Installation and Operation Manual
28VDC Wireless Audio Transmitter
Revision Date:
09/04/2012
Page 1 of 12
FD900X5
Advertisement
Table of Contents
Related Manuals for Flight Display Systems FD900X5
Summary of Contents for Flight Display Systems FD900X5
- Page 1 MAN – FD900X5 Page 1 of 12 FD900X5 Installation and Operation Manual 28VDC Wireless Audio Transmitter Manufactured by MILIC, LLC with marketing support from Flight Display Systems. This product does not have FAA PMA approval. TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
- Page 2 All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 2 of 12 FD900X5 28VDC Wireless Audio Transmitter © 2008 Flight Display Systems. All Rights Reserved. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com For the most current copy of all product manuals, please visit our website at www.flightdisplay.com...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 3 of 12 Table of Contents General Information ........................4 1. Front View ..........................4 2. Additional Information ....................4 Specifications ..........................5 Installation Instructions ......................5 1. Power ..........................6 Audio Wiring Suggestions ......................6... -
Page 4: General Information
Page 4 of 12 General Information The FD900X5 is a 28VDC Wireless Audio Transmitter that represents a state of the art audio experience. The FD900X5 has features that allow installation in the smallest of mounting areas with the minimum of interface equipment. Built with retrofit aircraft integration in mind, this transmitter can be mounted almost anywhere in the cabin. -
Page 5: Specifications
It is important to match the output impedance of the audio sources. The input of the FD900X5 should be low level audio such as that used for the inputs to home or automotive entertainment systems. If one source is significantly stronger than another, it will cause significant variation in the volume levels between channels. -
Page 6: Power
MAN – FD900X5 Page 6 of 12 Power The FD900X5 is a 28VDC device that requires .5 Amps of power to operate. Audio Wiring Suggestions The center conductor of coaxial cable should be high, and outer shield should be the return/low. -
Page 7: Power/Video
All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 7 of 12 Power/Video Pin out for P1 (High Density DB-25 Receptacle) Connector P/N: M24308/4-261 or Equivalent Crimp Contacts P/N: M39029/64-369 or Equivalent Number Description 28VDC Power Audio #1 –... -
Page 8: Operation Instructions
All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 8 of 12 Operation Instructions The passengers will be able to access the different audio channels by momentarily pressing the TUNE button found on the headset (not supplied). It is necessary to cycle the headset through the different frequencies once turned on so that it may recognize the transmitting frequencies. -
Page 9: Technical Drawing
All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 9 of 12 Technical Drawing... -
Page 10: Technical Support
09/04/2012 MAN – FD900X5 Page 10 of 12 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004... -
Page 11: Warranty
If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion. -
Page 12: Log Of Revisions
All manuals and user guides at all-guides.com Rev: Revision Date: 09/04/2012 MAN – FD900X5 Page 12 of 12 Log of Revisions Date Page Description 04/23/2009 Initial Release 09/17/2009 Updated Testing Information 03/02/2011 Added PA Interrupt info, Format Change Added Operating Temperature, Updated PA Interrupt, added...
