WIRED REMOTE CONTROLLER
E
Installation and
Owner's Manual
MODEL: KJR-120G1/TFBG-E(5V)
KJR-120G2/TFBG-E(12V)
IMPORTANT NOTE:
Read this manual carefully before
installing or operating your wired
remote controller. Make sure to save
this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KJR-120G1/TFBG-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Airstar KJR-120G1/TFBG-E

  • Page 1 WIRED REMOTE CONTROLLER Installation and Owner’s Manual MODEL: KJR-120G1/TFBG-E(5V) KJR-120G2/TFBG-E(12V) IMPORTANT NOTE: Read this manual carefully before installing or operating your wired remote controller. Make sure to save this manual for future reference.
  • Page 3 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of the wired controller please read this manual carefully before using the unit. ● For convenience of future reference, keep this manual after reading it.

  • Page 4: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTION................1 2. INSTALLATION ACCESSORY..............2 3. INSTALLATION METHOD................4 4. SPECIFICATION..................10 5. FEATURE AND FUNCTION OF THE WIRED CONTROLLER....11 6. NAME ON THE LCD OF THE WIRE CONTROLLER......12 7. NAME OF BUTTON ON THE WIRE CONTROLLER........13 8. PREPARATORY OPERATION..............14 9.

  • Page 5: Safety Precaution

    1. SAFETY PRECAUTION Read the safety precautions carefully before installing the unit. Stated below are important safety issues that must be obeyed. Means improper handling may lead to personal death or severe injury. WARNING Means improper handling may lead to personal injury or property loss. CAUTION WARNING Please entrust the distributor or professionals to install the unit.

  • Page 6: Installation Accessory

    2. INSTALLATION ACCESSORY Select the installation location Don’t install at the place where cover with heavy oil, vapor or sulfureted gas, otherwise, this product would be deformed that would lead to system malfunction. Preparation before installation 1. Please confirm that all the following parts you have been supply. Name Qty.
  • Page 7 2. INSTALLATION ACCESSORY Precaution of install the wire controller 1. This manual provides the installation method of wire controller. Please refer to the wiring diagram of this installation manual to wire the wire controller with indoor unit. 2. The wire controller working in low voltage loop circuit. Forbid to directly contact the cable of 220Vcommercial electricity or of 380V high voltage, and don’t wire this kind of wire in the said loop;...

  • Page 8: Installation Method

    3. INSTALLATION METHOD 1.Wired remote controller structure size figure 120mm 18.5mm 46mm (4.7”) (0.7”) (1.8”) 83.5mm 123mm (3.3”) (4.8”) 62mm (2.4”) Fig 3-1 2.Wiring Principle Sketch: Insert of the mainboard CN40 ----------------------------------- ----------------------------------- black black ----------------------------------- yellow yellow ----------------------------------- brown brown 4-Core Shield Cable, the length Wire controller...
  • Page 9 3. INSTALLATION METHOD 3.Wiring figure The connective wires group Mainboard 4-core shielding wire CN40 Fig 3-3 Connect the female joint of wires group from the mainboard with the male joint of connective wires group. (See Fig.3-3) Please connect the other side of connective wires group with the male joint of wires group leads from wire controller.
  • Page 10 3. INSTALLATION METHOD 5. Fasten the back plate of the wire controller For exposed mounting, fasten the back plate on the wall with the 3 screws (M4×20) and plugs. (Fig.3-5) Back plate Screws (M4×20) Fig 3-5 For flush-mounting, fasten the back plate on the switch box with 2 screws (M4×25) and fasten it on the wall with 1 screw (M4×20).
  • Page 11 3. INSTALLATION METHOD Battery installation Fig 3-7 Put the battery into the installationsite and make sure the positive side of the battery is in accordance with the positive side of installationsite.(See Fig.3-7) Please set the time corrected on the first time operation. Batteries in the wire controller can timing under power failure which ensure the time keep right.
  • Page 12 3. INSTALLATION METHOD 7. Wire the indoor unit 3 methods 1 from the rear; 2 from the bottom; 3 from the top; 1 notch the part for the wiring to pass through with nippers, etc.
  • Page 13 3. INSTALLATION METHOD NOTE: DO NOT allow water to enter the remote control. Use the trap and putty to seal the wires. Putty Trap Putty Putty Trap Trap Fig 3-8 8. Reattach the upper part of the wire controller After adjusting the upper case and then buckle the upper case; avoid clamping the wiring during installation.

