- Page 1 Getz Equipment Innovators Part No.: 3G0038 Mechanical Bench Vise Table of Contents Page 3 – Mounting Instructions Page 3 – Operating Instructions Page 4 – Parts List Page 4 – Drawing Page 1 of 4 1/23/2019...
- Page 2 All implied warranties, including, but not limited to, warranties of fitness for purpose and merchantability, are limited to the time periods as stated above. In no event shall Getz Equipment Innovators be liable to incidental or consequential damages. Some states do not allow limitations on how long an implied warranty lasts or the exclusions or limitation of incidental or consequential damages, so that the above limitations or exclusions may not apply to you.
- Page 3 Mechanical Bench Vise (3G0038) Mounting Instructions (refer to drawing on page 3) Tools needed: 1. Drill and 5/16” drill bit 2. Hammer and pin punch 3. Flat head screwdriver 4. 7/16” wrench Instructions: 1. Remove angle jaw (item #2) from base plate (item #1) of vise and turn hand wheel (item #11) clockwise until hand wheel stops.
- Page 4 THREADED PLATE 1G0005 THREADED ROD 1G0069 WASHER FLAT 3/8 BRASS 3G58581 JAW PADDING 3G59489 JAW PADDING WITH HOLE 1G0128 HANDWHEEL Please order replacement parts from: Getz Equipment Innovators Phone (888) 747-GETZ (4389) Fax (309) 309-495-0625 www.getzequipment.com Page 4 of 4 1/23/2019...
