ESTERS ELEKTRONIK GDR 1530-0000-0000 Instruction Manual

Flow computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P
=
Speed
Pressure
Flow Rate
Temperature
I
NSTRUCTION
Device:
Flow Computer GDR 1530-0000-0000
Content:
Instruction manual
Rev. No.:
IM 326-00 E V0.4-2023-08-11, FW G12.02
Instruction Manual IM 326-00 E
Phone: +49 6021- 45 807 - 0
Fax:
+49 6021- 45 807 - 20
M
IM 326-00 E
ANUAL
Esters Elektronik GmbH
Hafenrandstr. 14 · D-63741 Aschaffenburg
Page 1
eMail: info@esters.de
Internet: http://www.esters.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDR 1530-0000-0000 and is the answer not in the manual?

Questions and answers

Related Manuals for ESTERS ELEKTRONIK GDR 1530-0000-0000

Summary of Contents for ESTERS ELEKTRONIK GDR 1530-0000-0000

  • Page 1 Speed Pressure Flow Rate Temperature IM 326-00 E NSTRUCTION ANUAL Device: Flow Computer GDR 1530-0000-0000 Content: Instruction manual Rev. No.: IM 326-00 E V0.4-2023-08-11, FW G12.02 Instruction Manual IM 326-00 E Page 1 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de...

  • Page 2: User Information

    Internet: www.esters.de, www.fluidistor.de Copyright This manual is copyrighted. Duplication and distribution are not permitted without written permission. © Esters Elektronik GmbH, Aschaffenburg Instruction Manual IM 326-00 E Page 2 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de...

  • Page 3: Table Of Contents

    Overview of nameplates GD 300 (Ex) and GD 100 ___________________________________ 32 Factory calibration certificate for gas flow meter____________________________________ 33 Instruction Manual IM 326-00 E Page 3 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 4: Index Of Figure

    List of abbreviations Enumeration parameters Numerical parameters Factory settings Instruction Manual IM 326-00 E Page 4 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 5: Common

    4 - 20 mA, 2 wire = 0 - 1000 bar (17 bit) RESSURE Instruction Manual IM 326-00 E Page 5 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 6: Output

    UMIDITY CLASS acc. to EN 50082-2 LECTROMAGNETIC COMPATIBILITY Instruction Manual IM 326-00 E Page 6 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 7: Display, Housing, Weight

    GD 300 (only NON ATEX applications) Instruction Manual IM 326-00 E Page 7 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 8: Device Codes

    Speed Pressure Flow Rate Temperature Device codes GDR 1530-0000-0000 Inputs • 1: Flow rate: input for platinum wire sensor (GD 300/GD 500) (only NON-ATEX) or 1: Flow rate: impulse input for HB 300-R000000 (GD 300/GD 500), HB 300 Ex-R000000 •...

  • Page 9: Operating Overview

    Speed Pressure Flow Rate Temperature Operating overview Touch keypad The GDR 1530-0000-0000 is programmed directly on the device using the capacitive touch keyboard. left right upwards downwards cancel, escape Figure 1: Touch keypad confirm, enter The menu is guided using the buttons: Display: Device start The start-up screen appears when the device is started.

  • Page 10: Display: Live Screen

    Figure 10: Relay Figure 11: System status Instruction Manual IM 326-00 E Page 10 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 11: Display: Error Screens (Error Messages)

    PIN code has been Instruction Manual IM 326-00 E Page 11 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr.
  • Page 12 Command Sub menu Instruction Manual IM 326-00 E Page 12 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 13: Figure 15: Enumeration Parameter (Ep)

    If a parameter cannot be edited due to locking, a parameter info display opens instead. Instruction Manual IM 326-00 E Page 13 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr.
  • Page 14 ESC. Instruction Manual IM 326-00 E Page 14 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr.
  • Page 15 COUNTER VALUE Display of the quantity and pulse counters Instruction Manual IM 326-00 E Page 15 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 16: Menu Structure: Language

    The change is made according to the explanations for enumeration parameters from section 4.5.3 Setting parameters. Instruction Manual IM 326-00 E Page 16 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 17: Menu Structure: Device Info (#1100)

    The setting for "Measuring point" can be found in previous versions under the "System" menu item. Instruction Manual IM 326-00 E Page 17 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr.

  • Page 18: Menu Structure: Inputs (#1500)

    / GD 300 / GD 500 also directly via the platinum wire. Instruction Manual IM 326-00 E Page 18 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...
  • Page 19 (For details see section 7.2 Factory calibration certificate for gas flow meter #2111 Justierung 00 (FS) Instruction Manual IM 326-00 E Page 19 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...
  • Page 20 A maximum of 32 measuring points can be defined. Instruction Manual IM 326-00 E Page 20 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...
  • Page 21 PTE-3W, PTE-4W Esters resistance thermometers for the GD 600, only usable for IFC 16XX! Instruction Manual IM 326-00 E Page 21 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr.
  • Page 22 Specification of the desired fixed value in mbar (FS: 1013.0 mbar) Instruction Manual IM 326-00 E Page 22 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 23: Menu Structure: Outputs (#2400)

    Type Limit A − Type Limit B Instruction Manual IM 326-00 E Page 23 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...
  • Page 24 (Display only when selected Pulse/pause: Custom) xxx ms (FS: 500 ms) Instruction Manual IM 326-00 E Page 24 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...
  • Page 25 Flow (20mA) (Display only when selected: Custom) (FS: 100.00) Instruction Manual IM 326-00 E Page 25 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 26: Menu Structure: Limits (#2900)

    Hysteresis B xxx.x % (FS 2.5 %) Instruction Manual IM 326-00 E Page 26 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 27: Menu Structure: System (#1200)

    /h (FS) − /min − − l/min Instruction Manual IM 326-00 E Page 27 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...
  • Page 28 #1210 Time&date Definition of date and time. Instruction Manual IM 326-00 E Page 28 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg Internet: http://www.esters.de...

  • Page 29: Menu Structure: Wizards (#1900)

    Welcome Activates the automatic language request at device start. Instruction Manual IM 326-00 E Page 29 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 30: Menu Structure: Access Rights (#1950)

    Display of the info screen for the respective meter readings Instruction Manual IM 326-00 E Page 30 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 31: Error Codes List

    Table 2: Error codes Instruction Manual IM 326-00 E Page 31 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 32: Appendix

    Figure 18: Overview nameplates GD 300 (Ex) und GD 100 Instruction Manual IM 326-00 E Page 32 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...

  • Page 33: Factory Calibration Certificate For Gas Flow Meter

    Figure 19: Factory calibration certificate for gas flow meter Instruction Manual IM 326-00 E Page 33 Phone: +49 6021- 45 807 - 0 Esters Elektronik GmbH eMail: info@esters.de Fax: +49 6021- 45 807 - 20 Hafenrandstr. 14 · D-63741 Aschaffenburg...
