- Page 1 User Manual Model ID: STRIKEARRAYFLUSHBRACKET...
- Page 2 Edition Notes The Strike Array Flush Bracket User Manual includes a description, safety precautions, installation, and maintenance instructions for the Strike Array Flush Bracket as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, and Strike Array Flush Bracket are registered trademarks or trademarks of Chauvet &...
-
Page 3: Table Of Contents
Product Dimensions ..................3. Setup ................... Mounting ....................... Orientation......................Rigging ....................... Procedure......................Product Mounting Diagram ..................Mounting Products Attached in Series ..............4. Technical Specifications ............Contact Us ..................Warranty & Returns..................Strike Array Flush Bracket User Manual Rev. 2... -
Page 4: Before You Begin
Make sure there are no flammable materials close to the product when operating. • In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Strike Array Flush Bracket User Manual Rev. 2... -
Page 5: Introduction
Mounting bracket for Strike Array fixtures • Eliminates the need for a yoke • Creates a cleaner, easier-to-hang array in certain environments Product Dimensions 4.52 in 115 mm 3.77 in 350 mm 5.03 in 128 mm Strike Array Flush Bracket User Manual Rev. 2... -
Page 6: Setup
Use a mounting clamp of appropriate weight capacity when rigging the product onto truss. Procedure The Strike Array Flush Bracket is meant to be used with mounting clamps. Make sure the clamps are capable of supporting the weight of this product. Use at least two mounting points per product. For the Chauvet Professional line of mounting clamps, go to http://www.trusst.com/products. -
Page 7: Mounting Products Attached In Series
Up to 16 cells The Strike Array Flush Bracket can support up to 16 cells or 4 Strike Array products. Do not exceed! Strike Array Flush Bracket User Manual Rev. 2... -
Page 8: Technical Specifications
5.03 in (128 mm) 4.52 in (115 mm) 3.75 lb (1.7 kg) Note: Dimensions in inches are rounded. Ordering Product Name Item Name Item Code UPC Number Strike Array Flush Bracket STRIKEARRAYFLUSHBRACKET 03112102 781462224509 Strike Array Flush Bracket User Manual Rev. 2... -
Page 9: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Strike Array Flush Bracket User Manual Rev. 2...
