HAMMER
FEEL THE NOISE
S-3017
INSTRUCTION MANUAL
Feniex Product Copyrights This price List and the mentioned Feniex products include or describe copyrighted Feniex material. Laws in the United States and other countries
preserve for Feniex Industries and its licensors certain exclusive rights for copyrighted material, including the exclusive right to copy, reproduce in any form, distribute and make
derivative works of the copyrighted material. Accordingly, any copyrighted material of Feniex and its licensors contained herein or in the Feniex products described in this Price
List may not be copied, reproduced, distributed, merged or modified, transmitted, transcribed, stored in retrieval system or translated into any language or computer language,
in any form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S. Patent & Trademark Office.
Advertisement
Table of Contents
Related Manuals for Feniex HAMMER S-3017
Summary of Contents for Feniex HAMMER S-3017
- Page 1 List may not be copied, reproduced, distributed, merged or modified, transmitted, transcribed, stored in retrieval system or translated into any language or computer language, in any form or by any means, without prior written permission of Feniex Industries, Inc.. Feniex and the stylized Feniex logo are registered in the U.S. Patent & Trademark Office.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Regulations & Warranty Service after Expiration Copyright Feniex Product Copyright Box Contents Vehicle Specific Brackets Specifications, Tones, & Wiring Specifications Siren Tones Equipment Dimensions Wiring Diagram Siren Tone Selection Wiring & Installation Wiring Instructions Installation Notes... -
Page 3: Safety Regulations & Warranty
SAFETY REGULATIONS CONDITIONS The following provides all the information necessary to Feniex Industries, Inc. will not be held responsible for any safely operate the previously listed products of Feniex costs associated with equipment removal and/or Industries, Inc. Please read this manual thoroughly before re-installation resulting from a warranty claim. -
Page 4: Box Contents
BOX CONTENTS 4. Bolts 2. Brackets 5. Nuts 3. Universal Bracket 1. Low Frequency Siren BOX CONTENTS QUANTITY VEHICLE SPECIFIC BRACKETS* MODELS 1. Low Frequency Siren Ford Explorer (PIU) 2016+ 2. Brackets Ford Taurus (PIS) 2013+ 3. Universal Bracket Chevy Tahoe & Suburban 2015+ 4. -
Page 5: Specifications, Tones, & Wiring
SPECIFICATIONS, TONES, & WIRING MOUNTING INSTRUCTIONS SYSTEM SPECIFICATIONS Input Power 9V-15V DC Current Draw 17 Amps Peak 7.25" External Fuse 125% of Circuit Load Sound Output 100 Watts Frequency Input: 732Hz - 4KHz Frequency Output: 183Hz - 1KHz Decibels 110dB 7.25"... -
Page 6: Wiring Diagram
SPECIFICATIONS, TONES, & WIRING WIRING INSTRUCTIONS WIRING DIAGRAM 1) Connect the red 12v (+) wire to the positive terminal of the vehicle's battery. Ground the 12v (-) black wire or connect it to the 12v (-) terminal of the vehicle's battery. 2) Connect the yellow wire for mode 1 and brown wire for mode 2 to individual latching switches. -
Page 7: Mounting Instructions
MOUNTING MOUNTING INSTRUCTIONS Front Speaker Grilles For best results, the front of the unit should be facing forward and the speaker grille should be facing downward. Sideward facing mounting is also possible with the speaker grille facing downward. UNIVERSAL BRACKET ASSEMBLY 1) Place the L-bracket on the intended mounting surface. -
Page 8: Vehicle Specific Brackets
VEHICLE SPECIFIC BRACKETS Dodge Charger: HAMB-001 Chevy Tahoe/ Suburban: HAMB-002 Ford Interceptor Sedan: HAMB-004 Ford Interceptor Utility: HAMB-005 Universal**: HAMB-006 * Comes with purchase of Hammer Siren FE N IE X / / IN ST RU CT I O N MA N UAL WE B // w w w.fe n i ex .com...
