This manual applies to the following single Antenna Unit models with In-Cab Display:
Antenna Unit Model Number:
Configuration Option
SLAU-UV-NB-07
SLAU-UV-NB-DT-07
SLAU-UV-NB-RT-07
SLAU-UV-NB-RT-DT-07
SLAU-UV-NB-ERT-07
SLAU-UV-NB-ERT-DT-07
In-Cab Display Unit:
SLDU-006SR
SDLU-006SRE
This guide contains directions on the legally mandated requirements for a proper
Improper installation and/or modifications to the device not expressly approved by SCAN~LINK Technologies Inc.
may expose the operator to harmful radiation and may void the user's authority to operate the equipment.
The SCAN~LINK Armour System™ is to be used only as a tool to assist a vehicle operator and does not replace any
safety procedures in place, nor does it remove any responsibility for the safe operation of the vehicle from the driver.
CAUTION:
Changes or modifications not expressly approved by SCAN-LINK Technologies Inc. could void
the user's authority to operate the equipment.
The SCAN~LINK Armour System™ is intended for use on mobile equipment in construction and
industrial applications. It is not intended for use by the general public.
SCAN~LINK™ Technologies Inc. has made all efforts to ensure the accuracy and relevance of this document. SCAN~LINK™ Technologies Inc. and its
agents reserve the right to make corrections, modifications, enhancements, improvements, and other changes to the product to enhance the functionality and
reliability of the device. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All products are sold subject to terms and conditions of sale supplied at the time of order acknowledgment. SCAN~LINK™ and/or its agents
MAKE NO WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, RELATED TO THE INFORMATION HEREBY CONTAINED.
No part of this document can be copied or reproduced in any format including electronic and print without express written permission of SCAN~LINK™
Technologies Inc. The use of this document is strictly limited to the application of the SCAN~LINK Armour System™.
USER'S MANUAL
Standard Narrow Beam Antenna
Standard Narrow Beam Antenna with Data
Relay Output Narrow Beam Antenna
Relay Output Narrow Beam Antenna with Data
Enhanced Relay Output Narrow Beam Antenna
Enhanced Relay Output Narrow Beam Antenna with Data
Standard Output
Enhanced Output In-Cab Display Unit
installation.
SLAU-270NB
Description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the armour SLAU-UV-NB-07 and is the answer not in the manual?

Questions and answers

Summary of Contents for SCAN-LINK armour SLAU-UV-NB-07

  • Page 1 CAUTION: Changes or modifications not expressly approved by SCAN-LINK Technologies Inc. could void the user’s authority to operate the equipment.
  • Page 2: Table Of Contents

    Installation Wiring Diagram: Ignition Trigger with Alarm ....................15 Installation Wiring Diagram: Reverse Trigger, no Alarm ....................16 Installation Wiring Diagram: Reverse Trigger with Alarm ....................17 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 3: Disclaimer

    By using the SCAN~LINK Armour System or any of its components, you are bound to adhere to the conditions and practices outlined therein. 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 4: Product Description

    A moisture vent is incorporated in the Antenna Unit case so that moisture inside the case can vent to the outside. 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 5: In-Cab Display Unit

    Volume Button volume is being adjusted, the LED cluster will indicate the volume settings. The more LEDs that are on, the higher the volume. 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 6: In-Cab Display Unit Indications

    Rapid Pair™ Antenna Detection Error (Reader Response Error) Antenna Temperature Range Error Antenna Soft Reset Error Antenna Communications Protocol Error Indicator Communications Protocol Error 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 7: Detection Range

    Hard Hat, will have a higher probability of being detected by the SCAN~LINK Armour System™ than those wearing only a single article of SCAN~LINK Safety apparel. 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 8: Product Specification

    Moisture vent must face downward Power Connector Deutsch DTM04-6P Mates w/Deutsch DTM06-6S Relay Connector Deutsch DT04-4P Mates w/Deutsch DTM06-4S Enhanced Relay Connector Deutsch DTM04-12PA Mates w/Deutsch DTM06-12SA 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 9: Electrical Specifications

    Pin 6 Pin 7 Detection Relay Common Fault Relay Common Detection Relay Fault Relay Normally Open Normally Closed Not Detecting Open No Fault Open 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 10: Rs-485 Communications Note

    50º C Storage Temperature -30º C 80º C Ingress Protection IP52 Indoor Use Only Reverse Polarity Protected 100V/20A Voltage Spike Withstand SURVIVAL < 3ms: -600V/+400V 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 11: Physical Specifications

    Antenna’s reverse signal. However, operation in this mode requires additional configuration with RapidPair and has no function whatsoever until the appropriate settings are changed. 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 12: Cable Specifications

    Detection Relay Not Detecting / Power Closed to Relay Common (Green) Compatibility Specifications RapidPair RapidPair 2.0 Dongle Only (RPD-SS200 or RPD-SN220) Antenna SLAU-UV-NB-xx-xx-xx-04,SLAU-UV-NB-xx-xx-xx-06,SLAU- UV-NB-xx-xx-xx-07 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 13: Agency Certifications

    For further information on RF exposure and compliance, please visit the following links: https://support.scan-link.com https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm https://sms-sgs.ic.gc.ca/search/radioEquipmentPortal 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 14: Installation Wiring Diagram: Ignition Trigger, No Alarm

    SCAN~LINK Armour User’s Manual (EACU Rev 12.3) Installation Wiring Diagram: Ignition Trigger, no Alarm 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 15: Installation Wiring Diagram: Ignition Trigger With Alarm

    SCAN~LINK Armour User’s Manual (EACU Rev 12.3) Installation Wiring Diagram: Ignition Trigger with Alarm 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 16: Installation Wiring Diagram: Reverse Trigger, No Alarm

    SCAN~LINK Armour User’s Manual (EACU Rev 12.3) Installation Wiring Diagram: Reverse Trigger, no Alarm 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
  • Page 17: Installation Wiring Diagram: Reverse Trigger With Alarm

    SCAN~LINK Armour User’s Manual (EACU Rev 12.3) Installation Wiring Diagram: Reverse Trigger with Alarm 611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5 Phone: 1-905-304-6100 E-Mail: info@scan-link.com Web: www.scan-link.com...
