Gateway Using the External Power Supply Fire hazard. Use only the external power supply provided with the Gateway. Using another WARNING external power supply might result in a fire hazard. Another power supply might also result in an inability to meet conducted emissions standards.
  • Page 10 A-dec+ Gateway Installation Guide Install the Gateway in a Cabinet Choose a cabinet that is close to the dental chair. NOTE 1. Place the Gateway in the cabinet. Do not locate the Gateway near an antenna or transmitter, such as a Wi-Fi router. Do not place NOTE items directly on top of the Gateway.

  • Page 11: Connect To A-Dec

    A-dec+ Gateway Installation Guide 7. Plug the connector from the external power supply into the Gateway. Ethernet Cable DCS2 or DCS1 Data Line Connect to A-dec+ For configuring connectivity features, see the A-dec+ Instructions for Use ™ (p/n 86.1030.00) at a-dec.com/connectivity-manual.

  • Page 12: Regulatory Information And Warranty

    A-dec+ Gateway Installation Guide Regulatory Information and Warranty For required regulatory information and the A-dec warranty, see the Regulatory Information, Specifications, and Warranty document (p/n 86.0221.00) available in the Resource Center at www.a-dec.com. For quick access to this document online, scan, tap, or click this QR code, which points to a-dec.com/regulatory-guide.