  • Page 14: Specification

    4. SPECIFICATION DC 5V/DC 12V Input voltage -5~43 23~110 Ambient temperature RH40%~RH90% Ambient humidity Wiring specifications Wiring type Total length Size Sheathed vinyl cord or cable 0.75-1.25mm <50m 164’...

  • Page 15: Feature And Function Of The Wired Controller

    5. FEATURE AND FUNCTION OF THE WIRED CONTROLLER Feature: LCD display. Malfunction code display: it can display the error code, helpful for service. 4-way wire layout design, no raised part at backside, more convenient to place the wires and install the device. Swing Timer Day off/Del...

  • Page 16: Name On The Lcd Of The Wire Controller

    6. NAME ON THE LCD OF THE WIRE CONTROLER 1 Operation mode indication 8 Turbo function indication 2 Fan speed indication 9 °C / °F indication 3 Left-right swing indication 10 Temperature display 4 Up-down swing indication 11 Lock indication 5 Faceplate function indication 12 Room temperature indication 6 Main unit and secondary unit indication...

  • Page 17: Name Of Button On The Wire Controller

    7. NAME OF THE BUTTON ON THE WIRE CONTROLER Swing Timer Day off/Del Confirm Back/Turbo Copy/Ifeel Mode Fan speed (Lock) 1 MODE button 6 TIMER button 2 POWER button 7 DAY OFF/DEL button 3 Adjust button 8 COPY/IFEEL botton 4 FAN SPEED button 9 BACK/TURBO bottom 5 SWING Button 10 CONFIRM button...

  • Page 18: Preparatory Operation

    8. PREPARATORY OPERATION Set the current day and time Timer Press the Timer button for 3 seconds or more. The timer display will flash. Press the button “ + ” or “ - ” to set the date. The selected date will flash.

  • Page 19: Operation

    9. OPERATION To start/stop operation Press the Power button. To set the operation mode Operation mode setting Press the Mode button to set the operation mode. Mode (Heat function is invalid for cool only type unit) Room temperature setting Press the button“ + ”or “ - ” to set the room temperature. Indoor Setting Temperature Range : 17~30 62~86...
  • Page 20 9. OPERATION Fan speed setting Press the Fan speed button to set the fan speed. (This button is unavailable when in the mode of Auto or Dry) Fan speed (Lock) Room temperature sensor selection Copy/Ifeel Indoor Unit Press the Ifeel button to select whether the room temperature is detected at the indoor unit or the wire controller.
  • Page 21 9. OPERATION Child lock function Press the Lock botton for 3 seconds to activate the child lock function and lock all buttons on the wire controller. Press the button again for 3 seconds to deactivate the child lock function. Fan speed (Lock) When the child lock function is activated,the mark appears.
  • Page 22 9. OPERATION Turbo function (on some models) Press the Turbo button to activate the turbo function. Back/Turbo Press the button again to deactivate the turbo function. When the turbo function is activated,the mark appears. Faceplate function (on some models) 1.When the unit is off Press the Mode button long to activate the faceplate function.The mark will flash.
  • Page 23 9. OPERATION Swing function(For the unit left & right auto swing models only) 1 Left-Right swing Swing Press the Swing button to start Left-Right swing function. Press it again to stop. When the Left-Right swing function is activated, the mark appears. 2 Up-Down swing Swing Press the Swing button long to start up-down swing function.
  • Page 24 9. OPERATION Swing function(For the unit without left & right auto swing function models) Up-Down airflow direction and swing Swing Use Swing button to adjust the Up-down airflow direction. 1.Press the button every time, the louver swings 6 degrees. 2.Press and hold the button for 2 seconds,it turns into up-down swing mode, press ti again to stop.

