Christie 144-136101 Series Installation And Setup

Ultra short throw lens
installation and setup
The ultra short throw lens (P/N: 144-136101-XX) allows you to position your projector as close as
possible to your screen or display.

Affected products

The following product series are affected:
• 4K40-RGB
• Boxer
• Christie SST

Installing the ultra short throw projector lens

Learn how to install the ultra short throw projection lens.
The illustrations in this document are for representation only and may not depict your projector model
exactly.
1. Switch to the ultra short throw lens keep-out area.
a) Select MENU > Configuration > Lens Settings.
b) Select Enable UST Lens (0.38:1).
c) To enable the ultra short throw lens keep-out area, select Enter.
Not switching to this keep-out area risks damaging the projector when the ultra short throw
lens is installed.
2. Remove the lens caps from the lens.
3. Align both the guide on the front cover and the lens marked by a red line, and the insert plates
on the lens.
4. Insert the lens into the projector and turn it clockwise until it is locked in place.
Make sure the lens is supported near the front element.
Ultra Short Throw Lens Instruction Sheet
020-103364-01 Rev. 1 (04-2020)
