- Page 1 Quick start guide FOREST DS-XL® LED WIFI DIMMER 591754X000...
- Page 2 configuration button connection from 24V power supply connection to LED strip LED strip indicator (after power ON) Light up 100% Dimmer is already connected to app Flashing fast (twice per second) Easy Connect mode Flashing slow (each 3 seconds) Access Point mode Light up 100% after blinking for 3 Dimmer is not connected to app minutes...
- Page 3 Possible configurations: DS-XL LED track without motor DS-XL LED track with Shuttle S motor (<40kg curtain weight) DS-XL LED track with Shuttle M motor (>40kg curtain weight) Support Visit www.forestgroup.com/wifisupport for technical support & troubleshooting.
- Page 4 1. Assemble and/or install the DS-XL LED track and plug all connectors as in the diagram of your configuration on previous page. 2. Download and install the Forest Connect App from the Apple App Store or Google Play Store: QR scan OR code 3.
- Page 5 Troubleshooting I don’t see any lights on the LED strip after plugging in - try to bypass the Wifi dimmer and watch if the LED strip lights up: when LED strip doesn’t light up, check the track connections LED strip - make sure the power adapter, Wifi dimmer and LED strip are plugged in - disconnect the power, after 5 seconds, connect the power again.
- Page 6 It is important for the safety of persons to follow these instructions. Keep these instructions for future reference. Do not use the product for any other purpose than intended. In order for the Forest DS-XL LED dimmer to function correct and safe, the complete curtain system must be assembled with original parts and devices of Forest Group Nederland B.V.
