Instruction

Manual

USE R MA N UAL

PARAPET ANCHOR

ROP16

Meets or exceeds

applicable standards

Rev. Mar. 2023

Table of Contents

Need help?

Do you have a question about the ROP16 and is the answer not in the manual?

Questions and answers

Summary of Contents for FrontLine ROP16

Page 1 Instruction Manual USE R MA N UAL PARAPET ANCHOR ROP16 Meets or exceeds applicable standards Rev. Mar. 2023...
Page 3 Instruction Manual Frontline Fall Protection Inc. INSTRUCTION MANUAL This product meets applicable ANSI Z359.18, OSHA 1910 and OSHA 1926 fall protection standards. Designed in accordance with ANSI Z359.18 Type A These instructions apply to the following model(s): ROP16 Applicable standards and regulations depend on the type of work being done, and also might include state-specific regulations.
Page 4: Table Of Contents
Instruction Manual TABLE OF CONTENTS Definitions __________________________________________________________ 5 General Statement and Warnings ___________________________________ 9 Training Requirements _____________________________________________ 10 Description _________________________________________________________ 11 Application __________________________________________________________ 11 System Requirements _____________________________________________ 13 Installation _________________________________________________________ 19 Maintenance, Service, and Storage ________________________________ 23 Labels ______________________________________________________________ 25 BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT...
Page 6: Definitions
Instruction Manual DEFINITIONS Anchorage A secure point of attachment for lifelines, lanyards, or deceleration devices. Attachment Point A loop or “D” ring connected (integrally) to the body support that provides a means for attachment of other components of the fall protection system. Body Harness Means straps, which may be secured about the worker in a manner that will distribute the fall arrest forces over at least the thighs, pelvis, waist, chest and...
Page 7 Instruction Manual location of that attachment point after the employee comes to a full stop. Fall Arrest System A fall arrest system means a system used to arrest an employee in a fall from a working level. It consists of an anchor point, connectors, a body belt or body harness and may include a lanyard, deceleration device, lifeline, or suitable com- binations of these.
Page 8 Instruction Manual Leading Edge The edge of a floor, roof, or formwork for a floor or other walking or working surface (such as the deck) which changes location as additional floor, roof, decking, or formwork sections are placed, formed, or constructed. A leading edge is considered to be an “unprotected side and edge”...
Page 9 Instruction Manual (also referred to as a fall arrester). Self-Retracting Lifeline/Lanyard A deceleration device containing a drum-wound line, which can be slowly extracted from, or retracted onto, the drum under slight tension during normal worker movement, and which, after onset of a fall, automatically locks the drum and arrests the fall.
Page 10: General Statement And Warnings
User Instructions is not approved by Frontline Fall Protection and could result in serious injury or death. This device is only to be used by trained users in workplace applications.
Page 11: Training Requirements
TRAINING REQUIREMENTS Before using Frontline Fall Protection product, user and employers must ensure that the person using this equipment has been trained on the proper use, care and maintenance of this product by a competent person qualified in Fall Protection.
Page 12: Description
DESCRIPTION The Frontline parapet anchor is meant to be used on roof tops or surfaces that have a parapet wall and the work needs to be performed on the outside of the wall or structure.
Page 13 Paint: Electrostatic Paint 20.5 lbs WEIGHT: Purpose: The Frontline Fall Arrest Anchors are designed to be used as a component in a Personal Fall Arrest System (PFAS) Frontline Fall Arrest Anchors are tested to meet or exceed applicable OSHA and ANSI standards so employees can work safely tie-off while maintaining mobility and being productive when using Anchorage Connector.
Page 14: System Requirements
General Disclaimer: Frontline has tested their product to comply with OSHA and/ or ANSI under a controlled environment and with certain substrates. Frontline cannot and does not guarantee the same performance for different substrates other than the ones mentioned in these user manuals.
Page 15 Instruction Manual FIGURE 2 - NON - COMPATIBLE CONNECTIONS DO NOT connect two snaphooks or DO NOT connect two snaphooks or carabiners carabiners to each other. to a single D-ring at the same time. DO NOT connect in a way that would create DO NOT attach to a object in a manner a loading on the gate.
Page 16 • Ensure there are no swing hazards. If the user is unable to determine whether the anchorage meets the manufacturer’s specification, please contact Frontline at info@frontlinefall.com Before Working with your PFAS: It is required that before using PFAS, a fall protection plan should be in place and used including the working conditions and equipment to be used.
Page 17 Instruction Manual • Inspection procedures. • Fall clearances and potential swing falls. • Proper structure/substrate anchoring to withstand the minimum required loads. • A rescue plan in case end user or someone is subject to a fall. Total Fall Clearance for PFAS: According to OSHA, the total fall clearance distance is the minimum vertical distance between the worker and the lower level that is necessary to ensure the worker does not contact a lower level during a fall.
Page 18 Instruction Manual FIGURE 3 Connecting Subsystem (Energy Absorbing Lanyard Shown) Working Level Shown Lower Level or Obstruction Free Fall - 6ft. (1.8m) Max. (per ANSI Z 359.11) Deceleration Distance Total Fall Distance Free Fall (D) + Deceleration (E) BUILT TO LAST | MANUFACTURED TO COMPLY...
Page 19 Instruction Manual Swing Fall: The swing fall hazard is created by the pendulum effect, which can swing a fallen worker into a nearby surface, such as a wall or protruding beam. In addition to calculating the total fall clearance distance before beginning work on an elevated level, it is important to evaluate the swing fall hazard at the edges where a worker might fall.
Page 20: Installation
These are minimum requirements, and all inspections should be documented for recordkeeping. Any questions regarding the safety inspection of Frontline Fall Protection products please contact us at info@frontlinefall.com.
Page 21 Instruction Manual BUILDING Before installing the parapet anchor Frontline requires that the substrate withstand the required 5,000 lbs minimum breaking strength and approved before use by a qualified person. The parapet wall must be a minimum of 10” high so that the adjustable arm lies flat and unobstructed and the parapet wall be of a maximum width of no greater than 15”.
Page 22 Instruction Manual 2. Once anchor has been positioned, remove the locking pin out of the adjustable arm and then move the adjustable arm as close as possible to the parapet inner wall as shown on figure 6. FIGURE 6 3. Line up the closest slot and then insert the locking pin through the adjustable and fixed arm slots.
Page 23 Instruction Manual 5. Now, turn the adjustable pressure handle clockwise in order to tighten onto the inner parapet wall as tight and with as much as pressure possible to fully secure the parapet anchor to the wall as shown on figure 8. a.
Page 24: Maintenance, Service, And Storage
Repairs and maintenance can only by done Frontline MAINTENANCE AND SERVICE: Fall Protection. No company or end user shall maintenance or repair Frontline Fall Protection products under no circumstances. Product that does not pass inspection or is questionable needs to be taken out of service immediately and then notified to Frontline Fall Protection for inspection and further action.
Page 25 MAINTENANCE, SERVICE, AND STORAGE Instruction Manual Ensure to transport product where it doesn’t beat up against other TRANSPORT: products as this might cause damage to products and terminate the use of them. Product also should not be transported with harmful substances or chemicals as this might also compromised the integrity of the product.
Page 26: Labels
Instruction Manual INSPECTION DATE: INSPECTED BY: MODEL NUMBER: DATE OF FIRST USE: Corrective Action/Maintenance: Approved by: Date: Approved by: Corrective Action/Maintenance: Date: Corrective Action/Maintenance: Approved by: Date: LABELS BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT...