  • Page 25: Timer Functions

    10. TIMER FUNCTIONS WEEKLY timer Use this timer function to set operating times for each day of the week. On timer Use this timer function to start air conditioner operation.The timer operates and air conditioner operation starts after the time has passed. Off timer Use this timer function to stop air conditioner operation.The timer operates and air conditioner operation stops after the time has passed.
  • Page 26 10. TIMER FUNCTIONS To set the On or Off TIMER Press the Timer button to select the Timer No display Confirm Press the Confirm button and the Clock display is flashing. ex.Off timer set at PM 6:00 Press the button “ + ” or “ - ” to set the time. After the time is set, the timer will start or stop automatically.
  • Page 27 10. TIMER FUNCTIONS To set the On and Off TIMER Press the Timer button to select the Timer Confirm Press the Confirm button and the Clock display is flashing. Confirm Press the button “ + ” or “ - ” to set the time of On timer,and then press the Confirm button to confirm the setting.

  • Page 28: Weekly Timer

    11. WEEKLY TIMER Weekly timer setting Press the Timer button to select the .and Confirm Timer then press the Confirm button to confirm. Day of the week setting Press the button “ + ” or “ - ” to select the day of the Confirm week.and then press the Confirm button to confirm the setting.
  • Page 29 11. WEEKLY TIMER Up to 8 time scales can be setted in one day.Mode,temperature and fan speed in different time scale can be setted. ex.Tuesday time scale 1 Time setting Press the button “ + ” and “ - ” to set the time.and then Confirm press the Confirm button to confirm the setting.
  • Page 30 11. WEEKLY TIMER Fan speed setting Press the button “ + ” and “ - ” to set the fan speed .and Confirm then press the Confirm button to confirm the setting. NOTE: This setting is unavailable when in the mode of Auto, Dry or Off Different time scales can be setted by repeating step 3 to 7.
  • Page 31 11. WEEKLY TIMER WEEKLY timer operation ● To start Press the Timer button to select the ,and then the timer Timer starts automatically. ● To cancel Press the Power button to cancel the timer mode. Timer The timer mode can also be canceled by changing the timer mode using the Timer button.
  • Page 32 11. WEEKLY TIMER Press the Day off button to set the DAY OFF. Day off/Del mark is hidden ex.The DAY OFF is set for Wednesday The DAY OFF can be setted for other days by repeating the steps 2 and 3. Back/Turbo Press the Back button to back to the weekly timer.
  • Page 33 11. WEEKLY TIMER Copy/Ifeel Press the Copy button,the letter “CY” will be shown on the LCD. Press the button “ + ” or “ - ” to select the day to copy to. Press the Copy button to confirm . Copy/Ifeel mark flashes quickly ex.
  • Page 34 11. WEEKLY TIMER Delete the time scale in one day. During the weekly timer, press the Confirm button. Confirm Press the button “ + ” and “ - ” to select the day of the Confirm week.and then press the Confirm button to confirm the setting.

  • Page 35: Fault Alarm Handing

    12. FAULT ALARM HANDING If the system does not properly operate except the above mentioned cases or the above mentioned malfunctions is evident, investigate the system according to the following procedures. D ISPLAY MALFU N C T ION & PROT EC T ION D EFIN E DIGITAL TUBE Error of communication between wire controler and indoor unit...
  • Page 36 QSXUI-009AEN The design and specifications are subject to change without prior notice for product improvement.Consult with the sales agency or manufacturer for details. 2020551A7xxx 20151009...
