USER MANUAL
RANGE EXTENDER
ZAC38
Scan to register your product
for extended warranty and
direct access to firmware files.
www.getzooz.com/register

FEATURES

Boost your Z-Wave™ network
Ÿ
with this signal repeater
Back-up battery and power
Ÿ
outage notifications to your hub
NEW 800 series chip for faster
Ÿ
communication and more range
Extra small, doesn't block the
Ÿ
other outlet
The latest S2 security and
Ÿ
SmartStart for secure set-up
Supports OTA firmware updates
Ÿ
ETL listed for safety standards
Ÿ

SPECIFICATIONS

Model Number: Z
Ÿ
Power: 120 VAC 60 Hz
Ÿ
Operating Temperature: 32° –
Ÿ
104° F
Dimensions: 1" x 1" x 1.25"
Ÿ
Range: Up to 400 feet line of sight
Ÿ
Installation and Use: Indoor only
Ÿ

INSTALLATION

Plug the Range Extender into any
standard grounded 110 V
receptacle. Click the Z-Wave™
button to see if the LED indicator
comes on and off. If the LED
indicator doesn't light up at all,
please try a different receptacle.
If it's still off, please get in touch
with our support team:
ask@getzooz.com

WARNING

This product should be installed indoors
Ÿ
upon completion of any building
renovations.
Prior to installation, the device should be
Ÿ
stored in a dry, dust-and-mold-proof
place.
Do not install the Extender in a place with
Ÿ
direct sun exposure, high temperature, or
humidity.
Keep away from chemicals, water, and
Ÿ
dust.
Ensure the device is never close to any
Ÿ
heat source or open flame to prevent fire.
Ensure the device is connected to an
Ÿ
electric power source that does not
exceed the maximum load power.
No part of the device may be replaced or
Ÿ
repaired by the user.
NEED SOME HELP?
ask@getzooz.com
www.support.getzooz.com
PAGE 1
www.getzooz.com
AC38
Z-WAVE

1. ADD DEVICE to your hub

Initiate inclusion (pairing) in the
app (or web interface). Not sure
how? ask@getzooz.com
If you're using an S2 hub, it will ask
you to enter the DSK PIN or scan
the QR code printed on the side of
the extender to complete
SmartStart inclusion.

2. ACTIVATE the extender

While the hub is looking for new
devices, click the Z-Wave™
button 3 times as quickly as
possible. The LED indicator will
start flashing green to confirm
inclusion mode and turn green for
2 seconds once inclusion is
completed.
Z-WAVE™
BUTTON
The extender may display as a
binary sensor, plug, or a different
device type in your hub. That's OK.
As long as it's added, it will start
repeating the signal and working
as designed.
SmartStart enabled products can
be added into a Z-Wave network
by scanning the Z-Wave QR Code
present on the product with a
controller providing SmartStart
inclusion.
Choose your hub and scan the QR
code with your phone's camera.
Then click on the link to access the
step-by-step pairing instructions.
Z-Box Hub
SmartThings
Hubitat
Home Assistant
CONTROL
™
QR / PIN CODE
™
™
PAGE 2
