SUMAKE
Specification:
Free Speed
Capacity
Overall Length
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
Air Twister Cleaning Gun
W/plastic cup
SA-4012M
4,000-8,000 r/min
1000 cc
12.5"(320mm)
12 CFM (340 L/min)
1/4" (6.35 mm)
1/4" (6.35 mm)
50-115 psi (3.5-8 kg/cm²)
1.5 lbs (0.68 kg)
Noise and Vibration:
Vibration
EN ISO 20643:2008
Sound Pressure Level
Load:
2.49 m/s²
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
: 95 dB(A)
Sound power level
environment
: 106 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
K= 3dB
SA-4012M-S-2005B-G2F
Remark
wear ear
protector at
hearing!
Advertisement
Table of Contents
Related Manuals for Sumake Air Twister SA-4012M
Summary of Contents for Sumake Air Twister SA-4012M
- Page 1 Air Hose (I.D.) dB(A) due to risk of impaired Air Pressure 50-115 psi (3.5-8 kg/cm²) Uncertainty Uncertainty hearing! ² K= 1.5 m/s K= 3dB Net Weight 1.5 lbs (0.68 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 SA-4012M-S-2005B-G2F...
- Page 2 INSTRUCTION MANUAL SA-4012M, SA-4012MA ITEM NO.: AIR TWISTER CLEANING GUN (W/ MOTOR) SA-4012M SA-4012MA SA-4012M(A)-I-1804A-G2...
- Page 3 Instruction manual Please read this manual thoroughly before using the tools and store in a safe place for quick and easy reference at all times. Incorrect use of this device or actions non conform to the Directive can cause serious injuries. To be used only by qualified personnel.
- Page 4 3. Turn the black rocker lever into the vertical position to activate the (cleaning) liquid in the bottle. 4. Important: Hold the cleaning spout at a distance of 3 cm from the surface you are cleaning. 5. Press the "trigger" all the way; move the tools slowly in circular motions over the surface you are cleaning. 6.
- Page 7 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： AIR TWISTER CLEANING GUN Model/ Serial No.： SA-4012M to which this declaration applies, complies with these normative documents: ...
- Page 8 SA-4012M AIR TWISTER CLEANING GUN (W/ MOTOR) (PLASTIC CUP) SA-4012MA AIR TWISTER CLEANING GUN (W/MOTOR) W/PLASTIC CUP & BRUSH NOZZLE PARTS LIST PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty SA4012-01 Nozzle SA4012-27 SA4012-01A Brush Nozzle [SA-4012MA] SA4012-28 E-Ring SA4012-02 Alu.
